Installation instructions
Zip
HydroTap G5
Model :
BCS HOME, BCS20, BCS20 H, BCS30, BCS30 H Command Centres
809998 v3.00 08.24 G5 BCS HOME_20_30 Online install instructions
®
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the HydroTap G5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zip Water HydroTap G5

  • Page 1 Installation instructions HydroTap G5 ® Model : BCS HOME, BCS20, BCS20 H, BCS30, BCS30 H Command Centres 809998 v3.00 08.24 G5 BCS HOME_20_30 Online install instructions...
  • Page 2: Table Of Contents

    BCS Home, BCS20 with Celsius Plus All in One Pull Out models, General layout ..........31 BCS Home, BCS20 models with Celsius Plus All in One tap, General layout .............32 BCS Home, BCS20 HydroTap G5 models ......................33 BCS20 H HydroTap and vented mixer tap combinations ................34 BCS Home, BCS20 All-In-One 'Mains' tap .......................35...
  • Page 3 INSTALLATION INSTRUCTIONS Table of contents Section 5 Commissioning ....................43 Commissioning using the HydroTap Clean can ....................43 Section 6 Service and Trouble shooting ................54 Section 7 Operation and Maintenance ................55 Cleaning ................................55 Section 8 End of life disposal ...................56 809998 v3.00 08.24 G5 BCS HOME_20_30 Online install instructions...
  • Page 4: Using These Instructions

    Using these instructions Explanation of symbols Button/ WARNING DANGER DANGER DANGER Read the coin battery WARNING Electric shock Hot surface Flammable instructions Safety instructions Read and use the instructions and safety information supplied with individual kit components for a safe installation. Section 1 IMPORTANT SAFETY INSTRUCTIONS Compliance In Australia electrical installation must comply with AS/NZS3000.
  • Page 5 Application The HydroTap G5 Home series is intended to be used in household and similar applications such as: • Staff kitchen areas in shops, offices and other working environments; • Farm houses and by clients in hotels, motels and other residential type environments;...
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS Compressed gas warning - HydroTap Clean can • Read label before use. • Keep out of reach of children. • Use according to SDS (safety data sheet). • Pressurised container. Contains gas under pressure,may explode if heated. •...
  • Page 7: Warnings And Regulatory Information

    WARNINGS AND REGULATORY INFORMATION • For continued safety of this appliance it must be installed, operated and maintained in accordance with the manufacturer’s instructions. • This appliance may deliver water at high temperature. Refer to the Plumbing Code of Australia (PCA), local requirements and installation instructions to determine if additional delivery temperature control is required.
  • Page 8 WARNINGS AND REGULATORY INFORMATION • For water taste and quality reasons, following any non-use period of more than 72 hours, Zip recommends to perform a system flush. Failure to flush the system may affect water quality. • For UK, this appliance only contains materials that conform to the requirements of BS6920:2014 ‘Suitability of non metallic materials and products for use in contact with water intended for human consumption with regard to their effect on the quality of water'.
  • Page 9: Technical Data

    Technical data Technical data table Dimensions Power rating kW Power rating kW Weight Model W x D x H (mm) 220-240V 50Hz 220V 60Hz (kg) Command Centre only Boiling Chilled Sparkling models BCS30, BCS30 H 1.96 + Booster 1.86 + Booster 339 x 483 x 333 BCS20, BCS20H 1.96...
  • Page 10: Supplied Parts Checklist

    Supplied parts checklist BCS models Parts supplied in the kit BCS20 BCS20 H BCS30 BCS30 H BCS Home HydroTap tap, pipes, tubes  hoses and fittings Vented Mixer Tap, hoses,     fittings & instructions Mains Mixer Tap, hoses, Optional ...
  • Page 11: Installation Checklist

    Installation checklist • Check if there is adequate space to install all of the components. • Note Not all fittings are supplied with the appliance kit. Isolation valves are not supplied. • Check the mains water pressure is within min / max requirements. •...
  • Page 12: Before Installation

    Before installation • Review of all the technical specifications. • Ensure the under counter cupboard floor can support the product weight when full of water (allow an extra 3-8kg when full). • Sufficient space in the cupboard to install the Command Centre and other components in accordance with these installation instructions.
  • Page 13: General Product Features

    General product features Thank you for purchasing a Zip HydroTap G5. Please read and follow these instructions carefully to ensure safe and trouble free operation. If help and advice is required, contact your local service provider. What is the Zip HydroTap G5 ? This Zip HydroTap G5 is an electronically controlled, filtered, boiling, chilled and sparkling (functionality is dependant upon model purchased) drinking water system for the kitchen.
  • Page 14: Section 2 Ventilation

    Section 2 Ventilation Read and use the instructions and safety information supplied with individual kit components for a safe installation. Clearance envelope & airflow The integrated vent aperture must be cut out of the cupboard floor & mounting plate fitted. The vent provides a safe exhaust for the refrigerant gas in the unlikely event of a leak.
  • Page 15 Section 2 Ventilation BCS Home, BCS20, BCS20 H, BCS30, BCS30 H Vent grilles & plates cut-outs ventilation options For integrated vent cut-out, check Option 1: Ventilation arrangement using small cupboard with min. size relative to your product. 40mm overhang Directing warm air straight into the room. Must be installed For Command Centre width 339mm C l e...
  • Page 16: Section 3 Ancillary Installations - Install Rail Installation (Uk Only)

    Section 3 Ancillary Installations - Install Rail installation (UK only) Description • The install rails can be used to safely connect a wide range of water appliances to the mains water supply. The install rails include an isolation valve, double check valves, tamper proof pressure reducing valve pre- set to 0.3 MPa and a flood preventer with reset.
  • Page 17: Section 3 Ancillary Installations - Connect To The Water Supply

    Section 3 Ancillary Installations - Connect to the water supply Connect the braided hose to the mains water supply Valves and fittings must be sealed with PTFE tape if compression seals are not included. Note correct strainer orientation. Note Mixer tap installations also use a ‘Tee piece’ as part of the water supply plumbing connections, see the Tap installation instructions supplied with the Mixer Tap to connect the water supply if using the mixer tap option.
  • Page 18: Section 3 Ancillary Installations - External Limescale Filter Bypass Valve

    Section 3 Ancillary Installations - External Limescale filter bypass valve External bypass valve The following products have an external bypass valve. The external bypass valve allows the user to choose to have the boiling feed water bypass the internal filter and only be filtered by the external filtration.
  • Page 19: Section 3 Ancillary Installations - Limescale Filter Installation (Uk Only)

    Section 3 Ancillary Installations - Limescale filter installation (UK only) Limescale filter Note UK only option. An external lime scale filter may be fitted as an optional accessory to reduce the incidence of lime scale build up in the hot tank or may be supplied at the customer’s request. For Limescale filter installation instructions, scan the QR code on the Limescale filter carton.
  • Page 20: Section 3 Ancillary Installations - Booster System Installation

    The booster system is a compact electronically controlled auxiliary water heater. It is intended to provide pre-heating of water before it enters the Zip HydroTap G5 boiling tank. If the booster is used the boiling water output will be increased. Note 1 Water connection blue cap - water in.
  • Page 21 Section 3 Ancillary Installations - Booster system installation Installation procedure Site requirements • Booster must only be installed in a frost-free area. Never expose booster to frost. • The booster is designed for wall mounted installation and must be installed with water connectors facing upwards.
  • Page 22: Braided Hose Connections

    Note 1 This appliance is intended for use with the Zip HydroTap G5 Command Centre. Note 2 Water connections must be pointing vertically upwards. Note 3 The booster unit should be installed as close as possible to the Zip HydroTap G5 as the connection hoses cannot be lengthened.
  • Page 23: Secure The Cylinder

    Section 3 Ancillary Installations - CO cylinder and regulator Be aware of the risks of hazards which could cause harm when handling compressed CO2. Read the safety warnings at the start of this instruction manual. Assess the risks before starting the installation.
  • Page 24: Fit The Regulator And Connect The Gas Hose

    Section 3 Ancillary Installations - CO cylinder and regulator Fit the regulator and connect the gas hose • Ensure all mating surfaces are clean. • Turn the regulator OFF, (fully anticlockwise). • Check the regulator and hose seals, inside the connectors. •...
  • Page 25: Adjust The Universal G5 Regulator

    Section 3 Ancillary Installations - CO cylinder and regulator Adjust the Universal G5 regulator Cylinder pressure • Check the regulator is turned all the way OFF (anti-clockwise). • Turn the gas ON using the cylinder valve, Outlet (anti-clockwise). (dual-gauge regulator). pressure •...
  • Page 26: Section 4 Command Centre Installation

    Section 4 Command Centre installation Generic installation arrangement instructions Read these instructions together with those supplied with individual components before commencing Command Centre installation,they apply to all installation arrangements. • Install the mains water braided hoses to the Command Centre before locating in place.
  • Page 27: Position Of Carbonation Flow Valve (Sparkling Models)

    Elite carbonation flow valve as close to the tap as possible. • Use the diagrams as a guide. BCS240 /175 HydroTap G5 models BCS160 /175HydroTap • For the Celsius AiO Arc, the silicone tubes can be easily deformed, cable-tie the chilled tube assembly to an adjacent braided hose to avoid kinks and loops (as shown).
  • Page 28: John Guest Pipe And Fittings

    Section 4 Command Centre installation John Guest pipe and fittings Take care to use correctly, see below : Insert Remove 2. Pull pipe 1. Cut pipe clean & square 1. Press collet 2. Push pipe to down end stop Mains power cable Do not connect to the mains socket until commissioning Connect Command Centre to HydroTap.
  • Page 29: Bcs Home, Bcs20 Models, General Layout

    Section 4 Command Centre installation BCS Home, BCS20 models, General layout Command Centre Mains electrical power connector *CO2 cylinder *CO2 regulator Tap - Command Centre USB Carbonation valve Mains water supply Tap connections Mains braided hose - Command Centre manifold regulator Mains braided hose - Command Centre Water supply connection...
  • Page 30: Bcs20 H Models, General Layout

    Section 4 Command Centre installation BCS20 H models, General layout Command Centre Mains electrical power connector *CO2 cylinder *CO2 regulator Tap - Command Centre USB Carbonation valve Vented mixer tap Mains water supply Mains braided hose - Command Centre manifold Tap connections regulator Mains braided hose - Command Centre...
  • Page 31: Bcs Home, Bcs20 With Celsius Plus All In One Pull Out Models, General Layout

    Section 4 Command Centre installation BCS Home, BCS20 with Celsius Plus All in One Pull Out models, General layout Command Centre Mains electrical power connector *CO2 cylinder *CO2 regulator Tap - Command Centre USB Carbonation valve Mains water supply Hose management system Mains braided hose - Command Centre manifold Tap connections...
  • Page 32: Bcs Home, Bcs20 Models With Celsius Plus All In One Tap, General Layout

    Section 4 Command Centre installation BCS Home, BCS20 models with Celsius Plus All in One tap, General layout Command Centre Mains electrical power connector *CO2 cylinder *CO2 regulator Tap - Command Centre USB Carbonation valve Mains water supply Mains braided hose - Command Centre manifold Tap connections regulator...
  • Page 33: Bcs Home, Bcs20 Hydrotap G5 Models

    Section 4 Command Centre installation BCS Home, BCS20 HydroTap G5 models Command Centre connections Braided hose HydroTap Optional limescale filter BCS comm BC comm Connections key Mains CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS Fit foam insulation (supplied) to...
  • Page 34: Bcs20 H Hydrotap And Vented Mixer Tap Combinations

    Section 4 Command Centre installation BCS20 H HydroTap and vented mixer tap combinations Command Centre connections Braided hose Optional limescale filter HydroTap BCS comm BC comm Connections key Mixer Tap Mains connections CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS Fit foam insulation (supplied) to OUTLET...
  • Page 35: Bcs Home, Bcs20 All-In-One 'Mains' Tap

    Section 4 Command Centre installation BCS Home, BCS20 All-In-One 'Mains' tap Command Centre connections Braided hose Optional limescale filter HydroTap BCS comm BC comm Connections key Mains Fit foam insulation (supplied) to CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS OUTLET OUTLET...
  • Page 36: Bcs20 H All-In-One 'Vented' Tap

    Section 4 Command Centre installation BCS20 H All-In-One 'Vented' tap Command Centre connections Braided hose Optional limescale filter HydroTap BCS comm BC comm Connections key Mixer Tap Mains connections CHILLED SPARKLING MAINS MIXER Fit foam insulation (supplied) to MIXER BOILING BYPASS VENT BYPASS...
  • Page 37: Bcs Home, Bcs20 All-In-One Plus Pull-Out Tap

    Section 4 Command Centre installation BCS Home, BCS20 All-in-One Plus Pull-Out tap Command Centre connections Braided hose Optional limescale filter HydroTap BCS comm BC comm Connections key Mains Fit foam insulation (supplied) to CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS OUTLET...
  • Page 38: Bcs30 Models, General Layout

    Section 4 Command Centre installation BCS30 models, General layout Command Centre Mains electrical power connector *CO2 cylinder *CO2 regulator Tap - Command Centre USB Carbonation valve Tap connections Booster Mains water supply Mains braided hose - Command Centre manifold Bypass Booster braided hoses link - Command Centre...
  • Page 39: Bcs30 Hydrotap G5 Models

    Section 4 Command Centre installation BCS30 HydroTap G5 models Command Centre connections Braided hose HydroTap Booster and lime scale filter (optional) BCS comm BC comm Connections key Mains CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS Fit foam insulation (supplied) to...
  • Page 40: Bcs30 H Hydrotap And Vented Mixer Tap Combinations

    Section 4 Command Centre installation BCS30 H HydroTap and vented mixer tap combinations Command Centre connections Braided hose Booster and HydroTap lime scale filter (optional) BCS comm BC comm Connections key Mixer Tap Mains connections CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT...
  • Page 41: Bcs30 All-In-One 'Mains' Tap

    Section 4 Command Centre installation BCS30 All-In-One 'Mains' tap Command Centre connections Braided hose Booster and lime scale filter (optional) HydroTap BCS comm BC comm Connections key Mains Fit foam insulation (supplied) to CHILLED SPARKLING MAINS MIXER MIXER BOILING BYPASS VENT BYPASS OUTLET...
  • Page 42: Bcs30 H All-In-One 'Vented' Tap

    Section 4 Command Centre installation BCS30 H All-In-One 'Vented' tap Command Centre connections Braided hose Booster and lime scale filter (optional) HydroTap BCS comm BC comm Connections key Mixer Tap Mains connections CHILLED SPARKLING MAINS MIXER Fit foam insulation (supplied) to MIXER BOILING BYPASS...
  • Page 43: Section 5 Commissioning

    • Initial commissioning touch screen , set language option. COMMISSIONING 12:12 PM • The language is set automatically by country, but this can be changed manually, if required, by touching the language icon. HydroTap G5 Language 024-H5v0.1.16 BCS100 0000000000000 H50063000AU •...
  • Page 44: Select The Language

    Section 5 Commissioning Select the language • Touch the appropriate button to select the language and units of LANGUAGE 10:50 choice. • Touch the back arrow to go back to previous menu. • In the previous menu, touch the arrow to begin the commissioning process.
  • Page 45: Filter Flush

    Section 5 Commissioning Set the date, time & drain away options • Touch the date and time, use "-" or "+" to make adjustments. When DATE & TIME 10:50 ready, touch the arrow to continue. 2021 24 hr Time • Select 'Sink / Container' or 'Font' depending on the model , see DRAIN AWAY OPTION 9:26 below.
  • Page 46 Section 5 Commissioning FILTER FLUSH 12:12 PM FILTER HAS BEEN FLUSHED! Turn the flush line STOP COCK VALVE back to the OFF position Your filter has now been flushed and is ready to use. You will need to check the life span of the filter in filter settings •...
  • Page 47: System Priming

    Section 5 Commissioning LIMESCALE FILTER FLUSH 12:12 PM IN OUT LIMESCALE FILTER HAS BEEN FLUSHED! Reconnect the limescale filter hose to the manifold. • Once the filter flush is finished, reconnect the limescale filter OUT hose to the Command Centre manifold. •...
  • Page 48 Section 5 Commissioning HYDROTAP CLEAN PREPARATION 12:12 PM Step 3. Install HydroTap Clean adapter (1) into filter head. Step 4. Insert HydroTap Clean can (2) into adapter (1). Filter head • Check the adapter seal is present and correctly positioned in the adapter. •...
  • Page 49 Section 5 Commissioning • Confirm installation of the HydroTap Clean can by selecting YES HYDROTAP CLEAN PREPARATION 12:12 PM on the screen. Confirm that the HydroTap Clean can has been installed? Boiling calibration and cleaning • Read the on screen information. BOILING CALIBRATION &...
  • Page 50: Tank Flush

    Section 5 Commissioning • Unscrew the HydroTap Clean can (2). • Ensure to hold the adapter in place while unscrewing the can. 12:12 PM RE-INSTALL FILTER RE-INSTALL FILTER 12:12 PM If the below steps have not been completed. While Boiling Calibration in Progress..Follow the instructions below.
  • Page 51 Section 5 Commissioning • If NO is selected (indicating that it is not safe to continue) the EMPTY HOT TANK 12:12 PM screen will prompt the user to clear the sink area. • Once it is safe to continue select YES to empty the hot tank. Boiling water will be dispensed into your sink.
  • Page 52 Section 5 Commissioning • Touch the green arrow to run. PURGE WATER WITH CO2 12:12 PM • CO2 life settings should be adjusted for the size of the CO2 bottle Running connected. (see the User guide or Online Installation and User Water is now being purged from the sparkling chamber.
  • Page 53: Safety Sensor Calibration

    Light intensity varies from site to site, therefore it is recommended that a re-calibration be performed at the time of the installation. All direct sunlight must be shaded from the HydroTap G5, during the calibration. This can be achieved by closing any nearby curtains, blinds, etc.
  • Page 54: Section 6 Service And Trouble Shooting

    Section 6 Service and Trouble shooting Service items • Filters should be replaced at six month intervals for Commercial HydroTaps, and 12 month intervals for Residential HydroTaps. • CO2 regulator washers should be replaced annually. Trouble shooting table Fault Fault name Fault trigger code Power Board Fault...
  • Page 55: Section 7 Operation And Maintenance

    Section 7 Operation and Maintenance Please refer to the User Guide for all operational and maintenance features of the HydroTap. The User Guide is located in the HydroTap Command Centre filter door. Zip offers a fully-inclusive HydroCare Service Plan to take care of all routine maintenance, including filter replacements, sanitisation, electrical safety inspections as well as general maintenance of your HydroTap.
  • Page 56: Section 8 End Of Life Disposal

    Section 8 End of life disposal Waste electrical and electronic equipment The symbol above means that according to United Kingdom and European Union member countries laws and regulations, your product and /or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.
  • Page 57 WMKA00099 WMKA21821 AS 3498 AU02691 WMTS-105 Zip Water Zip Water UK 67 - 77 Allingham Street, Trafalgar House, Condell Park, NSW 2200 Rash’s Green, Dereham, Postal: Locked Bag 80, Norfolk, NR19 1JG Bankstown 1885 0345 6 005 005 Australia sales@zipindustries.co.uk (+612) 9796 3100 www.zipwater.co.uk...
