Summary of Contents for SnowWolf QuattroPlow HD
- Page 1 Operation & Maintenance Manual QuattroPlow ™ Model HD HD Models 15,000 - 30,000 lb. REMEMBER: Register your product! No claims for warranty shall be considered unless your product registration card is completed online within 30 days of purchase. Go to: snowwolfplows.com/registration. 2023 Rev 2.2...
- Page 2 SNOWWOLF. SNOWWOLF'S liability for any defect with respect to accepted goods shall be limited to repairing the goods at a SNOWWOLF designated location or at an authorized dealer location, or replacing them as SNOWWOLF shall elect.
-
Page 3: Table Of Contents
..............26 QuattroPlow HD Operation and Maintenance Manual... - Page 4 ............49 QuattroPlow HD Operation and Maintenance Manual...
-
Page 5: Introduction
SnowWolf is continually working to improve its NOTE: This document and the information products. SnowWolf reserves the right to make provided are the property of SnowWolf... -
Page 6: Attachment Identification, Hd Models
CUTTING BLADE CUTTING EDGE EDGE CUTTING EDGE RH WING CYLINDER RIGHT WING HYDRAULIC RH WING MANIFOLD FRONT CUTTING EDGE BLADE MARKER TRIP GUIDE SPRINGS ANGLE ATTACHMENT CYLINDER MOUNTING FRAME TRIP LH WING SPRINGS CYLINDER QuattroPlow HD Operation and Maintenance Manual... -
Page 7: Safety
Safety Safety Information Safe Operation Needs A Qualified Operator Safety Alert Symbol This SAFETY ALERT SYMBOL identifies important safety messages AVOID SERIOUS INJURY OR DEATH equipment and in the owner’s manual. When you see this symbol, be alert to the Operators must receive instructions before possibility of personal injury and carefully operating the machine. -
Page 8: Importance Of Safety
Safety Importance of Safety • DO NOT modify the equipment in any way. Unauthorized modification may impair the function and / or safety and could affect the life Operating Safety of the equipment. • Read and follow instructions in this manual and •... - Page 9 Safety Importance of Safety Cont’d Hydraulic Safety • Always disconnect hydraulic connections Fire Prevention Safety between the machine and the QuattroPlow before performing maintenance • All fuels, most lubricants and some coolant QuattroPlow. mixtures are flammable. Flammable fluids that are leaking or spilled onto hot surfaces or onto •...
- Page 10 Quatro Plow HD Operation and Maintenance Manual...
-
Page 11: Operation
Make sure hoses are routed and secured to avoid pinch points or strain during movement of the machine/attachment. 9. Check cutting blade for wear or damage. 10. Check hydraulic lines, connections and fittings for hydraulic oil leaks. QuattroPlow HD Operation and Maintenance Manual... -
Page 12: Attachment Inspection
Inspect the pins and mount • Stop the engine and remove the key. (on the attachment) for wear or damage. SEE MACHINE’S OPERATOR’S MANUAL Repair or replace damaged parts if necessary. FOR ADDITIONAL INFORMATION. QuattroPlow HD Operation and Maintenance Manual... -
Page 13: Attachment Installation
Wait for all moving parts to stop. back until the QuattroPlow is slightly off the SEE MACHINE’S OPERATOR’S MANUAL ground and attachment mounting frame fully FOR ADDITIONAL INFORMATION. contacts the front of the machine’s mounting plate. QuattroPlow HD Operation and Maintenance Manual... -
Page 14: Hydraulic Couplers
NOTE: DO NOT hammer on or heat up couplers to connect or disconnect. Engage machine’s locking levers / wedges (See Doing will damage couplers the machine's Operator’s Manual for detailed resulting in leaks. information). QuattroPlow HD Operation and Maintenance Manual... -
Page 15: Checking Quattroplow Operation
AVOID INJURY OR DEATH • Never start the machine from outside the cab. • Never operate the machine if any safety device is damaged, disconnected or missing. • Never exit the machine with the engine running. QuattroPlow HD Operation and Maintenance Manual... -
Page 16: Operating The Attachment
NOTE: Always be sure the A-frame of your QuattroPlow is level (parallel) with the ground when plowing, to insure proper cutting edge wear. NOTE: The machine speed is determined by the depth and density of the material being moved. QuattroPlow HD Operation and Maintenance Manual... -
Page 17: Attachment Removal
Disconnect the auxiliary hydraulic hoses. (See the machine’s mounting plate. “Hydraulic Couplers” on page 12.) Drive the machine slowly backward, away from Disengage the attachment locking levers / the attachment. wedges. (See the machine’s Operator’s Manual for correct procedure.) QuattroPlow HD Operation and Maintenance Manual... - Page 18 QuattroPlow HD Operation and Maintenance Manual...
-
Page 19: Maintenance
Make sure the machine’s wheels are blocked. • Never work under the machine or attachment unless the machine or equipment is blocked or supported securely. QuattroPlow HD Operation and Maintenance Manual... -
Page 20: General Maintenance
Safety signs and reflectors for damage. Replace any missing or damaged decals. • Cutting edge for wear or damage. • Hydraulic hoses and fittings for wear, damage or leaks. NOTE: Repair or replace any damaged parts. QuattroPlow HD Operation and Maintenance Manual... -
Page 21: Quattroplow Maintenance
Apply 1-2 pumps of grease to the wing cylinder to the QuattroPlow. ends (Item 2) [Figure 1] both sides every 40 hours of operation. AVOID SERIOUS INJURY OR DEATH Securely block up the attachment before working underneath. QuattroPlow HD Operation and Maintenance Manual... -
Page 22: Cutting Edge Replacement
NOTE: Use grease or “Anti Seize” on the rod cutting edge. and jam nut to prevent rusting. NOTE: Be cautious as the cutting edge and NOTE: Adjust trip springs evenly on both hardware may be sharp. sides. QuattroPlow HD Operation and Maintenance Manual... -
Page 23: Side Wing Cutting Edge Replacement
Remove the three nuts and bolts (Item 1) [Figure 4], hold down strip (2) and inner cutting edge (Item 3). Install new cutting edge, hold down strip, nuts and bolts. Tighten hardware. Repeat procedures on the opposite side. QuattroPlow HD Operation and Maintenance Manual... -
Page 24: Troubleshooting
Auto wing manifold. for valve adjustment. dragging. Lubricate and free wing hinge Wing hinge pin seized. QuattroPlow wing will not pin. move or moves slow. Faulty wing cylinder. Replace wing cylinder. QuattroPlow HD Operation and Maintenance Manual... -
Page 25: Storage And Return To Service
Check that all decals and/or reflectors are in good condition and legible. Replace any damaged or missing decals. • Cap all loose hose ends. • Place the QuattroPlow in a dry protected shelter. NOTE: Replace or repair any damaged parts QuattroPlow HD Operation and Maintenance Manual... - Page 26 QuattroPlow HD Operation and Maintenance Manual...
-
Page 27: Parts
Parts This page left intentionally blank QuattroPlow HD Operation and Maintenance Manual... -
Page 28: Models Qphd146, Qphd170
Parts Models QPHD146, QPHD170 Parts 12 13 1.10 QuattroPlow HD Operation and Maintenance Manual... - Page 29 BOLT, HEX, 3/8” x 6-1/2”, GR 5 P80002 PIN, UPPER PIVOT, 1.75” x 6.00” P60209 WASHER, FLAT, 1/2” USS P60094 BOLT, HEX, 5/16-18 x 2-1/2”, GR 5 P80116 WASHER, CUSTOM, LOWER PIVOT P60084 SPRING, HOSE HOLDER P60088 WASHER, FLAT, 3/8” QuattroPlow HD Operation and Maintenance Manual...
- Page 30 Parts Models QPHD146, QPHD170 (Cont’d) Parts (Cont’d) 12 13 1.10 QuattroPlow HD Operation and Maintenance Manual...
- Page 31 BOLT, HEX, 3/8”-16 x 2”, YELLOW ZINC, GR 8 For items above 24: See “Options (QPHD Models)” on page 30. For hydraulic hoses: See “Hydraulic Hoses (QPHD Models)” on page 34. For hydraulic components: See “Hydraulic Components (QPHD Models)” on page 35. QuattroPlow HD Operation and Maintenance Manual...
-
Page 32: Options (Qphd Models)
CARBIDE ActivEdge, AR400 WITH CARBIDE, SEE PAGE 39 P80124-A-SEC 10’ COMPLETE KIT P80124-B-SEC 12’ COMPLETE KIT P80124-A-REK 10’ REPLACEMENT CARBIDE EDGES w/ HW P80124-B-REK 12’ REPLACEMENT CARBIDE EDGES w/ HW SPILL GUARD (OPTION) P80102-K SPILL GUARD, 10’ P80103-K SPILL GUARD, 12’ QuattroPlow HD Operation and Maintenance Manual... - Page 33 Parts This page left intentionally blank QuattroPlow HD Operation and Maintenance Manual...
-
Page 34: Side Wing (Qphd Models)
Parts Side Wing (QPHD Models) QuattroPlow HD Operation and Maintenance Manual... - Page 35 WING EDGE, STEEL, RIGHT SIDE P25562 GREASE ZERK, 3/16” POUND IN P80062 HOLD DOWN STRIP, (REAR ONLY) P80084 WING, QUATTRO PLOW HD, RIGHT REAR WELDMENT For hydraulic hoses: See “Hydraulic Hoses (QPHD Models)” on page 34. QuattroPlow HD Operation and Maintenance Manual...
-
Page 36: Hydraulics Qphd146, Qphd170
PART # DESCRIPTION P50008 HOSE, 3/8” x 78”, 4800 PSI, 6FJIC-8FJIC P50008-D HOSE, 3/8” x 94”, 4800 PSI, 6FJIC-8FJIC P60082 HOSE, 3/8” x 38”, 4800 PSI, 6FJIC-6FJIC P80065 HOSE, 90DEG, 3/8” x 38.5”, 1AAFJ6-1AAFJB6 QuattroPlow HD Operation and Maintenance Manual... -
Page 37: Hydraulic Components (Qphd Models)
FITTING, #8 MJIC - #8MORB, STR P25562 GREASE ZERK, 3/16” POUND IN P80051-K MANIFOLD, AUTOWING ASSY, HD W/VALVES (with fittings) See page 37 P80057-K POWERWING MANIFOLD WITH FITTINGS & DIODE HARNESS See page 38 QuattroPlow HD Operation and Maintenance Manual... -
Page 38: Decal Identification (Qphd Models)
DECAL, “PATENTS PENDING” BLACK DC79 DECAL, WOLFHEAD, LARGE, LEFT SIDE, QPHD DC28 DECAL, SNOWWOLF, MOLDBOARD LEFT DC29 DECAL, WOLFHEAD, MOLDBOARD RIGHT DC68 DECAL, TAG US, BLACK W/YELLOW P20019 DECAL, “DANGER PINCH AREA” SWSN DECAL, SERIAL # QuattroPlow HD Operation and Maintenance Manual... -
Page 39: Options
CROSS OVER RELIEF VALVE, 2750 PSI P60126 WING CONTROL VALVE, 2250 PSI P60069 FITTING, #6MORB - #6MJIC, STRAIGHT P38078 FITTING, #6MJIC - #6 FJIC, 45 DEG P80060 FITTING, TEE P81009 FITTING, STRAIGHT CONNECTOR, RESTRICTED, .095 QuattroPlow HD Operation and Maintenance Manual... -
Page 40: Power Wing Upgrade Qphd-Pw (Hd Models)
SOLENOID VALVE & E-COIL P60069 FITTING, #6MORB - #6MJIC, STRAIGHT P38078 FITTING, 45 DEG, #6MJIC - #6 FJIC P80060 FITTING, TEE P60132 CROSS OVER RELIEF VALVE, 2750 PSI P81009 FITTING, STRAIGHT CONNECTOR, RESTRICTED, .095 QuattroPlow HD Operation and Maintenance Manual... -
Page 41: Activedge
BOLT, CARRIAGE, 5/8-11 x 3" P80107 BUSHING, STANDOFF P80108 SPRING, FOAM P60255 RETAINING WELDMENT, SINGLE P60252 P80109 AR400 BLADE, SINGLE P80106 P80109-CARB CARBIDE BLADE, SINGLE P80106-CARB P80112-K AR400 KIT, SINGLE SECTION P80110-K P80112-CARB-K CARBIDE KIT, SINGLE SECTION P80110-CARB-K QuattroPlow HD Operation and Maintenance Manual... -
Page 42: Spill Guard
P80102-L SPILL GUARD, LEFT 10 FT. P80102-R SPILL GUARD, RIGHT 10 FT. P80103-K SPILL GUARD KIT 12 FT for QPHD-170 w/ HW P80103-L SPILL GUARD, LEFT 12 FT. P80103-R SPILL GUARD, RIGHT 12 FT. QuattroPlow HD Operation and Maintenance Manual... -
Page 43: Mount, Mt100 Kit, Cat-It
BOLT, HEX, 1-1/2”-6 X 8”, GRADE 8 P80072 MOUNT PLATE, ALPHA CAT IT LEFT SIDE P80073 MOUNT PLATE, ALPHA CAT IT RIGHT SIDE P80088 NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80096 WISHBONE, MOUNTING PLATE KEEPER QuattroPlow HD Operation and Maintenance Manual... -
Page 44: Mount, Mt200 Kit, Cat-Fusion
BOLT, HEX, 1-1/2”-6 X 8”, GRADE 8 P80088 NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80096 WISHBONE, MOUNTING PLATE KEEPER P80094 MOUNT PLATE, CAT FUSION, LEFT HAND P80095 MOUNT PLATE, CAT FUSION, RIGHT HAND P81008 MOUNT SPACER, CAT FUSION QuattroPlow HD Operation and Maintenance Manual... -
Page 45: Mount, Mt300 Kit, Jrb-416
BOLT, HEX, 1-1/2”-6 X 12”, GRADE 8 P80088 NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80090 MOUNT PLATE, JRB, RIGHT HAND P80091 MOUNT PLATE, JRB, LEFT HAND P80092 MOUNT SPACER, JRB P80096 WISHBONE, MOUNTING PLATE KEEPER QuattroPlow HD Operation and Maintenance Manual... -
Page 46: Mount, Mt400 Kit
NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80120 UPPER BRACKET CROSSMEMBER P80039 BOLT, HEX, 3/4”-10 X 2-1/2” P20028 NUT, LOCK, 3/4”-10 P80122 3-POINT HITCH, LEFT SIDE P80121 3-POINT HITCH, RIGHT SIDE P81010 MOUNT SPACER, 3-POINT QuattroPlow HD Operation and Maintenance Manual... -
Page 47: Mount, Mt500 Kit, Volvo
NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80096 WISHBONE, MOUNTING PLATE KEEPER P80098 MOUNT PLATE, VOLVO, LEFT HAND P80099 MOUNT PLATE, VOLVO, RIGHT HAND P81005 MOUNT SPACER, VOLVO P81006 BOLT, HEX, 1-1/2”-6 X 16” QuattroPlow HD Operation and Maintenance Manual... -
Page 48: Mount, Mt600 Kit, Universal Weld On
PART # DESCRIPTION UNIVERSAL WELD ON MOUNT (MT600 KIT) (UNPAINTED) P80048 BOLT, HEX, 1-1/2”-6 x 8” P80088 NUT, HEX, NYLOCK, 1-1/2”-6 P80089 WASHER, FLAT, 1-1/2” P80096 WISHBONE P81008 MOUNT SPACER P81012 MOUNT PLATE, FOR UNIVERSAL QuattroPlow HD Operation and Maintenance Manual... -
Page 49: Specifications
Crossover Relief Value Standard Wing Thickness 5/8” Grade 50 Wing Wear Shoes 1” x 8” AR400 Floating Steel Wing Hinge Pin 1-7/8” x 29-3/4” Wing Cylinder 2-1/2” x 8” Double Acting Cylinder PowerWing Upgrade Optional QuattroPlow HD Operation and Maintenance Manual... -
Page 50: Dimensions (Qphd Models)
146” (12’ 2”) 170” (14’ 2”) Maximum Width (C) 176” (14’ 8”) 200” (16’ 8”) Width In Backdrag Position (D) 146” (12’ 2”) 170” (14’ 2”) Blade Height (E) 39” 39” Overall Width (F) 148” 172” QuattroPlow HD Operation and Maintenance Manual... -
Page 51: Torque Specifications
708 ft / lb 773 ft / lb 1000 ft / lb 386 ft / lb 545 ft / lb (289 N•m) (373 N•m) (742 N•m) (960 N•m) (1048 N•m) (1356 N•m) (523 N•m) (739 N•m) QuattroPlow HD Operation and Maintenance Manual... - Page 52 QuattroPlow HD Operation and Maintenance Manual...
- Page 54 15100 Business Parkway, Rosemount, MN 55068 1-800-905-2265 snowwolfplows.com © 2023 SnowWolf...
