- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. TWIN EAGLES TESB132F-BN Owner's Manual Shop genuine replacement parts for TWIN EAGLES TESB132F-BN Find Your TWIN EAGLES Grill Parts - Select From 58 Models -------- Manual continues below --------...
- Page 2 FREESTANDING SIDE BURNER INSTALLATION, USE, AND CARE MANUAL MODEL: TESB132F-C P/N: 24262E 01/19...
- Page 3 At TWIN EAGLES, we want you to enjoy grilling and spending time together as much as we do – making memories that linger long after the grill cools down.
- Page 4 IMPORTANT SAFETY INFORMATION WARNING! Read this manual carefully and completely before using your side burner to ensure proper operation, proper installation, proper servicing and to reduce the risk of fire, burn hazard and/ or other injury. AVERTISSEMENT! Lire ce manuel avec soin et en entier avant l’utilisation de votre barbecue afin d’en assurer un fonctionnement, une installation et un entretien adéquats et réduire le risque d’incendie, de brûlures et d’autres blessures.
- Page 5 • Never use the side burner in a windy area. • The pressure regulator and hose assembly supplied with the Twin Eagles Side Burner must be used. Replacement pressure regulators and hose assemblies must be those specified by Twin Eagles.
-
Page 6: Table Of Contents
TABLE OF CONTENTS INSTALLATION INSTRUCTIONS........................LEAK TEST………………………………………………………………………………………………………. OPERATING INSTRUCTIONS………………………………………………………………………………… CLEANING & MAINTENANCE o STAINLESS STEEL………………………………………………………………………………………. o S-GRATE………………………………………………………………………………………………….. o SPIDER AND INSECT WARNING……………………………………………………………………… REPLACEMENT PARTS o EXPLODED VIEW………………………………………………………………………………………... o REPLACEMENT PARTS LIST…………………………………………………………………………... o WIRING DIAGRAM……………………………………………………………………………………… o TROUBLE SHOOTING GUIDE………………………………………………………………………….. LIMITED PRODUCT WARRANTY…………………………………………………………………………… WARRANTY REGISGRATION CARD... -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Remove the front side shelf bracket. Save the screws. 2. Remove side shelf off cart. Store in the cart under the grill. Reinstall side shelf bracket using the saved screws. 3. Insert pin of the rear bracket into the hole on the back side of the side burner housing. Then slide the front pin into the slotted hole on the front side of the side burner housing. - Page 8 6. Locate and connect extension wires from side burner to grill. 7. Reinstall access door if removed.
-
Page 9: Leak Test
▪ Check to ensure that flexible hoses do not have any cuts and wear that may affect the safety before each use. Only the factory supplied hose and regulator must be used. Use only replacement regulator and hose assemblies specified by Twin Eagles. LEAK TEST 1) Prepare a leak testing solution of sudsy water by mixing in a spray bottle with half liquid soap and half water. -
Page 10: Operating Instructions
Caution: Always allow the Freestanding Side Burner to cool before cleaning. STAINLESS STEEL & GENERAL PRODUCT CARE To keep your TWIN EAGLES products free of surface corrosion and in good working order, it is important to take additional precautions under certain conditions. -
Page 11: S-Grate
However, the conditions outlined above, along with neglect, can lead to surface corrosion or rust. It is recommended that your TWIN EAGLES products be kept dry and covered when not in use. This is even more important when long-term storage is intended. -
Page 12: Exploded View
EXPLODED VIEW... -
Page 13: Replacement Parts List
Enameled Cap S13308 Enameled Ring S13307 Aluminum Bowl S13306 Base with Electrode, LP S13320 Base with Electrode, NG S13204 Logo, Twin Eagles S14160 Tinnerman Clips S16196 12V Switch, Illuminated S13270 Light Bezel Assembly S13224 Lens, Light Bezel S13226 Rubber Retention Ring... -
Page 14: Wiring Diagram
WIRING DIAGRAM TESB132/132F-C WIRING DIAGRAM SHOWN... -
Page 15: Trouble Shooting Guide
BEFORE CALLING FOR SERVICE: If your Twin Eagles Side Burner does not function properly, use the following trouble shooting guide before contacting your dealer for service. The troubleshooting guide may save you the cost of a service call and the inconvenience of being without your Side Burner. -
Page 16: Limited Product Warranty
800-789-2206. Be prepared to furnish the following information: Purchaser’s name, model and serial number of the grill, date of purchase and the accurate description of the problem. Twin Eagles will not pay for service calls for correcting an installation problem. Owner shall be responsible for proper installation, providing normal care and maintenance, providing proof of purchase upon request and making the grill accessible for service. - Page 17 THIS PAGE IS INTENTIONALLY LEFT BLANK...
- Page 18 HOW TO OBTAIN SERVICE For service, please contact your TWIN EAGLES dealer or call TWIN EAGLES direct at (800) 789-2206 or (562) 802-3488 or fax (562) 802-3391 Mailing address: Twin Eagles, Inc. 13259 East 166 Street Cerritos, CA 90703 Visit us at www.twineaglesgrills.com...
- Page 19 Here Place Postage Here Customer Service ATTN: Warranty Department 13259 East 166 Street Cerritos, CA 90703 Fax no. (562) 802-3391...
