- Page 1 AVR Series Manual Audio / Video Power Isolation Units ™ with Automatic Voltage Regulation Isolate. 19” Pro Series Rack Mount (RK) Faceplate Protect. Inspire! 17” Consumer Series (C) Faceplate Available in Black (B) and Silver (S) Colours...
-
Page 2: Table Of Contents
Table of Contents Page 1 Important Safety Instructions Page 2 Shipping Carton & Packing Material Page 2 Torus Power AVR Series Power Conditioners - Page 3 User Notes and Manual Front Panel Display Page 4 Rear Panel Connections and AVR Software... -
Page 3: Important Safety Instructions
15. The power switch should be in the “off” position when be paid to areas where the plug enters a socket or fused connecting or disconnecting equipment from a Torus Power strip and where the cord exits the device. unit. -
Page 4: Torus Power Avr Series Power Conditioners - User Notes And Manual
The front panel display on the Torus Power AVR indicates input and output voltages, and displays output current, as well as displaying fault conditions. The Torus Power AVR is pre-programmed to power down the system when a high or low fault conditions occurs (user can over-ride). -
Page 5: Front Panel Display
Front Panel Display (If ethernet connection is used) www.TorusPower.com ™ Owner’s Manual Power Conditioners Audio / Video Power Isolation Units Rack Mount (RK) / Consumer (C) 04/12 REV.04/19/2012 Page 4... -
Page 6: Rear Panel Connections And Avr Software
Rear Panel Connections and AVR Software Figure 1: AVR Rear Panel connections. Ethernet Allows access to the AVR and internal software. See AVR Software section for more details. RS232 Allows access to automation and external control. See Home Automation Interface commands at end of manual. -
Page 7: Avr Software - Menu Selection
AVR Menu Selections AVR Status Switch Power Setup Email Configuration Set Password Torus Power Home (website) Network configuration Below is a screen by screen description of software options. To access AVR software, enter user name and password. User name :... - Page 8 AVR Software - Menu Selections (continued) AVR Setup This screen allows the user to configure two AVR parameters. 1. Shutdown on Low or High line voltage. (The factory default is YES – to shut down in case of fault conditions.) Unselecting this button will override, and the AVR will remain on even if voltage drops or rises beyond the acceptable range.
- Page 9 AVR Software - Menu Selections (continued) Each AVR unit has a unique MAC Address which is factory assigned. The IP address assigned to the AVR is dynamically assigned and is displayed on this screen as well as on the front panel LCD of the AVR.
-
Page 10: Block Diagram - Avr System
Balanced Layout IEC Inlet Note: Medical Grade Outlets Layout drawing is Surge Protection Board provided for reference only, Torus Power AVR units have no serviceable parts inside. Please return unit to manufacturer for repair and service when Power Transformer required. -
Page 11: Schematic North American Model
Schematic North American Model INPUT 120VAC Schematic International Model Note: Schematic drawings are provided for reference only, Torus Power AVR units have no serviceable parts inside. Please return unit to manufacturer for repair and service when required. www.TorusPower.com ™ Owner’s Manual... -
Page 12: North American Model Numbers
North American Model Numbers 19” Pro Series 17” Consumer Description Input Output Output Rack Mount(RM) Series (CS) (Nominal) (Nominal) Connector AVR 15 RK AVR 15 CS Single 15A 120V 120V 10 outlets AVR 15 CB Medical-grade AVR 20 RK AVR 20 CS Single 20A 120V 120V... -
Page 13: Typical Front Panel Layout Of North American And International Models
When the power is on, the Switch is illuminated. When the breaker trips, the switch returns to its “off” position. While Torus Power AVR Units are designed to handle well beyond these limits, they must be marked with a Thermal Protection maximum input current that satisfies the requirements. -
Page 14: Line Cords And Wall Receptacles For North American Models
Line Cords and Wall Receptacles for North American Models Standard 15A 120V Standard 15A 240/208V Used on: Model Number AVR 15 RK, Used on: Model Numbers AVR 20 BAL RK AVR 15 CS and AVR 15 CB 20 BAL CS and AVR 20 BAL CB Equipment end: IEC C13 Equipment end:... -
Page 15: Electrical Specifications International Models
Electrical Specifications International Models Model Number Input Voltage Input Current Load Current Capability Input Current Nominal Limiting Rating ½ cycle 1 second 10 seconds AVR 16 UK RK 2 0VAC 16A Circuit Breaker 160A AVR 16 UK CB Range +/- 10% voltage Front Panel AVR 16 UK CS 47-53Hz... -
Page 16: Rear Panel Layout Of International Models
Rear Panel Layout of International Models 16A/250V Ivory Continental European Socket 13A/250V UK Socket Continental Europe 16A, Model Number United Kingdom 16A, Model Number AVR 16 AVR 16 CE C S and AVR 16 CE C AVR 16 UK RK, AVR 16 UK C S and AVR 16 UK C... -
Page 17: Home Automation Interface
Warranty coverage is extended to applicable products registered or having proof-of-purchase (sales invoice, etc.). In the event of a defect or malfunction, Torus Power will remedy the problem by repair or replacement, as we deem necessary, to restore the product to full performance. - Page 18 Torus Power products are marketed worldwide through Plitron Manufacturing Inc. www.TorusPower.com For sales contact: torussales@plitron.com Phone: 416-667-9914 Torus Power Toll free: 1-800-754-8766 #8 601 Magnetic Drive Fax: 416-667-8928 Toronto, ON M3J 3J2 Canada ™ Technical inquiries: 416-667-9914 torustechnical@plitron.com Phone: 416-667-9914 Specifications subject to change without notice.
