Icom IC-M802 Installing page 13

The control head and Speaker cables have snap on ferrite cores at the
OK/NA
transceiver end.
The DERA (DSC antenna) is installed and RG58 cable is ran to the back of
OK/NA the transceiver unit. It is connected to the number 2 antenna connection.
(closest to the center of the transceiver)
The two PL259 connectors for the DERA uses RG58 adapters for the
OK/NA
smaller cable and are soldered both at the center and the shield.
Verify the ohm meter readings on the cable have been recorded and are
OK/NA
within specified values (Step 8 - Installing the Icom IC-M802)
Verify every cable has some sort of ferrite cores installed on both ends:
OK
to/from the transceiver, modem and computer.
Power Testing Results as recorded in Step 15 of Installation
OK The Power out of the radio at maximum power is at least 150 watts
OK The SWR of the radio is less than 1.5 for all bands
