SIMATIC NET
Industrial Ethernet switches
SCALANCE XP-200G
Operating Instructions
08/2024
C79000-G8976-C686-02
Introduction
Safety notices
Security recommendations
Description of the device
Mounting and removal
Connecting up
Upkeep and maintenance
Technical specifications
Dimension drawings
Approvals
1
2
3
4
5
6
7
8
9
A

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIMATIC NET SCALANCE XP-200G and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SIMATIC NET SCALANCE XP-200G

Summary of Contents for Siemens SIMATIC NET SCALANCE XP-200G

  • Page 1 Introduction Safety notices Security recommendations SIMATIC NET Description of the device Industrial Ethernet switches SCALANCE XP-200G Mounting and removal Connecting up Operating Instructions Upkeep and maintenance Technical specifications Dimension drawings Approvals 08/2024 C79000-G8976-C686-02...

  • Page 2: Qualified Personnel

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Table of contents Introduction ............................5 Safety notices ............................11 Security recommendations........................13 Description of the device ........................21 Product overview ....................... 21 Device views ........................24 4.2.1 SCALANCE XP208 and SCALANCE XP208EEC ..............24 4.2.2 SCALANCE XP208G and SCALANCE XP208G EEC ..............26 4.2.3 SCALANCE XP208PoE EEC ....................
  • Page 4 Table of contents 5.6.1 Wall or rack mounting......................54 5.6.2 Mount a SCALANCE XP208 on the SCALANCE PSP9230PoE ..........56 5.6.3 Mount a SCALANCE XP216 on the SCALANCE PSP9230PoE ..........57 Disassembly........................58 Connecting up ............................. 59 Safety when connecting up....................59 Industrial Ethernet ......................

  • Page 5: Introduction

    Introduction Purpose of the Operating Instructions These operating instructions will help you to install and connect devices of the SCALANCE XP-200G product group. The configuration and the integration of the devices in a network are not described in these operating instructions. Validity of the Operating Instructions These operating instructions apply to the following devices: •...

  • Page 6: Further Documentation

    You will find the configuration manuals here: • on the data medium that ships with some products: – Product CD / product DVD – SIMATIC NET Manual Collection • On the Internet pages of Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/21869/man). Further documentation In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet"...
  • Page 7 Catalogs You will find the article numbers for the Siemens products of relevance here in the following catalogs: • SIMATIC NET Industrial Communication / Industrial Identification, catalog IK PI •...
  • Page 8 Introduction You can request the catalogs and additional information from your Siemens representative. Device defective If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are not possible. Decommissioning Shut down the device properly to prevent unauthorized persons from accessing confidential data in the device memory.

  • Page 9: Electrostatic Discharge

    Introduction Electrostatic discharge NOTICE Electrostatic sensitive devices (ESD) Electronic modules contain electrostatic sensitive components These components can easily be destroyed if handled incorrectly. Note the following instructions to avoid damage. • Touch electronic modules only when you absolutely need to work on them. •...
  • Page 10 Introduction SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 11: Safety Notices

    Safety notices Read the safety notices Note the following safety notices. These relate to the entire working life of the device. You should also read the safety notices relating to handling in the individual sections, particularly in the sections "Installation" and "Connecting up". CAUTION To prevent injury and damage, read the manual before using the device.
  • Page 12 Safety notices SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 13: Security Recommendations

    OpenVPN). • Separate connections correctly (WBM, SSH etc.). • Check the user documentation of other Siemens products that are used together with the device for additional security recommendations. • Using remote logging, ensure that the system protocols are forwarded to a central logging server.
  • Page 14 Industrial Security (https://www.siemens.com/ industrialsecurity) website. • Inform yourself regularly about security recommendations published by Siemens ProductCERT (https://www.siemens.com/cert/en/cert-security-advisories.htm). • Only activate protocols that you require to use the device. • Restrict access to the management of the device with rules in an access control list (ACL).

  • Page 15: Certificates And Keys

    Security recommendations Certificates and keys • The devices SCALANCE XF204G, SCALANCE XB206-2 as of firmware version V4.4 or SCALANCE XP-200G, SCALANCE XP-200G PP as of firmware version V4.5 use certificates for elliptic curve cryptography ("ECDSA certificates"). Only use ECDSA certificates in PEM format that were generated with the following curves: –...
  • Page 16 Security recommendations Secure/non-secure protocols and services • Avoid or disable non-secure protocols and services, for example HTTP, Telnet and TFTP. For historical reasons, these protocols are available, however not intended for secure applications. Use non-secure protocols on the device with caution. •...

  • Page 17: Available Protocols

    Security recommendations Interfaces security • Disable unused interfaces. • Use IEEE 802.1X for interface authentication. • Use the function "Locked Ports" to block interfaces for unknown nodes. • Use the configuration options of the interfaces, e.g. the "Edge Type". • Configure the receive ports so that they discard all untagged frames ("Tagged Frames Only"). Available protocols The following list provides you with an overview of the open protocol ports.
  • Page 18 Security recommendations The table includes the following columns: • Service The services that the device supports • Default port status This is the status of the port in the delivery state (factory setting). • Configurable port/service Indicates whether the port number or the service can be configured via WBM / CLI. •...
  • Page 19 Security recommendations Service Protocol / Port Default port Configurable Authentication Encryption number status Port Service Syslog (secure) Client TCP/6514 Closed ✓ ✓ ✓ Telnet TCP/23 Closed ✓ ✓ ✓ TFTP Client UDP/69 Outbound only ✓ ✓ 1) Port number can be configured via the WBM. 2) Read-only access only.
  • Page 20 Security recommendations SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 21: Description Of The Device

    Description of the device Product overview Article numbers Device Description Article number (PROFINET) SCALANCE XP208 6GK5 208-0HA10-2AS6 • 2 x 10/100/1000 Mbps, M12 connector technolo‐ gy electrical • 6 x 10/100 Mbps M12 connector technology elec‐ trical SCALANCE XP208G 6GK5 208-0XA00-2AS6 •...

  • Page 22: Ring Ports

    Description of the device 4.1 Product overview • IGMP Snooping/IGMP Querier: Off • IPv4 Address Collision Detection: Never give up Ring ports With PROFINET variants for which the ring redundancy redundancy method is set, the factory setting defines the following ring ports: •...

  • Page 23: Unpacking And Checking

    Description of the device 4.1 Product overview Unpacking and checking WARNING Do not use any parts that show evidence of damage If you use damaged parts, there is no guarantee that the device will function according to the specification. If you use damaged parts, this can lead to the following problems: •...

  • Page 24: Device Views

    Description of the device 4.2 Device views Device views 4.2.1 SCALANCE XP208 and SCALANCE XP208EEC The following figure shows an overview of the components of the SCALANCE XP208 and SCALANCE XP208EEC. ① Cutout for hexagonal nuts ② Keyhole hang-up mechanism ③ a Ethernet ports for Gigabit Ethernet (P1 - P2) b Ethernet ports for Fast Ethernet (P3 - P8) ④...
  • Page 25 Description of the device 4.2 Device views ⑩ LED display ⑪ Cover for: • C-PLUG slot • "RESET" button SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 26: Scalance Xp208G And Scalance Xp208G Eec

    Description of the device 4.2 Device views 4.2.2 SCALANCE XP208G and SCALANCE XP208G EEC The following figure shows an overview of the components of the SCALANCE XP208G and SCALANCE XP208G EEC. ① Cutout for hexagonal nuts ② Keyhole hang-up mechanism ③ Ethernet ports for Gigabit Ethernet ④...

  • Page 27: Scalance Xp208Poe Eec

    Description of the device 4.2 Device views 4.2.3 SCALANCE XP208PoE EEC The following figure shows an overview of the components of the SCALANCE XP208PoE EEC ① Cutout for hexagonal nuts ② Keyhole hang-up mechanism ③ a Ethernet ports for Gigabit Ethernet and PoE+ (P1 - P2) (max. 30 W) b Ethernet ports for Fast Ethernet and PoE+ (P3 - P8) (max.

  • Page 28: Scalance Xp208G Poe Eec

    Description of the device 4.2 Device views 4.2.4 SCALANCE XP208G PoE EEC The following figure shows an overview of the components of the SCALANCE XP208G PoE EEC. ① Cutout for hexagonal nuts ② Keyhole hang-up mechanism ③ Ethernet ports for Gigabit Ethernet and PoE+ (max. 30 W) ④...

  • Page 29: Accessories

    Description of the device 4.3 Accessories Accessories The following accessories are available for the devices mentioned in the scope of validity: C-PLUG Component Description Article number C-PLUG Configuration plug, exchangeable storage medium for 6GK1 900-0AB00 configuration data, 32 MB Configuration plug, exchangeable storage medium for 6GK1 900-0AQ00 configuration data, 32 MB, varnished (conformal coating) M12 data plug-in connector...
  • Page 30 Description of the device 4.3 Accessories Component Description Article number IE FC TP ROBUST STANDARD CA‐ Standard bus cable, ATPE outer jack‐ 6XV1 841-2A BLE GP 2X2 et for connection to FC RJ45 PLUG and FC OUTLET RJ45, fixed installa‐ (PROFINET type A) tion, for universal use, 4-wire, shiel‐...
  • Page 31 Description of the device 4.3 Accessories Cabinet feedthrough Component Description Article number IE M12 PANEL FEED‐ Cabinet feedthrough for conversion from 6GK1 901-0DM20-2AA5 THROUGH M12 connector technology (D-coded, IP65) to RJ-45 connector technology (IP20) pack of 5 IE M12 PANEL FEED‐ Cabinet feedthrough for conversion from 6GK1 901-0DM30-2AA5 THROUGH PRO...
  • Page 32 Description of the device 4.3 Accessories Energy cable Component Description Article number Energy Cable 2 x 0.75 Energy cable for connection of signaling 6XV1 812-8A contact, 2-wire, stranded 2 x 0.75 mm trailable, not assembled Sold by the meter Energy Cable 4 x 1.5 4-wire energy cable, stranded 4 x 6XV1 801-2B 1.5 mm...

  • Page 33: Spare Parts

    Description of the device 4.4 Spare parts Component Description Article number Rack wide Length: 500 mm (ready for installation) 6ES7 194-4GB00-0AA0 Pack of 1 Length: 1000 mm (ready for installation) 6ES7 194-4GB60-0AA0 Pack of 1 Length: 2000 mm, 6ES7 194-4GB20-0AA0 Pack of 1 Rack compact narrow Length: 500 mm (ready for installation) 6ES7 194-4GC70-0AA0...

  • Page 34: Led Display

    Description of the device 4.5 LED display LED display 4.5.1 Overview The following figure shows the arrangement of the LEDs. LED for displaying the fault/error status LED for displaying the "redundancy manager" function LED for displaying the "standby" function DM1/DM2 LEDs for displaying the display mode L1/L2 LEDs for displaying the power supply LEDs for displaying the port status *)

  • Page 35: Sb" Led

    Description of the device 4.5 LED display 4.5.3 "SB" LED The "SB" LED shows the status of the standby function. LED color LED status Meaning The standby function is disabled. Green The standby function is enabled. The standby section is passive. Green Flashing The standby function is enabled.

  • Page 36: Setting The Display Mode

    Description of the device 4.5 LED display Setting the display mode To set the required display mode, press the "SELECT/SET" button. If you do not press the "SELECT/SET" button for longer than 1 minute, the device automatically changes to display mode A. Pressing SELECT/SET button LED status Display mode...

  • Page 37: Port Leds

    Description of the device 4.5 LED display Meaning in display mode D In display mode D, the "L1" and "L2" LEDs indicate whether the power supply is monitored. Table 4-3 Power supply with devices with 24 VDC L1/L2 LED L1/L2 connector  ...
  • Page 38 Description of the device 4.5 LED display Meaning in display mode B In display mode B, the port LEDs indicate the transmission speed. LED color LED status Meaning Port operating at 10 Mbps Green Port operating at 100 Mbps Orange Port operating at 1000 Mbps If there is a connection problem and the type of transmission is fixed (autonegotiation off), the desired status, in other words the set transmission speed (1000 Mbps, 100 Mbps, 10 Mbps) continues to be displayed.

  • Page 39: Reset Button

    Description of the device 4.6 RESET button RESET button Position NOTICE Loss of water and dust protection If the cover is not mounted correctly, the device is not water and dust proof. The "RESET" button is located under the cover on the top of the SCALANCE XP-200. Figure 4-1 Position of the "RESET"...

  • Page 40: Select / Set Button

    Description of the device 4.7 SELECT / SET button Requirement • The device is in operation. • The function "Reset to factory defaults" is enabled for the RESET button. Note Reset despite disabled "RESET button" If you have disabled the "Restore Factory Defaults"function for the "RESET" button in the configuration, this does not apply during the startup phase, see section "Restoring the factory settings (Page 80)"...
  • Page 41 Description of the device 4.7 SELECT / SET button Position The "SELECT/SET" button is located on the front of the SCALANCE XP-200. Figure 4-2 SELECT/SET button Setting the display mode To set the required display mode, press the "SELECT/SET" button. For more detailed information on the display modes, refer to the section "LEDs "DM1" and "DM2"...

  • Page 42: C-Plug

    Description of the device 4.8 C-PLUG C-PLUG 4.8.1 Function of the C-PLUG NOTICE Do not remove or insert a C-PLUG during operation A C-PLUG may only be removed or inserted when the device is turned off. A C-PLUG is an exchangeable storage medium for storing the configuration data of the device.

  • Page 43: Response To Errors

    Description of the device 4.8 C-PLUG If changes are made to the configuration, the device stores the configuration directly on the C-PLUG, if this is in the "ACCEPTED" status and in internal memory. Response to errors Inserting a C-PLUG that does not contain the configuration of a compatible device type and inadvertently removing the C-PLUG, or general malfunctions of the C-PLUG are indicated by the diagnostic mechanisms of the device.
  • Page 44 Description of the device 4.8 C-PLUG Replacing a C-PLUG. Removing a C-PLUG 1. Turn off the power to the device. 2. Loosen the screws of the cover. 3. Remove the cover. 4. Insert a screwdriver between the front edge of the C-PLUG (A) and the slot and release the C- PLUG.

  • Page 45: Power Over Ethernet

    Description of the device 4.9 Power over Ethernet Inserting a C-PLUG 1. Turn off the power to the device. 2. Loosen the screws of the cover. 3. Remove the cover. 4. The housing of the C-PLUG has a protruding ridge on the long side (B). The slot has a groove at this position.

  • Page 46: Poe Properties Of The Devices

    Description of the device 4.9 Power over Ethernet PoE class Power supplied by the pow‐ Available power at the pow‐ Type Standard Designation er source er source 40 W IEEE802.3bt PoE++/ 4-pair PoE 51 W 4.9.2 PoE properties of the devices Note Turn off the power source before you disconnect the PoE cable of a power consumer. Power source •...

  • Page 47: Configuration

    Description of the device 4.9 Power over Ethernet D-coded ports MDI coding is specified for the M12 assignment for the SCALANCE XP-200 product group. This results in the assignment described in the table. In fact, the switch uses automatic detection methods in all settings, which always negotiate automatically and correctly between MDI and MDI-X assignment.
  • Page 48 Description of the device 4.9 Power over Ethernet SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 49: Mounting And Removal

    Mounting and removal Safety notices for installation Safety notices When installing the device, keep to the safety notices listed below. WARNING If a device is operated in an ambient temperature of more than 40 °C, the temperature of the device housing may be higher than 70 °C. The device must therefore be installed so that it is only accessible to service personnel or users that are aware of the reason for restricted access and the required safety measures at an ambient temperature higher than 40 ℃.
  • Page 50 Mounting and removal 5.1 Safety notices for installation WARNING The equipment shall only be used in an area with pollution degree 1 or 2 (see also EN/IEC 60664-1, GB/T 16935.1). WARNING When used in hazardous environments corresponding to Class I, Division 2 or Class I, Zone 2, the device must be installed in a cabinet or a suitable enclosure.

  • Page 51: Additional Notes

    Mounting and removal 5.1 Safety notices for installation WARNING Wall mounting outside of the control cabinet or housing does not fulfill the requirements of the FM approval. WARNING Wall mounting is only permitted if the requirements for the housing, the installation regulations, the clearance and separating regulations for the control cabinets or housings are adhered to.

  • Page 52: Types Of Installation

    Mounting and removal 5.4 Wall mounting Types of installation The following types of installation are permitted for the devices named in the scope of validity: • Wall mounting • Back wall mounting • Rack mounting Wall mounting Note Depending on the mounting surface, use suitable fittings. Note The wall mounting must be capable of supporting at least four times the weight of the device.

  • Page 53: Rack Mounting

    Mounting and removal 5.5 Rack mounting To mount the device screwed from the back on a wall, follow the steps below: 1. Prepare the drill holes for mounting. For the precise dimensions, refer to the section "Dimension drawings (Page 91)". 2. Bring the drill holes and the cutouts for the hexagon nuts together so that they cover the same area.

  • Page 54: Installation With The Scalance Psp9230Poe Power Supply

    Mounting and removal 5.6 Installation with the SCALANCE PSP9230PoE power supply To install the device on a rack, follow the steps below: 1. Screw the device to the rack using the keyhole hang-up mechanisms, see also sections "Dimension drawings (Page 91)" and "Accessories (Page 29)". 2.
  • Page 55 Mounting and removal 5.6 Installation with the SCALANCE PSP9230PoE power supply Use the following mounting hardware: • Wall mounting The type and length of screws depends on the nature of the wall (concrete, masonry, drywall, wood, etc.). If necessary, use suitable dowels. For more detailed information about the spacing of the fastening holes, refer to the following section: "Dimension drawing SCALANCE PSP9230PoE (Page 92)".

  • Page 56: Mount A Scalance Xp208 On The Scalance Psp9230Poe

    Mounting and removal 5.6 Installation with the SCALANCE PSP9230PoE power supply 5.6.2 Mount a SCALANCE XP208 on the SCALANCE PSP9230PoE Mount the SCALANCE XP208 on the SCALANCE PSP9230PoE using four M5 x 20 screws (maximum head diameter 9.5 mm, tightening torque 3 Nm). SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 57: Mount A Scalance Xp216 On The Scalance Psp9230Poe

    Mounting and removal 5.6 Installation with the SCALANCE PSP9230PoE power supply 5.6.3 Mount a SCALANCE XP216 on the SCALANCE PSP9230PoE To mount a SCALANCE XP216 to a SCALANCE PSP9230PoE, follow the steps below: 1. Screw the adapter plates onto the power supply in the position shown (tightening torque 3 Nm).

  • Page 58: Disassembly

    Mounting and removal 5.7 Disassembly Disassembly WARNING Improper disassembly Improper disassembly may result in a risk of explosion in hazardous areas. For proper disassembly, observe the following: • Before starting work, ensure that the electricity is switched off. • Secure remaining connections so that no damage can occur as a result of disassembly if the system is accidentally started up.

  • Page 59: Connecting Up

    Connecting up Safety when connecting up Safety notices When connecting up the device, keep to the safety notices listed below. Note Close unused sockets Close all unused M12 sockets with protective caps (tightening torque at least 0.4 Nm) to achieve the specified type of protection.
  • Page 60 Connecting up 6.1 Safety when connecting up WARNING Unsuitable cables or connectors Risk of explosion in hazardous areas • Only use connectors that meet the requirements of the relevant type of protection. • If necessary, tighten the connector screw connections, device fastening screws, grounding screws, etc.

  • Page 61: Transient Overvoltages

    Connecting up 6.2 Industrial Ethernet Notes for use in hazardous locations according to ATEX, IECEx, UKEX and CCC Ex If you use the device under ATEX, IECEx, UKEX or CCC Ex conditions you must also keep to the following safety instructions in addition to the general safety instructions for protection against explosion: WARNING Transient overvoltages...

  • Page 62: Gigabit Ethernet

    Connecting up 6.2 Industrial Ethernet Pin number Assignment Gigabit Ethernet For connection to Industrial Ethernet at 10/100/1000 Mbps, SCALANCE XP-200 devices have the following M12 interfaces: X-coded, 8-pin, female. These are highlighted in the figure. SCALANCE XP-200G devices only have Ethernet ports for Gigabit Ethernet. Pin number Assignment SCALANCE XP-200G...

  • Page 63: Auto-Negotiation

    Connecting up 6.2 Industrial Ethernet Connecting an Ethernet port 1. Connect the plug and socket. Make sure that they lock in place correctly. 2. Tighten the knurled screw (torque 1 Nm). To allow an orderly cable outlet, you can arrange the angled M12 plug as follows: IE FC M12 PLUG PRO The IE FC M12 Plug PRO has a high degree of protection (IP65/67) and is suitable for connecting to Industrial Ethernet, see the section "Accessories (Page 29)".

  • Page 64: Power Supply

    Connecting up 6.3 24 V power supply Two components connected to a link segment can exchange information about the transfer and can adapt their settings to each other. The mode with the highest possible speed is set. Note • If a port is set permanently to full duplex, the connected partner port must also be set to full duplex.
  • Page 65 Connecting up 6.3 24 V power supply WARNING Incorrect power supply You do not need to fuse the power supply cable if you only use power sources with limited power (LPS/PS2) or power sources according to NEC Class 2 for the power supply of the devices. If the device is connected to a redundant power supply (two separate power supplies), both must meet these requirements.

  • Page 66: 6.3 24 V Power Supply

    Connecting up 6.3 24 V power supply General notices NOTICE Suitable fusing for the power supply cables The current on the terminal may not exceed 5 A. Use a fuse, that protects against currents > 5 A. The fuse must meet the following requirements: •...
  • Page 67 Connecting up 6.3 24 V power supply Position and assignment Figure 6-1 Position of the power supply, for example on the SCALANCE XP208 Connector Pin number Contact Assignment L1 24 V DC 24 V DC Do not connect Ground Do not connect L2 24 V DC 24 V DC Do not connect Ground...

  • Page 68: 54 V Power Supply

    Connecting up 6.4 54 V power supply 54 V power supply Notes on the power supply WARNING Incorrect power supply Never operate the PoE variants of the device with AC voltage or DC voltage higher than 60 V DC. Information on the power supply •...

  • Page 69: Connect The Power Supply Of The Scalance Psp9230Poe

    Connecting up 6.5 Connect the power supply of the SCALANCE PSP9230PoE Connector Pin number Contact Assignment L1 54 V DC 54 V DC Do not connect Ground Do not connect L2 54 V DC 54 V DC Do not connect Ground Do not connect Connecting/disconnecting the power supply NOTICE Turn off the power supply before you insert or remove the plug of the power supply.
  • Page 70 Connecting up 6.5 Connect the power supply of the SCALANCE PSP9230PoE NOTICE No power supply interruption via the connectors The connectors for input and output are not approved for power supply interruption and cannot be used as disconnectors. A suitable disconnector for interrupting the power supply should be provided in the end application.
  • Page 71 Connecting up 6.5 Connect the power supply of the SCALANCE PSP9230PoE OUTPUT INPUT DC54V/4A DC24V/1A MAX. 4 A DC110-250V AC100-240V OVLD ① 54 V DC output Output voltage 54 V DC, M12 socket (L-coded) ② 24 V DC output Output voltage 24 V DC, M12 socket (L-coded) ③...
  • Page 72 Connecting up 6.5 Connect the power supply of the SCALANCE PSP9230PoE 24 V DC output   Pin number Contact Assignment 24 V DC Do not connect Mass Do not connect Do not connect NOTICE Damage to the device due to overvoltage Both the 54 V DC output and the 24 V DC output are designed as L-coded M12 sockets. Ensure assignment to the correct sockets when connecting the voltages.

  • Page 73: Signaling Contact

    Connecting up 6.6 Signaling contact Signaling contact Information on the signaling contact • To connect the signaling contact, the device has an M12 interface: B-coded, 5-pin, male. • The signaling contact is a floating switch that signals error statuses by opening the contact. The signaling contact must be operated within the range of the operating voltage.

  • Page 74: Serial Interface

    Connecting up 6.7 Serial interface Signaling faults • The signaling of errors by the signaling contact is synchronized with the fault LED "F", see section ""F" LED (Page 35)". All errors that the fault LED "F" indicates (freely configurable) are also signaled by the signaling contact.

  • Page 75: Assignment Of The Terminal Block

    Connecting up 6.7 Serial interface Position and assignment Figure 6-4 Position and pin assignment of the serial interface, for example on the SCALANCE XP208 Pin number Assignment Tx (Transmit Data) Rx (Receive Data) internal use only (do not connect) M (Signal Ground) internal use only (do not connect) Assignment of the terminal block The connecting cable listed in the "Accessories"...

  • Page 76: Functional Ground

    Connecting up 6.8 Functional ground Functional ground EMC disturbances are diverted to ground via the functional ground. This ensures the immunity of the data transmission. The functional ground must be connected with low impedance. The connection of the functional ground must be established directly on the mounting plate or the DIN rail terminal. The grounding screw is identified by the following symbol for the functional ground Protective earth/functional ground The connection of the reference potential surface with the protective circuit is normally in the...
  • Page 77 Connecting up 6.8 Functional ground Connecting up functional ground ① Grounding terminal with cable ② Screw (M4 thread) with spring washer and washer Follow the steps below to connect the functional ground: ① ② 1. Put the grounding terminal , and the bolt together as shown in the drawing.
  • Page 78 Connecting up 6.8 Functional ground SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 79: Upkeep And Maintenance

    Do not use solvents. Downloading new firmware using TFTP without WBM and CLI Firmware The firmware is signed and encrypted. This ensures that only firmware created by Siemens can be downloaded to the device. SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 80: Pressing The "Reset" Button

    Upkeep and maintenance 7.2 Restoring the factory settings Pressing the "RESET" button To load new firmware, you require the "RESET" button. When pressing the button, remember the information in the section "RESET button (Page 39)". Procedure with Microsoft Windows You can download new firmware to the device using TFTP. To do this, the device does not need to be reachable either using Web Based Management (WBM) or using the Command Line Interface (CLI).
  • Page 81 Upkeep and maintenance 7.2 Restoring the factory settings NOTICE Inadvertent reset An inadvertent reset can cause disturbances and failures in the configured network with further consequences. With the "RESET" button Restoring the factory settings during the startup phase NOTICE Reset despite disabled "RESET button" Using the "RESET"...

  • Page 82: During Configuration

    Upkeep and maintenance 7.2 Restoring the factory settings With SINEC PNI Follow the steps below to reset the device parameters to the factory settings with SINEC PNI: 1. Select the device whose parameters you want to reset. 2. Click "Reset device". A dialog opens in which you can select one of the following options: –...

  • Page 83: Technical Specifications

    Technical specifications Technical specifications SCALANCE XP208 and SCALANCE XP208EEC The following technical specifications apply to the following devices: • SCALANCE XP208 • SCALANCE XP208EEC Technical specifications Attachment to Industrial Ethernet   Quantity Connector M12 socket Properties D-coded Transmission speed 10 / 100 Mbps  ...

  • Page 84: Technical Specifications Of Scalance Xp208G And Scalance Xp208G Eec

    Technical specifications 8.2 Technical specifications of SCALANCE XP208G and SCALANCE XP208G EEC Technical specifications Design compact Housing material Aluminum Degree of protection IP 65 Dimensions (W x H x D) 200 x 200 x 49 mm (57 mm incl. protective caps) Weight 1800 g Installation options •...

  • Page 85: Technical Specifications Of The Scalance Xp208Poe Eec

    Technical specifications 8.3 Technical specifications of the SCALANCE XP208PoE EEC Technical specifications Fusing   5 A / at least 60 V The connected power supply must meet the requirements of NEC Class 2 or PS2/LPS in compliance with UL 62368-1. Permitted ambient conditions Ambient temperature During operation up to 2000 m -40 °C to +70 °C...

  • Page 86: Technical Specifications Of Scalance Xp208G Poe Eec

    Technical specifications 8.4 Technical specifications of SCALANCE XP208G PoE EEC Technical specifications Electrical data Power supply Rated voltage 54 V DC Voltage range 52 to 57 V DC Safety Extra Low Voltage Design M12 socket, 4-pin Cable cross-section ≥ 1.5 mm (16 AWG) Property Implemented redundantly Current consumption...
  • Page 87 Technical specifications 8.4 Technical specifications of SCALANCE XP208G PoE EEC Technical specifications Serial interface Quantity Connector M12 socket Electrical data Power supply Rated voltage 54 V DC Voltage range 52 to 57 V DC Safety Extra Low Voltage Design M12 socket, 4-pin Cable cross-section ≥...

  • Page 88: Technical Specifications Of The Scalance Psp9230Poe

    Technical specifications 8.5 Technical specifications of the SCALANCE PSP9230PoE Technical specifications of the SCALANCE PSP9230PoE SCALANCE PSP9230PoE     Input voltage Nominal voltage 100 to 240 V AC / 110 to 250 V DC Voltage range 85 to 264 V AC / 88 to 300 V DC Frequency 50 Hz / 60 Hz Frequency range 47 Hz to 63 Hz Design...

  • Page 89: Switching Properties

    Technical specifications 8.6 Switching properties SCALANCE PSP9230PoE     Ambient temperature during operation 100 to 110 V AC / 110 V DC 2 A -40 °C to +70 °C • Use of 54 V DC output (PoE) 3.5 A -40 °C to +60 °C • Any installation position 4 A -40 °C to +55 °C 220 to 240 V AC / 250 V DC 3 A...
  • Page 90 Technical specifications 8.6 Switching properties Full wire speed switching Frame length (bytes) Number of frames per second At 100 Mbps At 1000 Mbps 148810 1488095 84459 844594 45290 452898 23496 234962 1024 11973 119731 1280 9615 96153 1518 8127 81274 Note The number of SCALANCE switches connected in a line influences the entire frame delay.

  • Page 91: Dimension Drawings

    Dimension drawings SCALANCE XP-200G dimension drawings Note Dimensions are specified in mm. Front view of the SCALANCE XP208G Figure 9-1 Width, height and dimensions for wall mounting SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 92: Dimension Drawing Scalance Psp9230Poe

    Dimension drawings 9.2 Dimension drawing SCALANCE PSP9230PoE Side view of the SCALANCE XP-200G Figure 9-2 Depth Dimension drawing SCALANCE PSP9230PoE Note Dimensions are specified in millimeters. SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...
  • Page 93 Dimension drawings 9.2 Dimension drawing SCALANCE PSP9230PoE Front view and side view of the SCALANCE PSP9230PoE SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...
  • Page 94 Dimension drawings 9.2 Dimension drawing SCALANCE PSP9230PoE SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...

  • Page 95: Approvals

    Current approvals on the Internet You will find the current approvals for the product on the Internet pages of Siemens Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/15273/cert). Notes for the manufacturers of machines This product is not a machine in the sense of the EC Machinery Directive or the Supply of Machinery (Safety) Regulations (UK).
  • Page 96 Process Automation DE-76181 Karlsruhe Germany Importer UK: Siemens plc, Manchester M20 2UR You can find the current UK Declaration of Conformity for these products on the Internet pages under Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/15273/cert). SCALANCE XP-200G Operating Instructions, 08/2024, C79000-G8976-C686-02...
  • Page 97 "SIMATIC NET Product Information Use of subassemblies/modules in a Zone 2 Hazardous Area". You will find this document • on the data medium that ships with some devices. • on the Internet pages under Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/view/78381013).
  • Page 98 Approvals EMC (electromagnetic compatibility) The SIMATIC NET products described in these operating instructions meet the electromagnetic compatibility requirements according to the EU Directive 2014/30/EU as well as the UK- Regulation SI 2016/1091 and their associated amendments. Applied standards: • EN 61000‑6‑2 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial environments •...
  • Page 99 Approvals Underwriters Laboratories Inc. complying with • UL 62368-1 (information/communication technology) • CSA C22.2 No. 62368-1 (information/communication technology) • ANSI/ISA 12.12.01 • CSA C22.2 No. 213 Approved for use in Cl. 1, Div. 2, GP A, B, C, D T4 Cl.

  • Page 100: Mechanical Stability (In Operation)

    • "Industrial Ethernet / PROFINET Industrial Ethernet" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/27069465) • "Industrial Ethernet / PROFINET - Passive Network Components" System Manual (https:// support.industry.siemens.com/cs/ww/en/view/84922825) • "EMC Installation Guidelines" configuration manual (https:// support.industry.siemens.com/cs/ww/en/view/60612658)

  • Page 101: Index

    Index Electrical data, 83, 84, 86, 87 Environmental conditions, 83, 85, 86, 87 ESD directives, 9 Accessories, 29 A-coded, 66, 68, 74 Ambient temperature, 83, 85, 86, 87 Approvals, 95 Factory defaults, 39, 80 Article numbers, 21 Factory setting, 39, 80 Attachment to Industrial Ethernet, 83, 84, 85, 86 Fast Ethernet Autonegotiation, 63 Connecting up, 61 Overview, 24, 27, 28...
  • Page 102 Index Cover, 24, 26, 27, 28, 74 Overview, 24, 26, 27, 28 Signaling contact, 35 Connecting up, 73 Keyhole hang-up mechanism Overview, 24, 26, 27, 28 Installation, 54 SIMATIC NET glossary, 6 Overview, 24, 26, 27, 28 SIMATIC NET manual, 6 Spare parts, 33 Startup phase, 35, 40, 81 System manual, 6, 51, 100 LED, 34 Display, 34 Overview, 25, 26, 27, 28, 34...

This manual is also suitable for:

Simatic net scalance xp-200g pp
