Summary of Contents for Novus NVT516
-
Page 3: Table Of Contents
IM PO R T A N T S A FE T Y IN ST R U CT IO N S footwear that will protect your feet and improve your footing on TABLE OF CONTENTS WARNING! slippery surfaces. When using electric gardening appliances,basic safety ■Do not overreach-Keep firm footing and balance. -
Page 4: Important Safety Instructions
IMPO R T A N T S A FE T Y IN S T R U CT IO N S IMPO R T A N T S A FE T Y IN S T R U CT IO N S ■If the tiller starts to vibrate abnormally or become ■This product is only used with WMBP55 lithium battery pack/ ■Do not use water to clean battery packs and chargers... -
Page 5: Labels
LABELS LABELS Logo on battery pack and charger The following signal words and meanings are intended to explain the levels of risk associated with this product. LABEL SIGNA MEANING LABEL DESIGNATION/EXPLANATION DANGER Indicates a hazardous situation,which,if not avoided,will result in death or serious injury. Warning! Improper or careless use of chargers or batteries can be very dangerous and can WARNING Indicates a hazardous situation,which,if not avoided,could result in death or serious injury. -
Page 6: Personal Injury
FE A T U R E S ASSEMBLY PRODUCT SPECIFICATIONS UNPACKING ■Position the upper handle. Motor……………………………………………………58V DC Depth Capacity…………………………………………...8 inch This product requires assembly. ■Slide the upper handle into the lower handle. Number of Tines ……………………………………….……24 Speed……….……….……….………..…..137/205min(RPM) Carefully remove the product and any accessories from the ... -
Page 7: Always Wear Eye Protection With Side Shields Marked To Comply
For complete charging instructions,refer to the Operator's injury. Manual for your NOVUS battery pack and charger models. WARNING: WARNING: To avoid accidental starting, which could result in Do not use any attachments or accessories not serious personal injury, always remove the start key and recommended by the manufacturer of this product. - Page 8 OPERATION OPERATION Fig.10 Fig.12 To dig more deeply,continuously pull the tiller towards you To change to a narrow tine pattern: ■Remove the shear pins securing the outer tines from each and let it pull itself forward. If the machine remains stationary and digs in one spot, gently side of the tiller.
-
Page 9: Maintenance
MAINTENANCE BATTERY PACK OPERATION AND MAINTENANCE the charger cannot charge the battery pack. In this case, the CHECK BATTERY LUBRICATIO WARNING: charger charges after the battery cools down. ■The LED indicator light on the battery pack can display All moving parts within this product are lubricated with To avoid serious personal injury, always remove the the power of the battery pack and the abnormal state of LED light... -
Page 10: Charger Operation And Maintenance
When shipped, the battery pack is only allowed to have ■Unplug the power cord. Do not jerk the power cord out of a 30% charge. The Novus battery pack is only allowed to the socket. be charged with a suitable Novus charger. When charging ■... - Page 11 Transmission Components Ref No Material Code Description Non-Metallic Insert Hex Lock Nut M6 360120008 Adjustment Footplate 2424700002-0002 Adjustment Rod 3008900008-0001 Compression Spring Φ0.8×Φ9.7×36 2448600016-0001 Flat Washer 8 360660022 Open Retaining Ring 7 360940017 Hexagonal Flange Head Bolt M6×12 360300200 Tine Shield 2601600213-0001 Connecting Plate 2407000006-0001...
- Page 12 Battery Compartment Parts Ref No Material Code Description 3419100001-0002 Non-Standard Phillips Pan Head Self-Tapping Screw 4×16 2615100005-0001 Battery Pack Socket Press Plate 2209600007-0001 Battery Connector Wire 2611900005-0001 Battery Pack Socket 3415900008-0001 Compression Spring 2219100001-0001 Spring Cap 2218500002-0001 Battery Compartment 2220000001-0001 Safety Lock Connector Wire 2219000001-0001 Safety Lock Socket Bottom...
- Page 13 Exterior Parts Ref No Material Code Description 2215800012-0001 Lithium Battery Pack Assembly 3419100001-0002 Non-Standard Phillips Pan Head Self-Tapping Screw 4×16 Battery Compartment Parts 360450030 Phillips Pan Head Self-Tapping Screw 4.2×12 2218600002-0002 Battery Compartment Cover 2448600001-0001 Compression Spring 3411200016-0001 Positioning Pin 6×16 2608100004-0001 Upper Protective Cover 2412200008-0001...
- Page 14 Operation Parts Ref No Material Code Description 2213800002-0001 Insulation Piece 3008000003-0002 Armrest Locking Handle 2402400009-0001 Armrest Frame Connecting Pipe 3417100002-0001 Arc Washer 8 3402800002-0001 Armrest Locking Bolt M8×50 2466400002-0001 Upper Armrest Frame 1706100001-0003 Start Pull Rod 3000500027-0001 Shock-Absorbing Grip 2400600002-0001 Self-Locking Clamp 2220100002-0001 Switch Bus...
- Page 15 Walking Parts Ref No Material Code Description 360040013 Hexagonal Flange Nut M8 361020100 Pin Shaft 8×35 360220017 Hexagonal Flange Bolt M8×16 3410600033-0001 Clamp 3402200004-0001 Circlip B 2809500003-0001 Wheel Hub Cap 360920075 Shaft Retaining Ring 9 360650012 Large Washer 10 2803100017-0002 Travel Wheel 2401300027-0001 Resistance Rod...
- Page 16 Tillage Parts Ref No Material Code Description 361020100 Pin shaft 8×35 2718400001-0001 Secondary tillage blade assembly 3402200004-0001 Circlip B 2702500012-0001 Main tillage blade assembly -21-...
-
Page 17: Warranty
2-Year Limited Warranty Terms and Conditions Novus products are warranted for two (2) years against defects in materials or workmanship when put to ordinary and normal consumer use; ninety (90) days for any other use. For the purposes of all the above warranties, “ordinary and normal consumer use” refers to non-commercial residential use and does not include misuse, accidents or damage due to inadequate maintenance.
