- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. TWIN EAGLES TEPB24-CN Owner's Manual Shop genuine replacement parts for TWIN EAGLES TEPB24-CN Find Your TWIN EAGLES Grill Parts - Select From 58 Models -------- Manual continues below --------...
- Page 2 TWIN EAGLES POWER BURNER INSTALLATION, USE, & CARE MANUAL MODELS: TEPB24HG-C (SHOWN) TEPB24-C P/N: 19239F 01/19...
-
Page 3: For Your Records
At TWIN EAGLES, we want you to enjoy grilling and spending time together as much as we do – making memories that linger long after the grill cools down. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING! Read this manual carefully and completely before using your Power Burner to ensure proper operation, proper installation, proper servicing and to reduce the risk of fire, burn hazard and/ or other injury. AVERTISSEMENT! Lire ce manuel avec soin et en entier avant l’utilisation de votre barbecue afin d’en assurer un fonctionnement, une installation et un entretien adéquats et réduire le risque d’incendie, de brûlures et d’autres blessures. -
Page 5: General Safety Requirements
Burner. Without the drip pan, hot liquid and debris could leak downward and produce a fire hazard. 12. The pressure regulator supplied with the Twin Eagles Gas Power Burner must be used. Replacement pressure regulators must be those specified by Twin Eagles. -
Page 6: Table Of Contents
TABLE OF CONTENTS GETTING STARTED………………………………………………………………………………………………………. LOCATING THE POWER BURNER o CLEARANCE TO COMBUSTIBLE CONSTRUCTION………………………..………………………… o CLEARANCE TO NONCOMBUSTIBLE CONSTRUCTION……………….…………………………… GAS REQUIREMENTS o GAS SAFETY REQUIREMENT…………………………………………..……………......o LP GAS HOOKUP………….………………………………………………………..……………………... o NATURAL GAS INSTALLATION…………………………………………………..……………………. o LEAK TEST…………………………………………………………………………….…………………... o BURNER FLAME / AIR SHUTTER ADJUSTMENT …………………………………………………….. ELECTRICAL REQUIREMENTS ……..…………………………..………………………………..……………………. -
Page 7: Getting Started
GETTING STARTED 1. Remove all packaging materials, labels and protective plastic film. DO NOT LEAVE UNIT UNDER THE SUN WITH PROTECTIVE PLASTIC FILM ON FOR A LONG PERIOD OF TIME AS IT WILL BE DIFFICULT TO REMOVE THE FILM. 2. Check to ensure that all Power Burner accessories listed below are included. Power burner Accessories TEPB24-BN TEPB24-BL... -
Page 8: Locating The Power Burner
LOCATING THE POWER BURNER This gas appliance is designed and certified for outdoor use only. Do not locate this Power Burner under overhead combustible surfaces. Do not operate the Power Burner inside a building, garage, recreation vehicle or any enclosed area. CAUTION should be taken when grills are used near glass, vinyl siding or other temperature sensitive construction materials. -
Page 9: Gas Requirements
GAS SAFETY REQUIREMENTS Each appliance is set and tested at the factory for the type of gas supply to be used. Identify the type of gas, either natural gas or LP gas and make sure that the marking on the data plate (rating plate) matches the gas being supplied to the Power Burner. -
Page 10: Lp Gas Hookup
Power Burner. Do not use any replacement regulator other than that specified by Twin Eagles. Use only pipe sealants that are approved for use with natural and LP gases. An installer-supplied gas shutoff valve must be installed in an accessible location. (Reference: page 6 for leak test procedure). -
Page 11: Natural Gas Hook-Up
NATURAL GAS HOOK-UP The installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1 or Propane Storage and Handling Code, B149.2. 1. -
Page 12: Leak Test
LEAK TEST CAUTION BEFORE LIGHTING • Finding and/or fixing a gas leak is NOT a “DO IT YOURSELF” procedure. • NEVER USE THE POWER BURNER WITHOUT FIRST LEAK TESTING THE GAS CONNECTIONS • WARNING: DO NOT USE AN OPEN FLAME TO CHECK FOR LEAKS. USE OF AN OPEN FLAME COULD RESULT IN A FIRE, EXPLOSION, AND BODILY HARM. -
Page 13: Burner Flame / Air Shutter Adjustment
BURNER FLAME / AIR SHUTTER ADJUSTMENT Each grill burner is tested and adjusted at the factory prior to shipment; however, variations in the local gas supply may make it necessary to adjust the burners. The flames of the U-burners should be visually checked. Flames should be blue and stable with little to no yellow tips, no excessive noise or lifting. -
Page 14: Electrical Requirements
ELECTRICAL REQUIREMENTS The appliance should only be taken apart by a qualified technician, or electrical shock may occur. It is rated at 120V, 60Hz, and 2.2A. REMINDER: Keep any electrical supply cord and the fuel supply hose away from any heated features. WARNING Electrical Grounding Instructions: This outdoor gas cooking appliance is equipped with a three prong (grounding) plug for... -
Page 15: Cutout Dimensions
CUT-OUT DIMENSIONS NOTE: IT IS RECOMMENDED TO BUILD THE ENCLOSURE FOR THE POWER BURNER 6”-12” LOWER THAN THE COUNTERTOP. WARNING: The Power Burner must be installed in a NON-COMBUSTIBLE ENCLOSURE ONLY. -
Page 16: Operating Instructions
OPERATING INSTRUCTIONS BEFORE LIGHTING THE POWER BURNER DO NOT ATTEMPT TO LIGHT THE POWER BURNER IF YOU SMELL GAS • WARNING! IT IS CRITICAL THAT THE GAS BURNER IS PROPERLY INSTALLED WITH THEIR ORIFICES INSIDE THE BURNERS AIR SHUTTERS. If not properly installed, gas may leak outside of the burner that could lead to fire, potential damage to your Power Burner and bodily injury. -
Page 17: Cleaning And Maintenance
WARNING: It is recommended that your TWIN EAGLES products be kept dry and covered when not in use. This is even more important when long-term storage is intended. -
Page 18: Grates
GRATES Round Grates • The easiest way to clean the grates is to scrub them with a barbeque brush immediately after cooking is completed and the flame is turned off. • Wear a barbeque mitt to protect your hands from the heat and steam. Dip a brass bristle barbeque brush in tap water and scrub the hot grates. -
Page 19: Burner Installation Check
BURNER INSTALLATION CHECK CORRECT INSTALLATION THE ORIFICE IS COMPLETELY INSERTED INTO THE VENTURI INCORRECT INSTALLATION THE ORIFICE IS OUT OF POSITION AND IS NOT INSERTED INTO THE VENTURI ELECTRICAL DIAGRAM... -
Page 20: Exploded View
EXPLODED VIEW... -
Page 21: Replacement Parts List
IR Burner Elbow Assembly S16404 Power Supply, LPV-60-12 S26366Y Power Supply Bracket S16111 Electrical Cord S16112 Strain Relief S13204 Logo, Twin Eagles S14160 Tinnerman Clips S26331-24WY Front Panel Welded Assy. 12V Switch, Illuminated, 19mm, S16196 Blue S13270 Light Bezel S13224... -
Page 22: Troubleshooting Guide
TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE: If your Twin Eagles Power Burner does not function properly, use the following troubleshooting guide before contacting your dealer for service. The troubleshooting guide may save the cost of a service call and the inconvenience of being without your Power Burner. -
Page 23: Limited Product Warranty
2206. Be prepared to furnish the following information: Purchaser’s name, model and serial number of the Power Burner, date of purchase and the accurate description of the problem. Twin Eagles will not pay for service calls for correcting an installation problem. -
Page 24: How To Obtain Service
HOW TO OBTAIN SERVICE For service, please contact your TWIN EAGLES dealer or call TWIN EAGLES direct at (800) 789-2206 or (562) 802-3488 or fax (562) 802-3391 Mailing address: Twin Eagles, Inc. 13259 East 166 Street Cerritos, CA 90703 Visit us at www.twineaglesgrills.com... - Page 25 Place Here Postage Here Customer Service ATTN: Warranty Department 13259 East 166 Street Cerritos, CA 90703 Fax no. (562) 802-3391...
