Minimum installation height:
- 300mm from floor level to bottom edge of the product.
- This appliance includes a wall-fixing bracket.
- Install the appliance at any height above the recommended minimum of
300mm. (Note: 700mm is a commonly used installation height).
- Recommended installation height: Minimum of 300mm from floor level to
underside of hearth.
- WARNING: Installing below 300mm may cause overheating issues.
- The appliance is for wall mounting – it is not suitable for floor-level installation.
Installation:
This model comes with a wall-mounting bracket, along with five screws and wall
plugs.
Note: The provided screws and plugs are suitable for solid wall fixing only. If
installing on a hollow or stud wall, heavy-duty wall anchors or equivalent are
recommended.
To install the product:
1. Measure 700mm from the floor level and mark the wall with a pencil.
2. Position the bottom edge of the wall bracket on the 700mm mark. Use a spirit
level to ensure it is level, then mark and drill the five fixing holes.
3. Using the correct wall fixings, securely attach the wall bracket to the wall.
4. Locate the five slots on the back of the product, aligning them with prongs on
the wall bracket. Lift and slot the product into place.
5. Locate the power cable socket on the bottom of the right-hand side, underneath
the hearth of the fire. Plug in the appliance.
6. The product is now ready to be used.
OPERATING INSTRUCTIONS
After correctly installing and connecting the appliance to a grounded electrical
outlet, you can start operating the appliance.
Note: Ensure the circuit breakers for the power supply are turned on.
The heater controls are on the right side of the unit.
LED Screen
O/I: Press this button to power the appliance on. All other functions stop when the
O/I button is turned off, regardless of button position.
Control Panel
1 CR2025 batteries required
(NOT INCLUDED)
4
Remote Control
