- Page 1 ’1 8口RTG TILLER $N。�u� @JNOVUS Novus Performance Products LLC, Tel:800-409-7802 Email:support@novuspowerequipment.com Ve『sion : 2024.01...
- Page 3 Safety Information Your safety and the safety of others are very important. We have provided important safety information in the manual and on the machine itself. Please read them carefully. Safety information alerts you to potential hazards that could harm you or others. The safety information is preceded by a safety alert symbol and one of three safety words (DANGER, WARNING, CAUTION).
-
Page 4: Table Of Contents
Table of Contents 1. Safety Precautions and Warnings ..................5 1. Training ........................5 2. Preparation ......................5 3. Operation .........................6 4. Maintenance and Storage ..................7 5. Safety Warning Signs ....................8 2. Technical Specifications ....................9 1.Specification Sheet ....................9 2.Schematic Diagram of the Structure ..............10 3. -
Page 5: Safety Precautions And Warnings
1. Safety Precautions and Warnings 1. Training a) Read the operation and maintenance manual carefully. Become familiar with all the operation mechanism and the correct way of using the machine. Learn how to stop the engine and quickly disengage the clutch. b) Do not allow children to use the machine. -
Page 6: Operation
3. Operation a) Never put your hands or feet near or even under the rotating parts. b) Take special care when operating on or crossing gravel surfaces, sidewalks, or roads. Be alert to potential dangers, pay attention to traffic, and do not carry passengers. c) After hitting an object, stop the engine, check the machine thoroughly for any damage. -
Page 7: Maintenance And Storage
m) Never operate the tiller at high speeds on slippery surfaces. Be careful and watch behind when reversing. n) Never allow onlookers near the machine. o) Only use attachments and equipment approved by the manufacturer (e.g., wheel weights, counterbalance blocks, cabins). p) Do not operate the tiller in poor visibility or lighting conditions. -
Page 8: Safety Warning Signs
5. Safety Warning Signs... -
Page 9: Technical Specifications
2. Technical Specifications 1. Specification Sheet Number Item Unit Parameter Body Model NV18DRTG Structure type Two-wheel drive Dimensions 1600*520*940 Weight Transmission Gear type Clutch type Disc clutch Work Speed 0.22 Engine Model WM170F/P-2 Power Speed r/min 3600 Type of fuel... -
Page 10: Schematic Diagram Of The Structure
2. Schematic Diagram of the Structure Pulley Cable Drag Rod Handle frame Handle Adjustment Components Connecting Rod Tine Shield Tines Walking wheel Bumper Output clutch bar Engine Switch, Throttle Switch 3. Scope of Application This machine is suitable for farming in greenhouses, vegetable fields, orchards, gardens, and other areas from plains, hills, and mountainous areas. - Page 11 with hex bolts and nuts (see Figure 2). 4. Attach the tine assembly and soil-breaking shovel to the output shaft of the tilling box, and secure the tine assembly with a pin shaft and circlip B, then fasten the soil-breaking shovel with bolts (see Figure 3).
-
Page 12: Operation Instructions
5. Operation Instructions Before the tiller is shipped to you, we have made necessary adjustments to the machine. However, before you use it, please check and adjust it again to make it work best for you. 1.Check the Machine and Add Fluids ◇1.1 Check whether the connecting bolts are loose. -
Page 13: Height Adjustment
2. Height Adjustment Before adjusting the height of the handle frame, place the machine on flat ground to prevent accidental tipping. ◇2.1 Height of handle frame ◇2.2 Adjustment of tilling depth Adjust the armrest rack height with the adjusting handle. Control the tilling depth by changing the height of the resistance rod, when the resistance rod is moved downward, the depth becomes shallow, when the resistance rod is moved upward, the depth becomes deeper. -
Page 14: Operate The Tiller
4. Operate the Tiller ◇4.1 Start: Disengage the clutch handle, and each shift handle is in neutral position. ◇4.2 Operation: Put the shifts lever in the required gear position, and then press the Then start the engine according to the steps in The Engine User's Manual. ◇4.3 Forward rotation tilling: When the machine is cultivating soft soil, the shifts lever pulley cable drag rod to enter working or walking state. -
Page 15: Precautions For Daily Use
6.Precautions for Daily Use ◇5.1 In the process of use, pay attention to the working conditions and sound of each part, check whether the connection of each part is normal or not, loosening of any part is ◇5.2 It is not allowed to carry out heavy load work immediately after the machine just not allowed. -
Page 16: Technical Maintenance
amount of gasoline. Pull recoil handle for 5-10 times to clean it, and then drain the gasoline. Finally, add oil for a 4-hour running-in, and now your machine is now ready to work. 2. Technical Maintenance 2.1 Per-use Maintenance (before and after each work). Listen and observe if any part has abnormal issue (such as abnormal noise, overheating and loose screws, etc.). -
Page 17: Maintenance Chart
should disassemble the whole machine, clean and inspect it, and replace worn parts with new one. 3. Maintenance Chart (the standard “✔” in the table indicates the maintenance content that should be done) Interval Every Eight First month Third month Per year Second hours at... -
Page 18: Long-Term Storage Of The Tiller
4. Long-term Storage of the Tiller When you need to store the machine for a long time, the following steps should be ◇4.1 Clean dust and dirt from the surface. followed to prevent corrosion. ◇4.2 Drain the lubricating oil in the transmission case and add new oil. ◇4.3 Apply anti-rust oil on any non-aluminum alloy surface which has no paint on it. -
Page 19: Adjustment Method And Characteristics
Adjustment Method and Characteristics 1. Clutch Cable After the machine has been used for a period of time, clutch performance might be poor due to wear of the friction plate and the clutch fork. To solve the problem, the clutch ◇1.1 Adjustment of clutch cable cable should be adjusted. -
Page 20: Throttle Cable
2. Throttle Cable Air filter Terminal, Locking nut Fixing seat Adjustment plate Throttle cable ◇2.1 Adjust the throttle cable so that the throttle handle can be pulled to the maximum and minimum positions, and then lock the throttle switch screw. -
Page 21: Troubleshooting
Troubleshooting Issue Reasons Remedy Gear is not in place Hexagonal screw of the shift Replace the hexagonal screw fork shaft is broken Pad is seriously worn Replace the shift pad Shifting fork is worn out Replace the shift fork shaft Internal positioning spring of Replace the spring the first shaft fails... -
Page 22: List Of Wear Parts
10. List of Wear Parts Number Part Belongs to Clutch cable Handle assembly Throttle cable Handle assembly Engine switch, Handle assembly throttle switch Rubber handle Handle assembly Shock absorbing grip Handle assembly Fork shaft oil seal Gearbox Oil plug Gearbox ,walking box, tilling box parts Engine wearing parts Refer to the engine manual... -
Page 23: List Of Attachments
11. List of Attachments Number Part Unit Usage Remark 350*100 walking wheel Walking/transport Standard 4 pieces, 2 sets of tines Tilling Resistance rod piece Tilling depth adjustment Tool kit Maintenance Metal Wheel Kit Add traction to cultivator Optional... -
Page 24: Parts List
12. Parts List Wearing Parts Ref No. Material Code Description 1900200006-0001 Carburetor Gasket 1900100009-0001 Intake Manifold Gasket 1901000005-0001 Air Filter Gasket 1906100004-0001 Exhaust Manifold Gasket 1202000009-0001 Cylinder Head Gasket 1101400006-0001 Crankcase Gasket 2000100338-0001 Starter Assembly 2204700003-0001 Spark Plug 1807900112-0001 Carburetor Assembly 1815000001-0001 Fuel Line Clamp 2001900003-0002... - Page 25 Transmission Box Components 25 26 27 28 30 31 36 37 51 50 Ref No. Material Code Description 360720013 Deep Groove Ball Bearing 6007 2101400011-0001 Clutch Cover Assembly 360220040 Hexagonal Flange Face Bolts Small Series M8*20 360890004 External Tooth Lock Washer 360640005 Large Washer 8 360720019...
- Page 26 Ref No. Material Code Description 3409000007-0001 Oil Plug 40*6 360910021 Elastic Lock Washer For Holes 40 360720025 Deep Groove Ball Bearing 6203 2805300008-0001 Bracing Piece 360970002 Steel Ball 6.35 3404800005-0001 Gear Spring 2115100005-0001 Ⅲ Axis 3408800004-0001 Non-Standard Oil Seal 12*18*4 2103600003-0001 Cultivation Box Fork Shaft 2103100002-0001...
- Page 27 Ref No. Material Code Description 360710051 O-Ring 9.5*2.65 361020079 Pin 6*25 2102400011-0001 Clutch Fork Shafts 360010003 Hexagonal Nut M8 360620008 Spring Washers 8 3005300006-0001 Clutch Cable Movable Seat 2139200002-0001 2-Axis Active Gear 2119800007-0001 Gearshift Teeth 2114900005-0001 Ii Axis 2115000004-0001 Ⅰaxis 2155800001-0001 Drive Gear Assembly...
- Page 28 Walking Gear Box Components Ref No. Material Code Description 3408800017-0001 Non-Standard Oil Seal 25*52*9.5 360910011 Circlips For Holes 52 360720036 Deep Groove Ball Bearing 6205 2113600032-0001 Output Shaft 3410800196-0001 Bushing 25.5×32×11.5 2119600005-0001 Output Shaft Gear 3410800195-0001 Bushing 25.5×32×15.5 360290001 Hexagon Flange Bolts Fine Thread Small Series M10*1.25*12 3400100006-0001 Non-Standard Gasket 10*16*2 2124500029-0001...
- Page 29 Cultivation Box Components Ref No. Material Code Description 360920064 Shaft Circlip 20 2110100009-0001 Driven Bevel Gear 3410800210-0001 Bushing 20.2*25*17 360750007 Tapered Roller Bearing 32004 2141200013-0001 Transmission Shaft 2124100005-0001 Gearbox Back Cover 3400500004-0001 Back Cover Gasket 2144100006-0001 Transmission Standpipe 360250024 Hexagon Head Bolt Full Thread M8*20 360620008 Spring Washer 8 360660013...
- Page 30 Transmission Assembly Components Ref No. Material Code Description 360040009 Type 2 Hexagon Flange Nut M8 Walking Box Parts Transmission Parts Cultivation Box Parts 360660013 Flat Washer Class A 10 360620015 Standard Spring Washer 10 360010008 Type 1 Hex Nut M10 360220164 Hexagon Flange Bolts Small Series M8*30 2409500007-0001...
- Page 31 Engine Components Ref No. Material Code Description 360040009 Type 2 Hexagon Flange Nut M8 2602900070-0001 Bumper 360220043 Hexagon Flange Bolts Small Series M8*40 360220067 Hexagon Flange Bolts Small Series M8*35 T010330416 Engine 3401100011-0001 Power And Flange Gaskets 2109300030-0001 Flange 3401600001-0001 Flange Paper Pad 361280002 Hex Socket Head Cap Screw and Spring Washer Assembly M8*30...
- Page 32 Tines Assembly Ref No. Material Code Description 360220041 Type 1 Hex Nut M10 2700200016-0001 Rotary Tiller Blade 360620008 Standard Type Spring Washer 8 360040009 Hex Flange Nut M8 2706600047-0001 Cutter Drum Assembly...
- Page 33 Tine Shield Ref No. Material Code Description 360220040 Hexagon Flange Bolts Small Series M8*20 2605300018-0001 Mudguard Bracket 2605000010-0001 Side Mudguard Right 360120009 Type 1 Non-Metallic Insert Hexagonal Locking Nut M8 2601600189-0001 Mudguard 360120005 Type 1 Non-Metallic Insert Hex Lock Nut M6 3409300001-0001 Hinge 2602500008-0002...
- Page 34 Handrail Control Components Ref No. Material Code Description 360040008 Type 2 Hex Flange Nut M6 2408400007-0002 Front Cover Bracket 2603900002-0001 Transmission Case Cover 360300007 Hex Flange Bolt, Enlarged Series B Grade M6*16 360560004 Cotter Pin 1.6*20 3010900006-0001 Output Clutch Handle 361020048 Pin Shaft 5×25 360560027...
- Page 35 3017400008-0001 Plug 1704900011-0001 Control Lever 3009200095-0001 Clutch Pull Rope 360120013 Type 1 Non-Metallic Insert Hex Lock Nut M10 2131600001-0001 Anti-Loose Bracket Assembly 360650011 Large Washer C Grade 10 360260090 Hex Head Bolt M10*70 3000200002-0001 Throttle Pull Rope 3008800002-0001 Handle Frame Adjustment Assembly 2400600001-0001 Self-Locking Clamp 2410700004-0001...
- Page 36 Walking Parts Ref No. Material Code Description 361020029 Pin Shaft 8*43 2803200143-0001 Right Walking Wheel Assembly 3402200004-0002 Circlip B 2803200144-0001 Left Walking Wheel Assembly...
-
Page 37: Warranty
Novus Performance Products LLC certifies that Novus Products are fit for ordinary purposes for which a product of this type is used. Novus Performance Products LLC however, limits the implied warranties of merchantability and fitness in duration to a period of two (2) years in consumer use, ninety (90) days for any other use.
