TRENDnet TE100-S800I Specifications

FEATURES
• 8 x 10/100Mbps Auto-MDIX Ports
• Supports switch Fabric up to 3.8GBps
• Layer 2 Management Switch with Full Software Support
• IGMP Snooping with Query Mode Support for Multi-Media Application
• Supports Broadcast Storm Filtering
• Supports Port Status Control (Status, Auto-Negotiation, Speed, Duplex and Flow Control)
• Supports Port Trunking with Flexible Load Distribution Control and Fail-Over Functions
• Supports Port-Based VLAN and IEEE 802.1Q Tag-Based VLAN
• Supports IP Multicast, Port Mirroring, Spanning Tree, SNMP and RMON
• Supports Port Security and IEEE 802.1p Class of Services
• Store-and-Forward Switching Architecture with Non-Blocking Wire-Speed Performance
• Configuration via RS-232 Console Port, Telnet, and Web Browser (HTTP)
• TFTP Firmware Upgrade via Browser
• Configuration File Save and Restore Support
• 3-Year Limited Warranty
8-Port 10/100Mbps Layer 2 Managed Switch
TE100-S800i
The 8-Port 10/100Mbps Layer 2 Managed Switch provides
exceptional performance, ease of use and flexibility for managing
business networks. Utilizing a robust 3.8Gbps backplane, the 8 port
managed switch can connect to multiple switches while handling full-
duplex operations. In addition to the switch's scalability, it also offers
a variety of management features such as SNMP, IGMP for multi-
media applications, VLAN, Port Security, Spanning Tree Protocol,
Port Trunking, Broadcast Storm Filtering, Port Mirroring and other
features that can easily be accessed through a web browser or a
command line interface.
switch
TE100-S800i
rev:06.30.2010
