- Page 1 USER MANUAL SV 110 PORTABLE VIBRATION CALIBRATOR Copyright © 2022 SVANTEK. Warsaw, 2022-04-21 Rev. 1.02 All rights reserved.
- Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Svantek. Svantek provides this document “as is”, without warranty of any kind, either expressed or implied, including, but not limited to, its particular purpose. Svantek reserves the right to make improvements and/or changes to this manual, or to the products and/or the programs described in this manual, at any time.
-
Page 3: Table Of Contents
Calibration of the SV 105 Hand-Arm sensor ............... 13 Calibration of the general-purpose accelerometer ............. 15 General Care and Cleaning ......................15 Charging ..........................15 Recalibration of SV 110 ......................16 Technical data ........................18 Declaration of Conformity ..................... 19... -
Page 4: General Safety Summary
SV 110 User Manual 1 General safety summary Review the following safety precautions to avoid injury and prevent from damaging this product or other products connected with it. To avoid potential hazards, use this product only as specified. Qualified personnel should only perform the service procedures. -
Page 5: Accuracy Of Calibration
ISO 8041-1:2017. 4 SV 110 model information • The SV 110 is a hand-held vibration calibrator designed for verification of machine sensors as well as on-site checks of human vibration accelerometers in accordance to ISO 8041-1:2017. -
Page 6: Unpacking And Inspecting The Package Contents
Before the first use of the device, in order to charge the battery completely, connect the charger/power supply plug to the SV 110 USB socket and then connect it to the electrical mains. The complete set includes the following items: •... -
Page 7: Getting Started
SV 110 User Manual 6 Getting started The following figure shows the SV 110 controls and ports: SV 110 vibration calibrator 1-Shaker; 2-Rubber covers; 3-Keyboard; 4-Aluminum casing; 5-Display; 6-USB port; 7-External vibration diodes. -
Page 8: Manual Control Of The Calibrator
SV 110 User Manual Following the requirements of ISO 8041-1:2017, the calibrator’s built-in reference accelerometer measures the cross-axis (transverse) vibrations to detect any interference to the calibration signal. Faults caused by transverse vibrations are indicated by two LEDS on the calibrator’s housing. This unique solution ensures the stability of both the calibration level and the frequency, regardless of the mass of the tested object. -
Page 9: Turning On/Off
(“Shutting down” 3… 2… 1… ) is displayed. Thus, SV 110 gives you time to decide if you really want to turn off the instrument. If you release the key too early, SV 110 returns to the last presented VIEW mode. - Page 10 SV 110 User Manual For 159.2Hz: 1; 2; 3; 4; 5; 6; 7; 8; 9; 10 m/s2; 1; 2; 3; 4; 5; 6; 7; 8; 9; 10 mm/s; 1; 2; 3; 4; 5; 6; 7; 8; 9; 10 µm. Measurement units selection The Units position enables the user to select the measurement units: Linear Metric or Not Metric.
-
Page 11: Performing Calibration
Prepare and install the calibrated sensor according to Chapters 8.1 – 8.3. • • Switch on calibrator by pressing the <Start/Stop> key for a while. In the ready to operate mode SV 110 displays the amplitude and frequency of the shaker •... - Page 12 SV 110 User Manual • X and Y LEDs flashing yellow when the device is stabilising in Z axis direction. When the required level is achieved the LEDs stop flashing. • If X and Y LEDs light red steadily it means that external vibrations’...
-
Page 13: Calibration Of The Sv 105 Hand-Arm Sensor
SV 105 can be calibrated with the use of their dedicated adapters and the calibration description presented in the previous SV 110 User manuals. To perform calibration of the SV 105D Hand-Arm sensor, use the SA 150C belt with the greatest curvature. - Page 14 SV 110 User Manual • Install the calibration adapter with the vibration sensor to the calibrator’s shaker using special stud (included in the SA 105 set): Positioning of the adapter with the sensor for calibration of the X-axis, Y-axis and Z-axis should...
-
Page 15: Calibration Of The General-Purpose Accelerometer
Only the external parts of the device should be cleaned. 10 Charging The SV 110 instrument is equipped with an internal charger, so that the fixed internal batteries can be charged directly from the USB power devices (USP port) or charger/power supply unit. -
Page 16: Recalibration Of Sv 110
SV 110 User Manual Connect SV 110 to a USB port or USB charger. SV 110 will turn on automatically while charging and display the charge level of the instrument's internal battery. SV 110 will display ‘Fully charged’ once charging is complete. Full charging from the charger/power supply should take approximately 5 hours from a fully discharged state. - Page 17 SV 110 User Manual • With the <Level> button, select the Calibration position. • With the <Level> button, select the required frequency of the shaker. • With the <Start/Stop> button, enter the Calibration menu. Press the <Freq.> button (“Change”) and select the new •...
-
Page 18: Technical Data
SV 110 User Manual 12 Technical data Generated reference (calibration) signals Frequency 79,58 159,2 Hz Vibration 1; 2; 3; 4; 5; 6; 7; 8; 9; 10 1; 2; 3; 4; 5; 6; 7; 8; 9; 10 accelerations (RMS) Vibration velocities 2;... -
Page 19: Declaration Of Conformity
SV 110 User Manual 13 Declaration of Conformity...
