4u rackmount intel xeon scalable series gpu server, supporting 10 x pcie x16 double-deck cards plus 1 x pcie x16 and 1 x pcie x8 singledeck cards (102 pages)
Page 1
Quick Start Guide for SKY-8132S-11 Hardware installation and BIOS set-up December 08, 2021 Cloud-IoT Business Group Advantech Confidential – covered by NDA...
Page 2
Contents • Hardware removal and installation • BIOS setup and FAQ • Using your own OS Advantech Confidential – covered by NDA...
Page 3
Top view of SKY-8132S-11 Advantech Confidential – covered by NDA...
1. Use a M2 Phillips head screw driver 2. Notice there are 6 M2 screws (red marked) to be removed before opening the top cover 3. Lift the top cover of extended heatsink(yellow marked) Advantech Confidential – covered by NDA...
Page 5
Opening Top Cover (2/2) 1. Remove the 2 M2 screws behind the cover of extended heatsink (red marked) 2. Slide the top cover toward you and lift it Advantech Confidential – covered by NDA...
Page 6
After removing the top cover CPU heatsink 4028 High speed fan PCIe slots (for FHHL cards) 2.5” HDD Silicom FEC acceleration card Advantech Confidential – covered by NDA...
Page 7
Removing FHHL PCIe card cage 1. Loose the thumb screw (red marked) 2. Hold yellow areas and lift up gently PCIe card cage Advantech Confidential – covered by NDA...
Page 8
1. Make sure front groove has matched 2 red circled spot. 2. Make sure rear pillar matched another red circle 3. Hold yellow areas and press down to engage the PCIe connector on the MB Advantech Confidential – covered by NDA...
Page 9
Removing LP PCIe card Cage 1. Loose the thumb screw (red marked) 2. Remove right screw(red marked) 3. Hold yellow area and lift Advantech Confidential – covered by NDA...
Page 10
Installing LP PCIe card cage 1. Make sure front groove has matched 2 red circled spot. 2. Make sure rear pillar matched another red circle 3. Hold yellow area and press to the Advantech Confidential – covered by NDA...
Page 11
Accessories • Accessory box 1. System mounting ears*2 2. M2 screws for ear wings*6 (3 for each) 3. RJ45-USB console cable*1 4. Spare M2 screws*4 5. DC Power cable*2 Advantech Confidential – covered by NDA...
Page 12
Check power module LED are all green(blue circle) power cable • Check network link LED is blinking green (red circle) • For the first time boot up, waiting for 3~5 minutes for console display Advantech Confidential – covered by NDA...
Page 13
BIOS setup and FAQ • Please refer to SKY-8132S-11 BIOS Manual (double click) • [Quick Start Guide #1] How to get device power on and display? • [Quick Start Guide #2] How to setup remote monitoring and controlling to the device? •...
Page 14
2. using internet browser (recommended Google Chrome) from another PC to connect to BMC ip – 3. login with default credential account: administrator / password: advantech – 4. using iKVM to access to OS Advantech Confidential – covered by NDA...
Page 15
– 2. using internet browser (recommended Google Chrome) from another PC to connect to BMC ip – 3. login with default credential account: administrator/ password: advantech – 4. using iKVM to access to OS Advantech Confidential – covered by NDA...
Page 16
Co-Creating the Future Co-Creating the Future of the IoT World of the IoT World Advantech Confidential – covered by NDA...
