BUILT-IN ELECTRIC WALL OVEN
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions completely and carefully. Save these
instructions for the local inspector's use. Observe all governing codes
and ordinances.
NOTE TO INSTALLER: Be sure to leave these instructions with the
customer. Keep these instructions for future reference. Product failure
due to improper installation is not covered under the warranty
agreement.
INSTALLATION & USER MANUAL
Write Serial Number here:
____________________________
SEW24SSX
Felix Storch, Inc.
ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit SEW24SSX
Summary of Contents for Summit SEW24SSX
- Page 1 BUILT-IN ELECTRIC WALL OVEN SEW24SSX IMPORTANT SAFETY INSTRUCTIONS Read these instructions completely and carefully. Save these instructions for the local inspector’s use. Observe all governing codes and ordinances. NOTE TO INSTALLER: Be sure to leave these instructions with the customer. Keep these instructions for future reference. Product failure due to improper installation is not covered under the warranty agreement.
-
Page 2: Table Of Contents
Table of Contents SAFETY AND WARNINGS ............4-7 INSTALLING OVEN INTO KITCHEN ..........8 CONTROL PANEL DESCRIPTION ........... 9 OPERATION INSTRUCTIONS ............10 CLOCK SETTINGS ....................10 FUNCTION SETTINGS ..................10-11 LIGHTBULB SETTING ..................... 12 INQUIRY FUNCTION ....................12 CHILD LOCK FUNCTION ..................13 TIMER FUNCTION .................... -
Page 3: Safety And Warnings
Safety & Warnings WARNINGS These are the most critical warnings summarized below. WARNING • Make sure the appliance is properly installed and grounded by a qualified technician. • When the oven is first switched on, it may give off an unpleasant smell. - Page 4 Safety & Warnings • Do not allow children to go near the oven when it is operating. • Children should be supervised to ensure that they do not use or play with the appliance. • All wiring and electrical connections should be installed to local code.
- Page 5 Safety & Warnings • DO NOT use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass; such cleaners and tools can scratch the surface, which may result in shattering of the glass. • DO NOT use a steam cleaner to clean the appliance. •...
- Page 6 Safety & Warnings • Flammable materials should NOT be stored in an oven or near surface units. • DO NOT USE WATER ON GREASE FIRES. Smother fire or flame or use dry chemical or foam-type fire extinguisher. • Kitchens are an active work environment, and as such, we recommend wearing appropriate...
-
Page 7: Installing Oven Into Kitchen
Installing Oven into Kitchen The oven can be installed underneath a work top or into an upright cupboard. Affix the oven into position by screwing it into place, using the two screw holes in the frame. To locate the screw holes, open the oven door and look inside. To allow adequate ventilation, the measurements and distances must be adhered to when fixing the oven. -
Page 8: Control Panel Description
Control Panel Description Symbol Function Description Oven Lamp: Allows the user to observe the food inside of the oven, through the window. Oven lamp will light for all cooking functions. Defrost: The circulation of air at room temperature allows for quicker thawing of frozen food, without the use of any heat. -
Page 9: Operation Instructions
Operation Instructions Clock Settings After connecting the unit to the power, the numbers "12:00" will show on the display. 1.) Press " ", the hour number will flash. 2.) Press " " to adjust the hour number; time should be within numbers 0 through 12. -
Page 10: Function Settings
Operation Instructions Function Settings • After connecting the unit to the power, the numbers "12:00" will flash on the display. • When adjusting the clock time or the timer, the increments will change after 30 minutes: 0--0:30 min: increases by 1 minute 0:30--9:00 hours: increases by 5 minutes •... -
Page 11: Lightbulb Setting
Operation Instructions Lightbulb Setting 1.) Press " " to select a function, and the corresponding icon will light up. 2.) Press " " button to start, " 0:00 " and icon " " will light up, " : " will start blinking. Inquiry Function During the following functions, you can use the inquiry function;... -
Page 12: Child Lock Function
Operation Instructions Child Lock Function To Lock: Press " " and " " simultaneously for 3 seconds, there will be a long beeping sound and the “ “ symbol will light up. To Unlock: Press " " and " " simultaneously for 3 seconds, there will be a long beeping sound indicating the Child Lock has been unlocked. -
Page 13: Timed Cooking Function
Operation Instructions Timed Cooking Function This function can only be used once the Clock has been set up on the appliance and the unit is in standby mode: 1.) Press " " twice. The display will show “ " and "End". 2.) Press "... -
Page 14: Energy-Saving Function
Operation Instructions Energy-Saving Function This oven has an energy-saving function. This function can only be set when the oven is in Standby Mode. To start energy-saving mode: 1.) In standby mode, press "Start" for three seconds, the LCD display will turn off and the unit will enter energy-saving mode. -
Page 15: Accessories
Accessories Wire Shelf For grilling, dishes, or cake pans with items that will be grilled and/or roasted. Slider Shelf For cooking larger-sized food, these shelf support rails on the right and left sides of the oven can be removed, so dishes and trays can be placed on the oven floor to use functions such as Radiant Grilling, Double Grilling, and Double Grill with Fan. -
Page 16: Shelf Placement Warning
Shelf Placement Warning Shelf Placement Warning To ensure the oven shelves are used safely, correct shelf placement between the side rails is important. Shelves and pans only can be used between the first and fifth layers. The shelves should be used correctly with the side rails, as it will ensure that during careful removal of the shelf or tray and so any hot food will not slide out and cause injuries. -
Page 17: Lightbulb Replacement
Lightbulb Replacement Lightbulb Replacement 1.) Disconnect the power to the main outlet or shut off the circuit breaker to the unit’s power supply. 2.) Unscrew the glass lamp cover by turning it counter-clockwise (NOTE: It may be stiff) and replace the lightbulb with a new one of the same type. -
Page 18: Securing The Oven To The Cabinet
Securing the Oven to the Cabinet Securing the Oven to the Cabinet 1.) Place the oven in the cabinet recess. 2.) Open the oven door. 3.) Secure the oven to the kitchen cabinet using the two spacers " A " which fit inside the holes in the oven frame. Then insert the two screws "... -
Page 19: Ventilation Openings
Ventilating Openings When cooking is finished, paused, or the unit is in Standby Mode -AND- if the oven's center temperature is over 160 degrees, the cooling fan will continue working for 15 minutes, - OR- when the oven's center temperature becomes lower than 160 degrees, the cooling fan will stop working. -
Page 20: Electrical Connection
Electrical Connection This appliance must be properly installed and grounded by a qualified technician. Ask your dealer to recommend a qualified technician or an authorized repair service. This appliance is manufactured with a green GROUND wire connected to the oven chassis. After making sure that the power has been turned off, connect the flexible conduit from the oven to the junction box using a U.L. - Page 21 Electrical Connection Wire Branch Circuit Refer to Figure: • Disconnect ground from neutral at free end of the conduit. • Connect the green GROUND wire from the oven to the GROUND wire in the junction box (bare or green-colored wire). •...
- Page 22 Electrical Connection IMPORTANT: Use twist-on connector with square-wire spring Square-wire spring From power supply Terminal Block From the oven...
-
Page 23: Oven Installation
Oven Installation 22" 23.4" 21.8" 0.78" 23.4" 3.1" 9.84" 3.93" 23.6" 24.7" min. 22" 23.8" NOTES: • Only deviations that add clearance space are allowed for all dimensions. • The cabinet does not include the power switch or socket. • The number of accessories included depends on the appliance purchased. -
Page 24: Removing The Oven Door
Removing the Oven Door The removable oven door allows full access to entire interior of the oven for easier and quicker maintenance. 1.) To remove the door, open the door to the maximum angle. Then Figure 1 pull the buckle at the door hinge backward. -
Page 25: Cleaning And Maintenance
Cleaning & Maintenance To keep the appliance looking good and performing well, we strongly recommend keeping the unit clean. While the modern design of the appliance keeps maintenance to a minimum, the parts of the unit that come into contact with food must be cleaned regularly. - Page 26 NOTES...
-
Page 27: Warranty And Service
WARRANTY AND SERVICE... -
Page 28: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
