Page 1: Print Server
TE100-PS1 Ethernet / Fast Ethernet Multiprotocol Print Server Hardware Guide Rev. 01 (November, 1997) Printed In Taiwan RECYCLABLE... - Page 2 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Hersteller zugelassen sind. Das Ger酹 is vor Feuchtigkeit zu sch zen. Bei der Aufstellung des Ger酹es ist auf sichern Stand zu achten. Ein Kippen oder Fallen k 霵nte Verletzungen hervorrufen. Verwenden Sie nur sichere Standorte und beachten Sie die Aufstellhinweise des Herstellers.
-
Page 4: Table Of Contents
Service Features................1 External Features ................3 Rear Panel ..................3 LED Indicators ................4 ..........5 NPACKING AND NSTALLATION Unpacking and Inspecting.............5 Installing the TE100-PS1 ..............6 Power-up and Self-Test ..............7 ................7 LED Test Series Component Test Series ..............7 Operational Test ................8 Velcro-mounting the TE100-PS1...........9 ............10... -
Page 5: Bout This Guide
Multiprotocol Print Server, including full descriptions of its features, detailed installation procedures, and troubleshooting information. Your TE100-PS1 package includes important software components, and additional user manuals. The software components, and procedures for installation and setup of the software, are covered in the TRENDnet EtherPort Admin User’s Guide. -
Page 7: Introduction
PC acting as a print server can. Service Features TE100-PS1 print servers improve network printing services in three ways: ♦... - Page 8 Your TE100-PS1 package includes TRENDnet EtherPort Admin, a Windows-based setup and administration program, which makes configuration and management of your print servers quick and easy in a Windows environment. The TE100-PS1 also has a Telnet interface for management communications. If Windows is not...
-
Page 9: External Features
TE100-PS1 Rear Panel Printer Port The printer port, labeled LPT, is configurable by commands in the PS Admin program, or by commands issued to the TE100-PS1 via Telnet. See the TRENDnet EtherPort Admin User’s Guide for configuration procedures. -
Page 10: Led Indicators
10Base-T Ethernet cabling, or Category 5 twisted-pair cable for 100Base-TX Fast Ethernet. This port has auto-negotiation (NWay) functionality, which enables the TE100- PS1 to automatically negotiate and set its data rate to the highest rate allowed by its network. DC Power Input... - Page 11 Ether-P401 Print Server Hardware Guide ♦ LPT This indicator shows steady green while the TE100-PS1 is transferring print data through its printer port Introduction...
-
Page 12: Unpacking And Installation
♦ One Print Server Administration User’s Guide ♦ One lpr software diskette ♦ One lpr user's guide ♦ Velcro strips for optional mounting If any item is missing, or if you find any damage or mismatch, promptly contact your dealer for assistance. -
Page 13: Installing The Te100-Ps1
Follow this procedure to avoid complications at the configuration stage. 5. While the printer is power off, install a printer cable to connect its parallel port to the printer port of the TE100-PS1. 6. Switch printer power on. 7. Plug the DC power adapter output plug into the DC power input socket on the rear panel of the TE100-PS1 8. -
Page 14: Power-Up And Self-Test
Component Test Series The actual component tests immediately follow the LED tests. A normal (no fault) result is signaled by three flashes of the LPT indicator and the start of normal print server operation. If any error condition is found during the component test series, then the test will halt with the LPT LED continuously signaling the particular error according to the following table. -
Page 15: Operational Test
Administration User’s Guide ("TRENDnet EtherPort Admin Administration" section, under the heading "Upgrading the Print Server's Internal Firmware"). In the event that any of the other listed error conditions is encountered on startup, contact your dealer for correction of the fault. -
Page 16: Velcro-Mounting The Te100-Ps1
The bottom housing of the TE100-PS1 case features two corner markers which indicate the best location for applying the Velcro loop tape. Peel the white backing off of the loop tape, to expose its adhesive surface, and press it onto the bottom of the TE100-PS1, between the corner markers. -
Page 17: Product Specifications
Network Data Transfer Rate: 10Mbps and 100Mbps (megabits per second), according to network environment. Network Connector: RJ-45 connector for 10Base-T or 100Base- TX twisted pair connection; NWay automatic speed negotiation supported. Network Protocols Ethernet Frame Types: 802.2, 802.3, Ethernet II, SNAP (auto- switching) Transport Protocols: IPX/SPX, TCP/IP,... - Page 18 Weight: approx. 200g Operating Temperature: 0 to 50°C Storage Temperature: -10 to 50°C Humidity: 10% to 90% non-condensing Emissions: FCC Class A, CISPR 22 Class A, VCCI Class 1, AS/NZS 3548:1995 Class A Safety: UL (UL 1950), CSA (CSA950) Product Specifications...
-
Page 19: Port Pinouts
INOUTS The following table lists the pinouts of the TE100-PS1's 25-pin parallel port connector (identical to the parallel port connector used on most personal computers), and the corresponding pin numbers for the 36-pin Centronics connector as used on most printers. -
Page 20: Index
4, 7, 11 diskettes printing operational test error condition 7, 8 protocols 2, 10, 11 Ethernet 1, 3, 4, 10 PS Admin, Print Server Administration EtherTalk 2, 10 program 3, 5, 8 Fast Ethernet 1, 3, 4, 10 reload firmware firmware...
