  • Page 2 OPERATOR' S MANUAL Novus Performance Products LLC, Tel:800-409-7802 Email:support@novuspowerequipment.com...
  • Page 3 ◇This manual covers instruction for operation and maintenance of NV FTG. ◇Novus may revise this manual without prior notice. ◇No part of this manual may be reproduced without written consent. ◇This manual should be considered a part of the tiller and should be transferred along with it when resold.
  • Page 4 NV17FTG Assembly Instructions NV17FTG Assembly Instructions...

  • Page 5: Table Of Contents

     ■CONTENTS Safety Information Your safety and the safety of others are very important. We have provided important safety information in the manual and on the machine itself. 1.Safety Precautions and Warnings Please read them carefully. 2.Main Specification and Structure 1.Specification Sheet Safety information alerts you to potential hazards that could harm you or others.

  • Page 6: Safety Precautions And Warnings

    f ) Stop the engine when doing the following works: leaving machine, cleaning 1. Safety Precautions and Warnings knives, repairing, adjusting and inspecting. ◆1.Training g) When no people is operating the tiller, the engine must be stopped, the tiller a ) Carefully learn the manual, be familiar with proper use of the machine. placed in neutral gear, and clutch released.

  • Page 7: Main Specification And Structure

    2. Main Specification and Structure ◆5.Safety Warning Stickers ◆1.Main specification !Warning Item Data Engine model W80F gasoline engine Max. power(kW) Engine Rated power(kW) Rated speed(r/min) 3100 Dimension(L*W*H)(in) 43.3*21.3*39.4 A2Maximum noise limit signs A1Knives protector and safety signs Weight(lb) Transmission Chain V belt,tension pulley Connections Designed speed(r/min)

  • Page 8: Scope Of Application

    ◆2.Structure 3 groups Tines setting 4 pieces Standard knives Tines quantity 4×3 Tilling width 17 inch Sheet 2 1.Handlebar 2.Clutch rod 3.Handle connect bending pipe 4.W80F/P-M engine 5.Engine frame 6.Flameout switch 7.Belt cover 8.Dust fender 9.Tines 10.Road wheels 11.Resistance rod Drawing 2 4.

  • Page 9: Operation

    Notice Don't start engine without an air filter, which can accelerate engine 5. Operation wear. Before the tiller leaves the factory,we have made routine adjustments. But ◆2. Tiller condition adjustment before using machine, you should check,adjust and make machine in better working condition.

  • Page 10: Adjustment

    Notice If the clutch cable is not properly adjusted, it will affect the operation of the tiller. ◎If necessary, start engine to check if the clutch can work properly. ◆3.Tilling Work Precautions !Notice ◇3.1 When working, you should pay attention to the working condition of all parts, check if they are well connected.

  • Page 11: Engine Operation

    7. Engine Operation ◇2.2 Flameout switch adjustment ◆1.Start steps Before start engine, clutch rod must be released. ① Connect flameout switch with engine flameout wire. ◇1.1 Turn the choke handle to the "CLOSE" position. ②Turn flameout switch to OFF, then the engine will stop immediately. ◇1.2 Adjust the fuel valve from low speed to high speed, about 2/3 position.
  • Page 12 ◇1.4 Pull the starter grip slowly until feel the resistance, then pull it fast. High speed Low speed ◇1.5 If starting engine by choke handle on CLOSE position, when engine is hot, you should turn the choke handle on OPEN position. ◇2.3 Close the engine switch.

  • Page 13: Maintenance

    ◆3.Tiller maintenance time table (The marked V indicates what should be done). 8. Maintenance Every 1st month 3rd months Every Half load Time Every It is inevitable that the tiller has problems after working due to variations in load, year or work 8 or every or every 150...

  • Page 14: Tiller Long-Term Storage

    ◇4.7 Take out and use the engine !Warning 4.7.1 Use methods as mentioned earlier to check engine. Don’t use water to wash the engine! Otherwise water may enter into air filter and muffler, and then cause the engine to broke. 4.7.2 If all gasoline evaporates, add new gasoline.

  • Page 15: Troubleshooting

    ◆2.Tiller Troubleshooting Sheet 9. Troubleshooting Troubleshooting Problem Reason Clutch doesn’t work or Belt is too tight Adjust engine position, make ◆1.Engine Troubleshooting cannot work well belt more loose Belt is tight when tension pulley is When the recoil starter can't start the engine. Adjust clutch cable, make already loose.

  • Page 16: Tiller Wearing Parts List

    10. Tiller Wearing Parts List Name Affiliated components Handle bar comp Clutch cable Handle bar comp Flameout switch Handle bar comp Rubber handle Refer to engine manual Engine wearing parts 11. Accessories List Usage Name Pair Note Unit 4 pcs 3 groups knives Tilling Piece Standard...

  • Page 17: Parts List

    12. Parts List Wearing Parts Ref No. Material Code Description 1900200004-0001 Carburetor Gasket 1907100003-0001 Exhaust Pipe Gasket 1901000023-0001 Air Filter Gasket 1202000007-0001 Cylinder Head Gasket 1101400004-0001 Crankcase Gasket 2000100042-0016 Starter Assembly 2204700004-0001 Spark Plug 1807900069-0001 Carburetor Assembly 2001900002-0001 Starter Cup 1903700041-0001 Air Filter Foam Element 1300500016-0001...

  • Page 18: Gear Box Components

    Gear Box Components Ref No Material Code Description 2106000009-0006 Gearbox Body Case 360720006 Deep Groove Ball Bearing 6003-2Rs 2121000002-0001 Driving Sprocket'S Shaft Assy 2100200013-0001 Chain 06B-1-84 2112800007-0001 Supporting Shoe For Chain 360380019 Hexagon Socket Head Cap Screws M6×55 2413200002-0005 Hoop Assembly For Gearbox 360120005 Hexgon Locking Nut M6(Non-Metallic) 3417700001-0001...
  • Page 19 Engine Support Frame and Dust Fender Ref No Material Code Description 360180012 Hexgon Locking Nut M6(Non-Metallic) 2601600072-0009 Tine Sheild 360660004 Flat Washer No.6 2410300001-0001 Supporting Plate 360300007 Hexagon Flange Bolt M6×16 2401200044-0005 Engine Support 360300197 Hexagon Flange Bolt M6×45 3410800081-0001 Support Sheath 10×7×27...
  • Page 20 Walking Wheel Components Ref No Material Code Description 360920015 Snap Ring No.12 360660009 Flat Washer No.12 2803100002-0001 Walking Wheel 2805400001-0001 Strut Bar For Walking Wheel 2113200001-0001 Torsinoal Spring Pin Φ8 2401300011-0001 Resistance Rod 361020029 Pin 8×43 3402200004-0001 Jump Ring B...

  • Page 21: Engine Components

    Engine Components Ref No Material Code Description T011030009 W80F Engine 360220039 Hexagon Flange Bolt M8×16...

  • Page 22: Handle Components

    Handle Components Ref No Material Code Description 360180013 Hexgon Locking Nut M8(Non-Metallic) 2402400001-0010 Handle Connect Bending Pipe 2400600002-0002 Self-Locked Hoop 22 3419400001-0001 Arc Stud 2402300055-0008 Handle Bar 3000900013-0002 Clutch Handle 3000500007-0001 Grip Φ22 3009200006-0001 Main Clutch Cable 3417100003-0001 The Curved Gasket 360210006 Cap Nut M8 2210900012-0001...
  • Page 23 Belt Cover Components Ref No Material Code Description 2601500011-0013 Belt Cover Baseplate 360660004 Flat Washer No.6 360390018 Hexagon Socket Button Head Screws M6×20 360920017 Snap Ring No.15 2109200004-0001 Driven Pulley 2123600027-0001 Belt 13×945Lw 360480006 Flat Holding Screw M8×16 2110300007-0001 Tensioning Wheel Assembly 360980068 Flat Key 5×5×30 2419800001-0001...
  • Page 24 3404700002-0001 Tension Pulley Return Spring 360850005 Round Pin 6×60 360120013 Hexgon Locking Nut M10(Non-Metallic) 2422000006-0001 Belt Cover Baseplate 3410800062-0001 Spacer Bush 9×13×9 2113000009-0001 Belt Strut Bar 360250028 Hexagon Bolt M8×25 2106600012-0001 Driving Pulley 360250070 Hexagon Bolt M10×35...
  • Page 25 Tine Components Ref No Material Code Description 2702700005-0002 Vice Tines Comp 2 2702600005-0002 Vice Tines Comp 1 2702500005-0002 Main Tines Comp 361020072 Pin 8*32 3402200004-0001 Circlip B...

  • Page 26: Warranty

    Novus Performance Products LLC certifies that Novus Products are fit for ordinary purposes for which a product of this type is used. Novus Performance Products LLC however, limits the implied warranties of merchantability and fitness in duration to a period of two (2) years in consumer use, ninety (90) days for any other use.
