- Page 1 Instruction Manual USE R MA N UAL UNIVERSAL LADDER STABILIZER LAS48 Meets or exceeds applicable standards Rev. July. 2024...
- Page 3 Instruction Manual Frontline Fall Protection Inc. INSTRUCTION MANUAL Applicable standards and regulations depend on the type of work being done, and also might include state-specific regulations. Refer to local, state, and federal (OSHA) requirements for additional information concerning the governing body of occupational safety regarding ladders, ladder systems and/or Personal Fall Arrest Systems (PFAS).
-
Page 4: Table Of Contents
Instruction Manual TABLE OF CONTENTS Specific Use ________________________________________________________ 5 System Specifications ______________________________________________ 5 General Statements and Warnings __________________________________ 5 Training______________________________________________________________ 6 Ladder Stabilizer Assembly Diagram _______________________________ Installation __________________________________________________________ 7 Precautions and Warnings __________________________________________ 11 Maintenance, Storage & Transportation _____________________________ 11 Inspection __________________________________________________________ 13 BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT... -
Page 5: Specific Use
SPECIFIC USE: The Frontline Ladder Stabilizer is used to help provide better stability to the user when working and using a compatible straight or extension ladder. SYSTEM SPECIFICATIONS: SYSTEM SPECIFICATIONS: 1 Person with a combined weight of 300 lbs, including... -
Page 6: Training
Instruction Manual TRAINING Before using Frontline Fall Protection product, user and employers must ensure that the person using this equipment has been trained on the proper use, care and maintenance of this product by a competent person qualified in Fall Protection. It is the responsibility of the user of this product to ensure that proper training has been done in addition to reading and fully understanding these user instructions manual. -
Page 7: Ladder Stabilizer Assembly Diagram
LADDER STABILIZER ASSEMBLY DIAGRAM: PARTS Left and Right Side Rail Intermediate Bracket U - Bolts Tie Back Plates Bracket Pins Plastic Nuts Rubber Supports INSTALLATION: 1. Insert side rails (a) into intermediate bracket (b) and accordingly to ladder width and desired width of stabilizer (40” - 46”). BUILT TO LAST | MANUFACTURED TO... - Page 8 Instruction Manual FIGURE 1 2. Locate the ladder’s top rung, and insert the Bracket Pins (e) of the Tie Back Plates (d) into the hole that best fits your ladder inside the ladder side rails. a. Ensure both left and right side rails match the same holes and maintain the same distance on the Intermediate Bracket.
- Page 9 3. Place the U - Bolts (c) over the ladder rungs facing the Ladder Stabilizer. a. Ensure the ladder rails and frame are up against the flat part of the ladder stabilizer FIGURE 3 Flat against rails and ladder stabilizer 4.
- Page 10 Instruction Manual 5. Secure the Bracket Pins (e) by inserting the safety pins at the bottom end of the ladder rung. FIGURE 5 6. Ladder stabilizer side rails should be perpendicular to ladder in order to support up against wall/surface accordingly. FIGURE 6 BUILT TO LAST...
-
Page 11: Precautions And Warnings
Frontline assumes and takes no responsibility for maintenance measures outside of light maintenance as described above. Product that does not pass inspection or is questionable needs to be taken out of service immediately. - Page 12 Instruction Manual a clean area away from sunlight, rain and other environmental conditions. Products should be also stored where they are not exposed to chemical, oils, paint, concrete, or other contaminants that might compromise the integrity of the product. Equipment that has been physically exposed such as rain/dirty water, concrete, paint, buildup of other construction material or other surface contamination shall be cleaned and dried before storage.
-
Page 13: Inspection
INSPECTION INSPECTION DATE: INSPECTED BY: Prior to installation and prior to each use / Inspection by a INSPECTION: PASS FAIL competent person other than the user is required every 6 months. Ensure ladder frame is flat up against intermediate bracket LADDER STABILIZER: Ensure bracket pins are fully inserted... - Page 14 Frontline Fall Protection Inc. www.frontlinefall.com info@frontlinefall.com ©2024 Frontline...
