Denkovi smartDEN IP-Maxi Series User Manual page 16

Parameter
Analog inputs number
Analog inputs full scale voltage range, V DC
Analog inputs absolute maximum non-
destructive voltage, V DC
Analog inputs resolution, bits
Value of LSB, mV
Input impedance, KΩ
Sample period, ms
Protection against reverse polarity
*No communication (HTTP, SNMP) is taking place with the module
**Intensive communication (HTTP, SNMP) with the module
Parameter
NTC inputs number
Sensor type
Units
Sensor working temperature range
Accuracy
Sample period, ms
*No communication (HTTP, SNMP) is taking place with the module
**Intensive communication (HTTP, SNMP) with the module
Parameter
Relays number
Max. Voltage
Max. switchable current
Parameter
Analog outputs number
Output voltage
®
Voltage=250V AC
Voltage=125V AC
Voltage=28V DC
smartDEN IP-Maxi-XX User Manual
Table 4.5. Analog inputs
Value
4
0 up to 10
24
10
∼10
1330
Min: 25*
Max: 300**
Yes
Table 4.6. Temperature inputs
Value
4
B57500M
Celsius/Fahrenheit
-55°C/-67°F to +155°C/311°F
±0.5°C / 0.9°F
Min: 25*
Max: 300**
Table 4.7. Relays
Value
8
250V AC
10A
15A
10A
Table 4.8. Analog outputs
Value
2
0 to 10V DC
30 Oct 2023
- 16 -
