TRENDnet TE100-S5Pplus Specifications

TE100-S5P
5-port 10/100Mbps NWay Auto-MDI Fast Ethernet Mini Switch
TRENDnet's TE100-S5P, 5-port, palm-sized 10/100Mbps
NWay Ethernet Switch, presents the perfect choice for small
workgroups for any desktop space. It allows users to simply
plug any port to either a 10Mbps or 100Mbps network to
multiply bandwidth, boost response time and satisfy heavy
load demands. The NWay ports automatically negotiate
between 10Base-T and 100Base-TX network speeds, half-
and full-duplex modes, and MDI-II and MDI-X media types.
TE100-S5P is truly a Plug-N-Play device, which provides
cost-effective and high-performance solutions.
FEATURES
Compliant with IEEE 802.3 and IEEE 802.3µ
standards
5-port NWay 10/100Mbps connection speed auto-
detection
Half- or Full-Duplex operation for each port
Auto-MDI-II / MDI-X media type detection
Operates at maximum packet filtering and
forwarding rate
Store-and-forward switching method
128KB buffer memory
Address table up to 4K MAC address
Compact design with external power adapter
Comprehensive LED indicators for port status
Wall-Mountable with two magnets on the bottom for
mounting on ferrous surface
5-year Warranty
TRENDnet
TRENDware, USA
What's Next in Networking
BENEFITS
Easy Installation:
Designed to link 10Mbps and
100Mbps with 5 ports for an easy
connection.
Flexibility:
NWay ports auto-negotiate between
10Base-T and 100Base-TX, as well as
between half- and full-duplex modes.
Auto-MDI for each port; connects to
regular RJ45 port or Uplink port with
either regular "straight through" or
crossover RJ45 cable.
Expandability:
All ports support 200Mbps (in full-
duplex mode), expanding from any
port and for any number of Switches.
Easy Migration:
Easy upgrade to Fast Ethernet without
reconfiguration.
Dependability:
Parallel store-and-forward architecture
allows direct transfer.
TE100-S5P (11-17-2002)
