Icom IC-M802 Installing page 22

Quick no meter Quick test.
Individually Select 2A, 4A, 6A, 8A, 12A, 16A, 18A, 22A, 25A and complete the steps
below:
1. Select Channel and make sure not in use.
2. Press [Set/Mode] button on to display "FSK"
3. Press [THRU/TUNE] button and make sure display indicates "TUNE". (Signal
Strength bar should indicate one bar while tuning)
4. Press PTT on Microphone
5. Signal Strength should be 8 signal strength bars if antenna system is tuning
properly.
Note: While in a marina
frequently the 2A and 4A
may have less bars as a result
of the signal bouncing back off
other boats. Re check out of the
marina if that occurs. If you are
missing bars, re-test with a SWR
meter in line using the same process
as above.
10/16/2017
RX
L
www.Made-Simplefor-Cruisers.com
TUNE USB
MaritimeNT
118
CH
H
SIMP
- - - GPS - - -
24 o 13.016 N
o
110 19.174W
UTC 16:23
1 1
