uick Reference Installation Guide
Q
Zip HydroTap G5
Command Centre - BCS HOME, BCS20, BCS20 H,
BCS30, BCS30 H, BCS 60, BCS 60 H, BCS100, BCS100 H
Follow these steps for a safe and effective install.
1
Read the safety information
overleaf.
This QRIG may be sufficient
for installers who have
had previous HydroTap
installation experience.
Inexperienced installers
please scan the QR codes
for detailed installation
instructions.
2
Contact us if you need support and advice.
Zip Water Australia
67 - 77 Allingham Street, Condell Park NSW 2200
Postal: Locked Bag 80, Bankstown 1885
Australia, Tel (+612) 9796 3100, Free call 1800 947 827 (1800 ZIP TAP)
Zip Water UK
Trafalgar House, Rash's Green, Dereham,
Norfolk, NR19 1JG
United Kingdom, Tel 0345 6 005 005
Quick Reference Installation Guide
810008 v1.00 08.24 G5 BSC Quick Reference Installation Guide
!
!
!
Installation
Full installation
videos
instructions
BCS20, BCS20 H
BCS30 , BCS30 H
!
!
V
U
Full installation
instructions
BCS Home
BCS60, BCS60 H
BCS100, BCS100 H
!
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Zip Water HydroTap G5
Summary of Contents for Zip Water HydroTap G5
- Page 1 Reference Installation Guide Zip HydroTap G5 Command Centre - BCS HOME, BCS20, BCS20 H, BCS30, BCS30 H, BCS 60, BCS 60 H, BCS100, BCS100 H Follow these steps for a safe and effective install. Read the safety information overleaf.
-
Page 2: Safety Information
Safety information This document is a Quick Reference Installation Guide. Download & read the full Command Centre installation instructions for more installation information. Explanation of symbols Read the Compressed Danger of instructions Gas WARNING electric shock Highly WARNING Lithium flammable Surface Coin cell •... - Page 3 A ventilated area is a non-enclosed area which could include the kitchen, living room etc. • The HydroTap G5 Home series is intended to be used in household and similar applications such as: •...
- Page 4 Installation - Technical data, part supplied Review the technical data & parts supplied in the kit. Power rating, kW Dimensions Water supply Weight Model 220-240V, 50Hz W x D x H (mm) Connection (kg) BCS100,BCS100 H 2.15 + Booster 395 x 487 x 333 G 1/2 BCS60,BCS60 H 2.15...
- Page 5 Ventilation installation instructions Make sure there’s enough ventilation in the cupboard, air needs to circulate as follows: Cold air is drawn in through the gaps provided by the door buffers (supplied), they must be fitted. Command Centre clearances must be observed. Warm air is expelled through the integrated vent in the base of the Command Centre, via the vent cut-out in the cupboard floor.
- Page 6 Ventilation installation instructions BCS Home, BCS20, BCS20 H, BCS30, BCS30 H ventilation options Option 1: Ventilation arrangement using small cupboard with min. 40mm overhang Directing warm air straight into the room. Must be installed C l e a r a Inlet Must be installed...
- Page 7 Ventilation installation instructions BCS60, BCS60 H, BCS100, BCS100 H ventilation options Option 3: Ventilation arrangement using large cupboard with min. 40mm overhang Directing warm air straight into the room. Must be installed Inlet Must be installed Extra Inlet vent option Option 4: Ventilation arrangement using small cupboard with min.
- Page 8 Ventilation installation instructions Option 5: Ventilation arrangement if using a large cupboard with less than 40mm, or no overhang. Directing warm air into the kick space & out through a vent grille. Must be installed Inlet Both must be installed Extra Inlet vent option Option 6: Ventilation arrangement if using small cupboard with less than 40mm, or no...
- Page 9 Installation - Ancillary components, Booster If supplied as part of the kit mount the Booster as follows: 10⁰ 15⁰ Connect the braided hoses to the Booster: Do not over tighten hose connections. Braided hoses supplied cannot be lengthened. 3/8" BSP connections Cold water into Booster, Hot water out of Booster,...
- Page 10 Installation - Ancillary components, Carbonation valve When fitting the carbonation valve, observe the following guidelines : Classic, Wave Celsius Other Avoid AiO Arc Classic Plus, sparkling Elite 12 14 Adjust the carbonation valve during commissioning, see sections Use an Allen key or screwdriver to adjust the carbonation flow.
- Page 11 BCS Home, BCS20, BCS20 H, BCS30, BCS30 H Installation Scan the QR Code & Install the HydroTap in order read the instructions Install the vent mounting plate on the cupboard floor, scan the QR Code & read the instructions. Ventilation Installation Install Rail Instructions UK only...
- Page 12 BCS Home, BCS20, BCS20 H, BCS30, BCS30 H Commissioning Commission the HydroTap in order Commissioning process, follow screen prompts, scan HydroTap Clean QR for more information. If cupboard temperatures exceed 35 C additional ventilation HydroTap Clean will be required. To use the HydroTap, scan the User Guide QR Code &...
- Page 13 BCS60, BCS60 H, BCS100, BCS100 H Installation Scan the QR Code & read Install the HydroTap in order the instructions Install the vent mounting plate on the cupboard floor, scan the QR Code & read the instructions. Ventilation Installation Install Rail Instructions UK only Fit the tap connections:...
- Page 14 BCS60, BCS60 H, BCS100, BCS100 H Commissioning Commission the HydroTap in order Commissioning process, follow screen prompts, scan HydroTap Clean QR for more information. HydroTap Clean If cupboard temperatures exceed 35 C additional ventilation will be required. Turn on water supply &...
- Page 15 Notes Quick Reference Installation Guide 810008 v1.00 08.24 G5 BSC Quick Reference Installation Guide...
- Page 16 Refer to User Guide for operation and maintenance. As Zip policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
