Audio / video power isolation units 19” pro series rack mount (rk) faceplate 17” consumer series (c) faceplate available in black (b) and silver (s) colours with automatic voltage regulation (18 pages)
Page 1
Audio / Video Power Isolation Units with Automatic Voltage Regulation Isolate. Protect. 19” Pro Series Rack Mount (RM) Faceplate 19” Pro Series Rack Mount (RM) Faceplate Inspire! 17” Consumer Series (CS) Faceplate Available in Black (B) and Silver (S) Colours Output 19”...
Table of Contents Table of Contents Page 1 Torus Power AVR Series Power Conditioners - Page 2 User Notes and Manual Front Panel Display Page 3 Rear Panel Connections and AVR Software Page 4 AVR Software - Menu Selection Page 5,6...
The front panel display on the Torus Power AVR indicates input and output voltages, and displays output current, as well as displaying fault conditions. The Torus Power AVR is pre-programmed to power down the system when a high or low fault conditions occurs (user can over-ride).
Rear Panel Connections and AVR Software Figure 1: AVR Rear Panel connections. Ethernet Allows access to the AVR and internal software. See AVR Software section for more details. RS232 Allows access to automation and external control. See Home Automation Interface commands at end of manual.
AVR Software - Menu Selections www.TorusPower.com Owner’s Manual Power Conditioners Audio / Video Power Isolation Units RM/CS 60 BAL AVR 02/11 Page 5...
Page 7
AVR Software - Menu Selections (continued) AVR Setup This screen allows the user to configure two AVR parameters. 1. Shutdown on Low or High line voltage. (The factory default is YES – to shut down in case of fault conditions.) Unselecting this button will override, and the AVR will remain on even if voltage drops or rises beyond the acceptable range.
Block Diagram - AVR System Layout IEC Inlet Note: Medical Grade Outlets Layout drawing is Surge Protection Board provided for reference only, Torus Power AVR units have no serviceable parts inside. Please return unit to manufacturer for repair and service when Power Transformer required.
When the power is on, the Switch is illuminated. When the breaker trips, the switch returns to its “off” position. While Torus Power AVR Units are designed to handle well beyond these limits, they must be marked with a Thermal Protection maximum input current that satisfies the requirements.
CS 60 INT’L AVR USA S and CS 60 INT’L AVR USA B Ground Stud Rubber Mounting Feet Schematic Note: Schematic drawings are provided for reference only, Torus Power AVR units have no serviceable parts inside. Please return unit to manufacturer for repair and service when required. www.TorusPower.com Owner’s Manual...
“off” position when connecting or so they are not likely to be stepped on or crushed by items disconnecting from a Torus Power unit. placed on them or against them. Special attention should be paid to areas where the plug enters a socket or fused...
Torus Power operating instructions, voids the warranty. applicable products registered or having proof-of-purchase (sales invoice, etc.). In the event of a defect or malfunction, Torus Power will remedy the problem by repair or replacement, as we deem necessary, to restore the product to full performance.
Page 13
Torus Power products are www.TorusPower.com marketed worldwide through Bryston Limited. For sales contact: Torus Power #8 601 Magnetic Drive James Tanner, Toronto, ON M3J 3J2 jamestanner@bryston.ca Canada Phone: 705-742-5325 416-667-8473 USA: Craig Bell, cnbell@verizon.net Specifications subject to change without notice.
