- Page 1 USER MANUAL SV 34B ACOUSTIC CALIBRATOR Warsaw, 2024-10-07 Copyright © 2024 SVANTEK. Rev. 1.03 All rights reserved.
-
Page 2: Table Of Contents
SV 34B User Manual Contents Introduction ......................3 1.1. Calibration ....................3 1.2. Accuracy of calibration ................. 3 Acoustic calibrator SV 34B ................... 5 2.1. General description ..................5 2.2. Using the calibrator ..................6 2.2.1. Button functions ..................6 2.2.2. -
Page 3: Introduction
The displayed value of the measured variable will therefore usually differ from the true value of the measured variable. It is recommended that the SV 34B is checked every 2 years with periodic testing of the test equipment to ensure that the level values do not change, and the test results are reliable. - Page 4 SV 34B User Manual Each of the following types (LS, 1 and 2) allows a wider tolerance range (see Table 1). Table 1. Tolerances for these types of acoustic devices, except for the maximum extended measurement uncertainty (f = 1kHz)
-
Page 5: Acoustic Calibrator Sv 34B
2. ACOUSTIC CALIBRATOR SV 34B 2.1. General description The SV 34B Acoustic Calibrator is a small, portable single range Class 2 device (sound source) instrument. The SV 34B is suitable for calibrating Class 2 sound level meters and dosimeters ½”... -
Page 6: Using The Calibrator
2.2. Using the calibrator 2.2.1. Button functions The SV 34B is equipped with a button to control the operation of the calibrator. The button is used to switch the device ON and OFF. In this case, pressing the button has an immediate effect. -
Page 7: Replacing The Batteries
SV 34B User Manual Note: Calibration should only be performed when the '114 dB' LED is lit continuously. The LED called “LOW BAT.” presents the batteries status. When the combined battery voltage is less than 2.1 V the “LOW BAT.” diode will blink with a frequency of approximately 2 Hz. It is recommended to not use the calibrator in this state as the generated level may differ from the declared values. - Page 8 SV 34B User Manual 5. Carefully place the cover so that the diodes fit into the corresponding holes in the cover. 6. Hold the cover with one hand and carefully tighten the fixing screws. 7. Fit the rubber cover.
-
Page 9: 34B Technical Specifications
SV 34B User Manual 3. SV 34B TECHNICAL SPECIFICATIONS Output signal 114 dB, with respect to 20 Pa in reference conditions Sound Pressure Level (SPL): Output frequency 1000 Hz Accuracy: IEC 60942: 2003 standard, Class 2 0.5 dB SPL Accuracy: 0.2 %... - Page 10 SV 34B User Manual EMC properties • The configuration with the highest RF emission in the direction parallel to the axis of the calibrated microphone in the acoustic chamber • The lowest level of noise immunity is parallel to the axis of the calibrated microphone in the acoustic chamber.
