Advantech SKY-8260SV2 User Manual

Compact 2u carrier grade, high performance server based on amd epyc 7003/7002 series processors

Hide thumbs

Table Of Contents

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

Table of Contents

Quick Links

Download this manual

SKY-8260SV2

Compact 2U Carrier Grade, High

Performance Server based on AMD

EPYC™ 7003/7002 Series Processors

SKY-8260SV2

Page I

Table of Contents

Need help?

Do you have a question about the SKY-8260SV2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech SKY-8260SV2

Page 4: Copyright And Trademarks
Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights of third parties, which may result from its use.
Page 5: Technical Support And Assistance
If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
Page 6: Warnings, Cautions, And Notes
Please let us know of any aspect of this product, including the manual, which could use improvement or correction. We appreciate your valuable input in helping make our products and documentation better. Please send all such - in writing to: ciot@advantech.com SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved Page VI...
Page 7: Table Of Contents
2.4.11 Internal Storage ..................46 2.4.12 BIOS ......................47 2.4.12.1 Password Protection ............... 47 2.4.12.2 BIOS Defaults ................. 47 2.4.12.3 PCIe Tree ..................47 2.4.13 Advanced Platform Management ............... 47 SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved Page 7...
Page 8 A.6 RJ45 Management Ports ..................95 BIOS POST Code ..............96 Power Supply Specification ..........102 C.1 Redundant 1200W AC PSU ................103 C.2 Redundant 800W DC PSU ................. 105 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 8...
Page 9 Declaration of Conformity ..........107 Warranty and RMA ............109 Glossary ................111 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 9...
Page 10 Figure 1-3: PuTTY Keyboard Settings ................ 22 Figure 1-4: PuTTY Colour Settings ................22 Figure 1-5: BIOS POST Screen .................. 23 Figure 2-1: Carrier Grade Server SKY-8260SV2............28 Figure 2-2: System Dimensions .................. 32 Figure 2-3: Front Panel ....................33 Figure 2-4: Status LEDs (Front Panel) ................
Page 11 Figure A-2: USB Type A Connector ................91 Figure A-3: DisplayPort Connector ................93 Figure A-5: RJ45 10/100/1000Base-T Connector ............94 Figure A-6: RJ45 management port Connector ............95 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 11...
Page 12 Table A-3: USB 2.0 Type A Connector Pin Assignment or Pin Assignment ....91 Table A-4: DisplayPort Connector Pin Assignment ............. 93 Table A-5: RJ45 10/100/1000Base-T Connector Pin Assignment ....... 94 SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved Page 12...
Page 13 Table A-7: RJ45 Management port Connector Pin Assignment ........95 Table B-1: BOIS POST Codes ..................97 Table C-1: 1200W AC Power Supply Specification ........... 103 Table C-2: 800W DC Power Supply Specification ............. 105 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 13...
Page 15: Safety Instructions
Advantech intends to provide all necessary information to install and handle the SKY-8260SV2 in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete. If you need additional information, contact your Advantech representative.
Page 16: Safety Precautions - Static Electricity
16. The sound pressure level at the operator’s position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: The set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
Page 17: Unpacking
Advantech representative. The SKY-8260SV2 is packaged inside a single carton, collectively referred to as the “box” in the remainder of this document. When opening the box, you will find the SKY-8260SV2 embedded in protective foam and the accessory box embedded to the foam.
Page 18: Installation And Configuration
The SKY-8260SV2 comes as a pre-configured system with CPUs, memory and peripherals installed in the unit. In the rare case that you procured a barebone system or need to install components in the SKY-8260SV2 for any other reason, please refer to Section 3.3.
Page 19 Caution! DO NOT add any weight upon the system when chassis slide rail is installed. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 19...
Page 20: Powering On
Inrush current and steady state power specifications for the SKY-8260SV2 can be found at the type label on the bottom of the unit. Connect the power cords to the PSU modules first and then to the power outlets.
Page 21: Figure 1-1: Putty Session Configuration
Figure 1-1: PuTTY Session Configuration Figure 1-2: PuTTY Serial Configuration ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 21...
Page 22: Figure 1-3: Putty Keyboard Settings
Figure 1-3: PuTTY Keyboard Settings Figure 1-4: PuTTY Colour Settings ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 22...
Page 23: Installing An Os
- Install an OS via network boot. - Install an OS image via Advantech remote storage from Advantech BMC Web Interface If you use Advantech’s services to pre-install an OS, you can skip the following section. 1.3.5.1 Pre-Installed reference OS ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co.
Page 24: Installing And/Or Boot An Os From A Usb Key
/ or Linux distribution. Please make sure you configure the network installer image properly for the Ethernet port / device of the SKY-8260SV2 that you plan to use for the installation. 1.3.5.4 Booting an OS via network boot The SKY-8260SV2 supports booting over network via PXE.
Page 25: Table 1-2: Pxe Bios Options
DHCP required for PXE booting may conflict with existing DHCP servers in your network. The PXE client in the SKY-8260SV2 sends the system’s GUID as part of the DHCP Request. Some boot servers have mechanisms to automatically configure the target OS image based on the client system’s GUID.
Page 26: Getting Help: Technical Support And Assistance
1.4 Getting Help: Technical Support and Assistance In case the unit you received is a sample for evaluation, please contact your Advantech representative. For production units, please follow the process below: Visit the Advantech web site at http://www.advantech.com/support to find the latest information about the SKY-8260SV2 and related products.
Page 27: Product Specification
Chapter Product Specification ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 27...
Page 28: Overview
2.1 Overview The SKY-8260SV2 is designed and optimized to meet the high availability and for business-critical use cases. It is equipped with AMD EPYCTM 7003/7002 Series Processor, which not only upgrades the total core counts per each consumed power watt, but also provides a high performance and highly reliable platform for network edge and virtualization applications.
Page 29: Product Versions
2.2 Product Versions The SKY-8260SV2 is available in the following standard configurations. Contact your Advantech representative for availability of other configuration options. Table 2-1: Available Product Versions Model Name Configurations Storage 20” 2U server with single 2x 2.5” AMD EPYC™ 7003/7002...
Page 30: Technical Specifications
6x hot pluggable (6056) fans. (Hot swappable and Chassis Fan N+1 redundant fan modules) Thermal Control Two separate thermal zones for motherboard and Cooling FL PCIe cards Resilient to single fan failure Reliability ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 30...
Page 31 Dimension (W x D x H) 436 x 533 x 87 mm ((17.19" x 20.9" x 3.48") ~18kg Weight (N.W) Physical Lockable front bezel and chassis intrusion sensor Security ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 31...
Page 32: System Dimensions
NOTE! User can select to install two AC 1200W PSU as SKY-8260SV2 AC system, or to install two DC 800W PSU as SKY-8260SV2 DC system 2.3.2 System Dimensions The system dimensions (in mm) are shown below: Figure 2-2: System Dimensions...
Page 33: Detail Description
Table 2-2: Front Elements Power button / ID button / LED Service Tag Bezel Security Lock 2x USB 2.0/3.0 ports and VGA port Fan and storage status LED ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 33...
Page 34: Leds Details
2.4.1.1 LEDs Details The SKY-8260SV2 supports an array of status LEDs and buttons at location A. The LEDs are visible when the front cover is closed as well as when the front cover is open. Figure 2-4: Status LEDs (Front Panel)
Page 35 Green This LED is on in normal mode and will be cleared in case of a failure event in the power subsystem, such as a loss of redundancy. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 35...
Page 36: Front Button Details
Reset Button 2.4.1.3 Fan Module Details The SKY-8260SV2 has six hot swappable fan modules at the front. Each of the fan modules carries high performance fans for optimized air flow, and has an integrated fan status LED to simplify identifying a faulty module during service operation.
Page 37: Storage Led
DO NOT leave the slot empty when extracting the FAN module, the alternative FAN module MUST be inserted immediately. 2.4.1.4 Storage LED SKY-8260SV2 contains two internal storages inside the system on the middle bar (refer to 2.4.11 Internal storage). The status/activity LEDs of the two storages are shown in the front panel.
Page 38: Rear Panel
Or 2x PCIe Gen 4x16 FH/FL + 2x PCIe Gen4 x8 FH/HL slots+2x FH/HL PCIe Gen 4 x8 slots 2x PCIe x8 LP expansion slots Or 1x PCIe x16 LP expansion slot 2x 2.5” NVMe/SATA SSD Trays ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 38...
Page 39: Disk Bay Detail
2.4.2.1 Disk bay detail The SKY-8260SV2 supports two hot swappable 2.5” HDDs/SSDs at the rear. Figure 2-9: Disk Bays Table 2-8: Disk Item Element Description Disk #1 2.5” Disk Tray Disk #2 2.5” Disk Tray Table 2-9: Disk Tray Item...
Page 40: Inside The System
For full height expansion slots PCIe Card Cage 2 PCIe Card Cage For full height expansion slots Carries two internal drive bays Middle bar Cages hosting fan modules Fan Cages ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 40...
Page 41: System Block Diagram
128MB 3200 MHz 155W 7F32 3.7GHz 128MB 3200 MHz 180W 7272 2.9GHz 64MB 3200 MHz 120W 7282 2.8GHz 64MB 3200 MHz 120W 7302 3.0GHz 128MB 3200 MHz 155W ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 41...
Page 42: Processor Feature Details
For more information, please visit AMD website. 2.4.6 Memory A total of 16 DDR4 DIMMs are supported on the SKY-8260SV2. One DIMM socket per DDR4 Channel with total 16 DDR4 Channels supported for one AMD EPYCTM 7002/7003 series processor.
Page 43: Ddr4 Dimm Location And Smbus Mapping
CPU1 / CHF DIMM0 SA[2:0]=010 CPU1 / CHF DIMM1 SA[2:0]=011 CPU1 / CHG DIMM0 SA[2:0]=100 CPU1 / CHG DIMM1 SA[2:0]=101 CPU1 / CHH DIMM0 SA[2:0]=110 CPU1 / CHH DIMM1 SA[2:0]=111 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 43...
Page 44: Validated Memory Modules
DDR4-3200 96D4-8G3200ER-AT DDR4-3200 96D4-16G3200ER-AT DDR4-3200 Please contact you Advantech representative for the most recent list of validated peripherals or if you would like to use modules not listed. Other configurations are available on request. 2.4.7 Network Interface (On board) ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co.
Page 45: Pcie Expansion
The SKY-8260SV2 supports two onboard network ports implemented using Intel i210 and labelled “1” and ”2” at the rear. Ethernet controllers. Connectors are located at Also, the SKY-8260SV2 contains one management port which provides access to the BMC over LAN via NC-SI interfaces. Connectors are located at and labelled as “mgmt”...
Page 46: Tpm
- CPU x8 port may negotiate down to x4 2.4.9 TPM A 2.0 Trusted Platform Module is supported on the SKY-8260SV2. This module is TCG-compliant and has passed Common Criteria EAL4+ certification. 2.4.10 Mass Storage Two M.2 2280 SSDs are supported on the SKY-8260SV2 located at underneath the air duct, beside the memory slots.
Page 47: Bios
2.4.12 BIOS The SKY-8260SV2 BIOS is based on Advantech’s APTIO BIOS and compliant to the UEFI, SMBIOS and ACPI specifications. The BIOS performs probing, initialization and configuration of the SKY-8260SV2 and initializes the OS boot process at the end of POST (Power On Self Test).
Page 48: Hardware And Environmental Monitoring
- Enhanced security (more information available under NDA) For a detailed description of Advanced Platform Management features, the BMC commands and sensor lists please refer to the SKY-8260SV2 BMC User’s Guide. 2.4.13.1 Hardware and Environmental Monitoring BMC monitors all critical voltages on the SKY-8260SV2: - Main system voltages (12V, 5V, 3.3V)
Page 49: Figure 2-16: System Airflow And Fans
The PSU modules have integrated fans which provide for independent cooling of the PSU modules and exhaust air through the rear panel. Figure 2-16: System Airflow and Fans ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 49...
Page 50: Power Supplies
2.4.14 Power Supplies The SKY-8260SV2 supports 1200W redundant AC and 800W redundant DC power supplies. Technical specification for the power supply can be found in Appendix 2.4.14.1 AC PSU Figure 2-17: AC PSU Details Table 2-15: AC PSU Details Item...
Page 51: Dc Psu
2. For 1+1 redundant system power, only ONE PSU is allowed to be extracted at one time. 3. DO NOT leave the slot empty when extracting the PSU, the alternative PSU MUST be inserted immediately for safety purpose. ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 51...
Page 52 2. Disconnect the power cord from equipment. 3. Remove the signal cables from the connectors. 4. Remove the earthed cable from the protective earthed terminal of the equipment. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 52...
Page 53: Advanced Platform Features
2.5 Advanced Platform Features 2.5.1 Intrusion Detection The SKY-8260SV2 supports intrusion detection by default. Removing or lifting the top cover will activate an intrusion detection switch (location IS1). Chassis intrusion will be signaled via an IPMI event by the BMC.
Page 54: Available Accessories And Related Products
2.6 Available Accessories and Related Products 2.6.1 Accessories The following accessories are available for ordering. Please contact your Advantech representative for a list of available and supported peripherals such as memory modules, hard disks and solid state drives. Table 2-17: Accessories...
Page 55: Related Products
EPYC™ 7003/7002 Series CPU SKY-8260SV2AS-A00 socket, redundant AC 1200W PSU , 4x Storage 20” 2U server with single EPYC™ 7003/7002 Series CPU SKY-8260SV2AS-D00 socket, redundant DC 800W PSU , 4x Storage ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 55...
Page 56: Configuration And Service
Chapter Configuration and Service ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 56...
Page 57: Jumper Settings
There are no jumpers on the SKY-8260SV2 intended for customer use. 3.2 BIOS Setup Menu This section describes the SKY-8260SV2’ UEFI BIOS based on AMI’s APTIO BIOS. Users can modify BIOS settings and control the special features of the SKY-8260SV2 using the BIOS setup menu. Note! Please note that Advantech supports shipping the SKY-8260SV2 with custom BIOS defaults to simplify the deployment and integration for our customers.
Page 58: Figure 3-2: Bios Setup Screen Organization
Main Setup screen shown below. Users can always return to the Main setup screen by selecting the Main tab. Figure 3-3: BIOS Setup Main Screen ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 58...
Page 59: Table 3-1: Main Menu
Please note that system time and date are set during manufacturing process according to factory’s local time zone. You may need to update system time to reflect the desired time zone when you receive the unit. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 59...
Page 60: Figure 3-4: Platform Setup: Main Screen
This sub menu allows you to change the settings used for the serial console. For example, users can define the terminal type, bits per second, data bits, parity, stop bits and others. Figure 3-5: Platform Setup: Serial Console Menu ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 60...
Page 61: Table 3-2: Serial Console Menu
Enable or disable extended terminal 100x31 Enabled resolution Legacy OS 80x24 Select Legacy OS Redirection Redirection 80x25 Resolution Resolution Putty KeyPad VT100 Select FunctionKey and KeyPad on LINUX Putty. XTERMR6 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 61...
Page 62: Figure 3-6: Platform Setup: Usb Configuration Menu
Description Options USB Support Disabled Enable or disable USB function Enabled support None If the OS doesn’t support EHCI, XHCI Hand-off Disabled Enabled BIOS will get the control. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 62...
Page 63: Figure 3-7: Platform Setup: Trusted Computing (Tpm2.0)
None Choose TPM operation for next boot. operation TPM Clear Platform Disabled Enable or Disable Platform Hierarchy Enabled Hierarchy. Storage Disabled Enable or Disable Storage Hierarchy Enabled Hierarchy. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 63...
Page 64: Figure 3-8: Platform Setup: Virtualization
This sub menu allows you to change the settings used for Virtualization function. Figure 3-8: Platform Setup: Virtualization Table 3-5: Virtualization Access / Group Setup Item Description Options None SVM Mode Disabled Enable/disable CPU ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 64...
Page 65: Figure 3-9: Platform Setup: Platform Management
POWER CYCLE is needed after Enabled selecting the 'Enable' option. Select 'Auto' Control Auto base on BIOS PCD (PcdAmdSmtMode) default setting. WARNING - S3 is NOT SUPPORTED on systems where SMT is ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 65...
Page 66: Figure 3-10 Hardware Setup
The sub menus are described on the following pages. Figure 3-10 Hardware Setup 3.2.3.1 CPU Configuration This menu supports configuration of the AMD CPU. Figure 3-11 Hardware Setup: CPU Configuration ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 66...
Page 67: Figure 3-12: Hardware Setup: Dimm Configuration
Displays information on the Processor Model Display only information processor installed Microcode Patch L1 Cache L2 Cache L3 Cache 3.2.3.2 Northbridge 3.2.3.2.1 Socket 0 Information Figure 3-12: Hardware Setup: DIMM Configuration ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 67...
Page 68: Figure 3-13: Hardware Setup: Southbridge
Table 3-8: Southbridge Access / Group Setup Item Description Options SATA Configuration Select sub-menu. ACPI Settings Select sub-menu. None Always Off Always On Ac Loss Control Previous No Change ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 68...
Page 69: Figure 3-14: Hardware Setup: Sata Configuration
Figure 3-14: Hardware Setup: SATA Configuration Table 3-9: SATA Configuration Access / Group Setup Item Description Options Disabled Disable or enable OnChip SATA SATA Enable Ensabled controller Auto 3.2.3.3.2 ACPI Settings ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 69...
Page 70: Figure 3-15: Hardware Setup: Acpi Settings
Table 3-11: Runtime Error Logging Access / Group Setup Item Description Options Enabled System error enabling and None System Errors Disabled logging setup option Auto 3.2.3.4 NVMe Configuration ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 70...
Page 71: Figure 3-17: Hardware Setup: Nvme Configuration
Figure 3-17: Hardware Setup: NVMe Configuration 3.2.4 Server Management Setup The Server Mgmt menu supports configuring BMC related features such as OS Watchdog Timer, etc. Figure 3-18: Sever Management Setup ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 71...
Page 72: Table 3-12: Server Management Setup
Disabled Disable the logging of EFI Both Log EFI Status Status Codes or log only Error code Codes error code or only Progress progress code or both code ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 72...
Page 73: Security Setup
Setup. In Setup the User will have Administrator rights. 3. The password length must be in the following range: Minimum length: 3 Maximum length: 20 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 73...
Page 74: Figure 3-20: Post And Boot Menu
Enable/Disable AMI Redfish Enabled Boot Option Priority User Defined Sets the system boot order. CSM Parameters CSM Support Enable the CSM support 3.2.6.2 Compatibility Support Module (CSM) Configuration ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 74...
Page 75: Figure 3-21: Post And Boot Menu: Csm Configuration
Figure 3-21: Post and Boot Menu: CSM Configuration Table 3-14: CSM Configuration Access / Group Setup Item Description Options Enabled Enables or disables the None CSM Support Disabled Compatibility Support Module. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 75...
Page 76: Figure 3-22: Save & Exit Menu
3.2.7 Save & Exit Menu The SKY-8260SV2 BIOS allows users to store BIOS configuration results as “User Defaults.” Users can select “Save as User Defaults” to record all changes which had been made in previous pages as the default setting for further use.
Page 77 Options options. This option allows you to override the Boot UEFI: < boot specified boot order and use a different Override device> boot device for the next boot. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 77...
Page 78: Installing Components
CAUTION: TO DISCONNECT POWER, REMOVE ALL POWER CORDS FROM UNITS. ATTENTION: DÉBRANCHER TOUS LES CORDONS D’ALIMENTATION POUR DÉCONNECTER L’UNITÉ DU SECTEUR. 警告: 電源を切るには、ユニットから電源コードをすべてつとも抜いてください。当心: 如要切断电源, 请将所有电源线都从机器上拔掉。注意: 若要切斷電源, 請將所有電源線都從機器上拔除。 ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 78...
Page 79: Reinstalling The Top Cover
Figure 3-33: PCIe Card Cage Assembly: PCIe slot latch Now, insert the card(s) and make sure the card(s) align with the IO opening as well as the PCIe connector during installation. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 79...
Page 80: 5Disk Installation
Pull up rear side HDD module vertically. Figure 3-37: Rear side HDD module Remove eight M3 screws on the left and right side. Figure 3-38: Removing HDD screws ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 80...
Page 81: Ssd
Insert the M.2 SSD with an angle of approximate 33° in the slot. Press the M.2 SSD downwards. Install and fasten the fixing screw. Reinstall the airduct, the PCIe card cage and CG2, middle bar and top cover. Figure 3-34: M.2 SSD Installation ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 81...
Page 82: Memory Installation
Figure 3-36: DIMM Key Alignment Insert the DIMM from the top using the guide rails on the left and right of the DIMM sockets. Figure 3-37: DIMM Insertion into Slide Rails ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 82...
Page 83: Figure 3-38: Seating The Dimm In The Socket
DIMM evenly until the white latches fully close with a click. Figure 3-38: Seating the DIMM in the Socket In case you want to install another DIMM, repeat steps 1 to 5 accordingly. ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 83...
Page 84: Cpu Installation
3.3.7 CPU Installation The SKY-8260SV2 normally ships as a pre-configured system with CPUs and memory installed. Installing CPUs requires trained personal, special tools and a full production environment. In the unlikely case that you need to install CPUs by yourself, please contact your Advantech representative as product warranty may be impacted.
Page 85: Firmware Upgrades
3.4 Firmware Upgrades Advanced Platform Management allows users to update the SKY-8260SV2 firmware via the BMC’s system or LAN interfaces using the HPM.1 protocol and related definitions. Firmware components supported include the BMC firmware itself as well as the system BIOS.
Page 86: Psu Modules
Connect the power cord. The PSU module should start operation and the PSU Status LED should turn green ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 86...
Page 87: Dimms
Pull the DIMM module out vertically. Figure 3-41: Unlocking and Removing a DIMM To insert a new DIMM, please follow the process described in Section 3.3.5 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 87...
Page 88: Tips, Tricks And Troubleshooting
Chapter Tips, Tricks and Troubleshooting ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 88...
Page 89: Connector Pinout And Led Information
Appendix Connector Pinout and LED Information ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 89...
Page 90: Console Port
A.1 Console Port SKY-8260SV2 uses RJ45 connector for the console port at rear I/O panel. Figure A-1: RJ45 Console Connector Table A-1: Console Connector Pin Assignment Pin No. Signal Name Description Request To Send Data Terminal Ready Transmitted Data Digital Circuit Ground...
Page 91: Usb 3.0/2.0 Type A Connectors
A.2 USB 3.0/2.0 Type A Connectors SKY-8260SV2 provides two USB 3.0 connectors at real I/O panel and one at the front panel. And one USB 2.0 connector at the front panel. USB3.0 USB2.0 Figure A-2: USB Type A Connector Table A-2: USB 3.0 Type A Connector Pin Assignment or Pin Assignment Pin No.
Page 92 USB Power (5V, 900mA, Fused) Power USB 2.0 Differential Pair Signals Digital Circuit Ground No connection No connection GND_DRAIN Digital Circuit Ground for Signal Return No connection No connection ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 92...
Page 93: Vga Connector
Green video Blue Blue video No Connection Ground Ground Ground Ground Power +5V DC Ground No Connection DDC_Data I²C data HSYNC Horizontal sync VSYNC Vertical sync DDC_CLK I²C clock ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 93...
Page 94: Rj45 10/100/1000Base-T Ports
A.5 RJ45 10/100/1000BASE-T Ports SKY-8260SV2 has two 10/100/1000BASE-T RJ45 ports, these connectors can be found at rear panel. Speed Link/Active Figure A-5: RJ45 10/100/1000Base-T Connector A.5.1 Connector Pinout Table A-5: RJ45 10/100/1000Base-T Connector Pin Assignment Pin No. Signal Name Description...
Page 95: Rj45 Management Ports
A.6 RJ45 Management Ports SKY-8260SV2 has one management port art ther rear I/O panel. Figure A-6: RJ45 management port Connector Table A-7: RJ45 Management port Connector Pin Assignment Pin No. Signal Name Description Media Dependent Interface [0]+ MDI[0]+ Media Dependent Interface [0]-...
Page 96: Bios Post Code
Appendix BIOS POST Code ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 96...
Page 97: Table B-1: Bois Post Codes
Memory initialization. Programming memory timing information 0x2E Memory initialization. Configuring memory 0x2F Memory initialization (other). 0x30 Reserved for ASL (see ASL Status Codes section below) 0x31 Memory Installed ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 97...
Page 98 CPU DXE initialization (CPU module specific) 0x66 CPU DXE initialization (CPU module specific) 0x67 CPU DXE initialization (CPU module specific) 0x68 PCI host bridge initialization 0x69 North Bridge DXE initialization is started ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 98...
Page 99 Reserved for future AMI codes 0xA0 IDE initialization is started 0xA1 IDE Reset 0xA2 IDE Detect 0xA3 IDE Enable 0xA4 SCSI initialization is started 0xA5 SCSI Reset 0xA6 SCSI Detect ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 99...
Page 100 0xE4-0xE7 Reserved for future AMI progress codes 0xE8 S3 Resume Failed 0xE9 S3 Resume PPI not Found 0xEA S3 Resume Boot Script Error 0xEB S3 OS Wake Error ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 100...
Page 101 Reserved for future AMI progress codes 0xF8 Recovery PPI is not available 0xF9 Recovery capsule is not found 0xFA Invalid recovery capsule 0xFB – 0xFF Reserved for future AMI error codes ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 101...
Page 102: Power Supply Specification
Appendix Power Supply Specification ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 102...
Page 103: Redundant 1200W Ac Psu
The SKY-8260SV2 is available with different power supply options. The specifications for the available power supplies on the standard product SKUs are listed below. Please consult your Advantech representative reg. other power supply options. C.1 Redundant 1200W AC PSU Table C-1: 1200W AC Power Supply Specification...
Page 104 GB 9254 2008 (EMC) Certification (China) GB 17625.1 – (Harmonics) CNCA Certification (China) Input Brown Out Input Surge Input Transient Protection Output Over voltage Output Over current & Short circuit Thermal Fan failure ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 104...
Page 105: Redundant 800W Dc Psu
Operatio n: 0.01g²/Hz at 5 Hz sloping to 0.02g²/Hz at 20 Hz, and maintaining 0.02g²/Hz from 20 Hz to 500 Hz. Non-Operation : 5Hz to 500Hz @ 0.5gRMS at 0.5 octave/min ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 105...
Page 106 GB 9254 2008 (EMC) Certification (China) GB 17625.1 – (Harmonics) CNCA Certification (China) Input Brown Out Input Surge Input Transient Protection Output Over voltage Output Over current & Short circuit Thermal Fan failure ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 106...
Page 107 Appendix Declaration of Conformity ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 107...
Page 108 The SKY-8260SV2 has been successfully tested for compliance to the regulations below. Should you need a signed copy of the declaration of conformity or the related test reports, please contact your Advantech representative. This product has passed the CE test for environmental specifications when shielded cables are used for external wiring.
Page 109 Appendix Warranty and RMA ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 109...
Page 110 Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.
Page 112 Power Supply Unit Pre-boot Execution Environment QuickAssist Technology QuickPath Interconnect RASUM Reliability, Availability, Serviceability, Usability, Maintainability RDIMM Registered DIMM RMCP Remote Management Control Protocol Receive Serial Attached SCSI ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 112...
Page 113 Small Computer System Interface Sensor Data Record SerDes Serializer/Deserializer Serial Over LAN Solid State Disk Software Trusted Platform Module Transmit UDIMM Unbuffered DIMM UHCI Universal Host Controller Interface Universal Serial Bus ________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 113...
Page 114 All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 20 ____________________________________________________________________________________________________ SKY-8260SV2 Copyright 2022 Advantech Co. Ltd. All rights reserved. Page 114...

Advantech SKY-8260SV2 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Advantech SKY-8260SV2

Summary of Contents for Advantech SKY-8260SV2

Table of Contents
