Toroidal
Isolation
Power
Conditioning
Audio / Video Power Isolation Units
™
Model Number
WM 90 BAL AVR TVSS
AVR Manual
with Automatic Voltage Regulation
Surge
Suppression
√
Operating Range
(170-270VAC
Warning:
User is responsible for installing this
unit in accordance with all local,
provincial/state and federal electrical
code requirements. The installation of
this unit requires inspection and approval
by local electrical safety authority. This
wall mount unit is not equipped with a
power safety interlock.
Input
Output
Voltage
Voltage
5x120VAC
Maximum
Available
Output Current
90A
Advertisement
Table of Contents
Related Manuals for Torus Power WM 90 BAL AVR TVSS
Summary of Contents for Torus Power WM 90 BAL AVR TVSS
- Page 1 Input Output Maximum Suppression Voltage Voltage Available Conditioning Output Current WM 90 BAL AVR TVSS √ Operating Range 5x120VAC (170-270VAC Warning: User is responsible for installing this unit in accordance with all local, provincial/state and federal electrical code requirements. The installation of this unit requires inspection and approval by local electrical safety authority.
-
Page 2: Table Of Contents
Table of Contents Page 1 Important Safety Instructions Page 2 Shipping Carton & Packing Material Page 2 Torus Power AVR Series Power Conditioners - User Notes and Manual Page 3 Front Panel Display Page 4 Interface Connections and AVR Software... -
Page 3: Important Safety Instructions
Ship the AVR only in the original packing material, as the unit is not insurable by carriers otherwise. www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 2... -
Page 4: Torus Power Avr Series Power Conditioners - User Notes And Manual
The front panel display on the Torus Power AVR indicates input and output voltages, and displays output current, as well as displaying fault conditions. The Torus Power AVR is pre-programmed to power down the system when a high or low fault conditions occurs (user can over-ride). -
Page 5: Front Panel Display
Front Panel Display www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 4... -
Page 6: Interface Connections And Avr Software
In case you forget your password, the AVR can be restored to the factory default password avr by pressing and holding the button on the front panel for at least 10 seconds. www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 5... -
Page 7: Avr Software - Menu Selection
AVR Power Control This screen allows ON or OFF control of the AVR unit. Press SET button to implement your selection. www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 6... - Page 8 AVR unit and HOLDING it down for at least 10 seconds. The default password is avr www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 7...
- Page 9 TVSS The Wall Mount Torus Power is available with a TVSS device built in to its signal path. This UL certified Panel TVSS has a sub-nanosecond response time and manages surges beyond 20,000 Amps.
-
Page 10: Block Diagram - Avr System
Warranty coverage is extended to applicable products registered or having proof-of-purchase (sales invoice, etc.). In the event of a defect or malfunction, Torus Power will remedy the problem by repair or replacement, as we deem necessary, to restore the product to full performance. -
Page 11: Interior Detail
Model Number Input Voltage Output Voltage Input Output Load Over-current Nominal Nominal Current Rating Regulation Protection WM 90 BAL AVR TVSS 240VAC 5 X 120VAC Circuit 1.5% Input: 45A time-delay 57-63Hz Breakers fuses (2) Operating Range 5 X 120VAC (170-270VAC) www.TorusPower.com ™... -
Page 12: Layout
Layout www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 11... -
Page 13: Schematic
Schematic www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 12... -
Page 14: External Layout
Mechanical Specifications Model Number Construction Weight Size (w” x d” x h”) WM 90 BAL AVR TVSS NEMA 1 Enclosure 285 lbs. 25.25 x 10.25 x 32.5 16 gauge steel Black Powder-Coat Slip hinges enable door removal 1/4 turn latch www.TorusPower.com... -
Page 15: Home Automation Interface
Commands are terminated with the carriage return character (13 decimal). Command Description Response “C0<CR>” Turn off power “OK<CR>” “C1<CR>” Turn on power “OK<CR>” Other Not supported “ERROR<CR> commands www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units WM 90 BAL AVR TVSS 04/13 REV.04/24/2013 Page 14... - Page 16 Torus Power products are marketed worldwide through Plitron Manufacturing Inc. www.TorusPower.com For sales contact: torussales@plitron.com Phone: 416-667-9914 Torus Power Toll free: 1-800-754-8766 #8 601 Magnetic Drive Fax: 416-667-8928 Toronto, ON M3J 3J2 Canada ™ Technical inquiries: 416-667-9914 torustechnical@plitron.com Phone: 416-667-9914 Specifications subject to change without notice.
