- Page 1 Quick Installation Guide TE100-P11 TEW-P11G H/W: V1...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ...................... 1 1. Before You Start ................. 2. How to Install ..................3. Configure the Print Server ..............Troubleshooting ..................8 Version 12.12.2008... -
Page 3: English
1. Before You Start Package Contents TE100-P11/TEW-P11G Utility CD-ROM Multi-Language Quick Installation Guide AC Power Adapter (5V DC, 2A) System Requirements CD-ROM Drive Windows 98SE/Me/2000/XP/2003 Server/Vista Wired or Wireless Router An Available DHCP Server – routers usually have a built-in DHCP server English... - Page 4 Application 2-Port USB/Parallel Print Server (TE100-P11) 4-Port Gigabit Firewall Router (TWG-BRF114) Internet Parallel Workstation with Worstation with Cable/DSL Printer Printer Modem 10/100Mbps PCI Adapter 10/100Mbps PCI Adapter (TE100-PCIWN) (TE100-PCIWA) 10/100Mbps Wireless 2-Port USB/Parallel Print Server (TEW-P11G) Workstations with Wireless N USB Adapter...
-
Page 5: How To Install
2. How to Install Note: Please power off all printers before connecting them to the print server. Then turn on each printer after you make your hardware connections. 1. Connect a RJ-45 network cable from the LAN port on your Router to the LAN port of the Print Server. -
Page 6: Configure The Print Server
3. Configure the Print Server Note: Disable any anti-virus and firewall programs before starting hardware installation. For Windows Users 1. Insert the Utility CD-ROM into your computer's CD-ROM Drive. 2. Click Run autorun.exe (Windows Vista only). 3. Click Setup Wizard. - Page 7 Name. 7. Select the Obtain IP Address automatically and then click Next. Note: If you have the TE100-P11, skip to step 11. If you have the TEW-P11G, continue on step 8. 8. Select the desired wireless network and click Next.
- Page 8 9. The correct wireless settings should be automatically configured. Then click Next. 10. If enabled, enter the encryption key for your wireless network and then click Next. This example shows WPA2-PSK. 11. Click Finish. English...
- Page 9 98SE/ME/2000/XP/2003 Server/Vista, please refer to the User's Guide on the Utility CD-ROM or TRENDnet's website at www.trendnet.com Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at:...
-
Page 10: Troubleshooting
(e.g. ZoneAlarm). If your computer is running Windows XP or Vista, disable the built in firewall program. Fourth, unplug the power to the print server, wait 15 seconds, then plug the power back in. How do I add a printer to my computer? Please refer to the User's Guide on the CD-ROM for instructions on adding a printer. - Page 11 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 12 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2008. All Rights Reserved. TRENDnet.
