USE AND MAINTENANCE
This manual contains important information for safe use and operation of this machine. Failure to read this manual before starting
up, adjusting or carrying out maintenance operations on this machine may cause damage to persons and/or things. The operator
must be trained to use the machine before starting it up. Keep this manual for future reference. For new manuals, apply to:
Janser GmbH - Maschinen- und Gerätebau
Böblinger Straße 91
- D-71139 Ehningen
Tel. 07034 / 127-0 - Telefax 07034 / 8838
http:// www.janser.com Email: info@janser.com
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PUMA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Janser PUMA

Summary of Contents for Janser PUMA

  • Page 1 The operator must be trained to use the machine before starting it up. Keep this manual for future reference. For new manuals, apply to: Janser GmbH - Maschinen- und Gerätebau Böblinger Straße 91 - D-71139 Ehningen Tel.
  • Page 2 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 2 /13 INDEX Instructions for operator safety Machine safety characteristics Introduction and machine characteristics Instructions for electrical connection Carrying the machine Setting the machine up Machine operation Adjustment procedures work surface on the floor...
  • Page 3 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 3 /13 INSTRUCTIONS FOR OPERATOR SAFETY means The operator or other person may be seriously injured or die if the DANGER warnings found on this machine or in this manual are ignored or not kept to.
  • Page 4 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 4 /13 Maintenance or repairs carried out on a machine which is not duly disconnected from the power supply line may cause electrocution. Disconnect the power line before carrying out any maintenance work and/or repairs.
  • Page 5 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 5 /13 MACHINE SAFETY INSTRUCTIONS The following information highlights potentially dangerous conditions for the operator and/or machine. Read this manual carefully in order to become familiar with the machine. Learn to know when these conditions may occur. Set all the safety devices on the machine.

  • Page 6: Instructions For Electrical Connection

    Puma Puma Puma Puma ED 95 EDGE SANDER PG. 6 /13 INSTRUCTIONS FOR ELECTRICAL CONNECTION CAUTION: This machine only works with the voltage and frequency shown on the machine plate. Before connecting the cable to the power supply grid, make sure that the voltage and frequency available are correct.
  • Page 7 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 7 /13...

  • Page 8: Carrying The Machine

    Puma Puma Puma Puma ED 95 EDGE SANDER PG. 8 /13 CARRYING THE MACHINE Make sure that the power supply cable is disconnected from the mains and the machine. Always carry the sander using both handles with the bag support facing upwards.

  • Page 9: Machine Operation

    Puma Puma Puma Puma ED 95 EDGE SANDER PG. 9 /13 MACHINE OPERATION DANGER: Sanding wooden floors may lead to an explosive environment. Cigarettes, cigars, pipes, lighters, pilot lights and all other sources of fire may cause an explosion if they are used while sanding.

  • Page 10: Routine Maintenance

    Puma Puma Puma Puma ED 95 EDGE SANDER PG. 10 /13 ADJUSTMENT OF THE WORK SURFACE ON THE FLOOR Abrasive carrying plate P (fig. 1) has the shape of a very wide truncated cone. For the plate to work on the level, its axis must slope with respect to the floor.

  • Page 11: Spare Parts

    Puma Puma Puma Puma ED 95 EDGE SANDER PG. 11 /13 Remove the motor cover by unscrewing the four attachment screws using an Allen wrench. Use a screwdriver to remove the cable terminal attachment screws on each brush. Pull back the brush pressure spring and remove the brush.
  • Page 12 Puma Puma Puma Puma ED 95 EDGE SANDER PG. 12 /13 PROBLEMS CAUSES REMEDIES Insufficient cut worn or unsuitable abrasive replace abrasive Insufficient motor speed insufficient voltage due to: excessive length or unsuitable cable cross- use cable of suitable length and cross-section...
  • Page 13 Böblinger Straße 91 71139 Ehningen GERMANY declare under our responsibility that the product PUMA EDGER to which this declaration relates complies with the following standards or other normative document(s): • Safety of machinery - Basic concepts, general principles for design Basic terminology, methodology EN 292 Part 1 -September 1991 ..
