Icom IC-M802 Installing page 15

Metz DSC Antenna and mount with 30 ft. Cable & PL-259 Connector
OK/NA
One ferrite core for up to 17/64" size to be installed on the Metz antenna at the
OK transceiver.
OK/NA HF 23 foot fiberglass antenna and mount
OK/NA GTO-15 antenna lead-in wire long enough to go from AT-140 Tuner to antenna
OR Back Stay Antenna
Modified Stay with 2 insulators installed
OK/NA
OK/NA 3/4 " PVC to construct 3" standoffs for GTO-15 wire on backstay
OK/NA
The GTO-15 to Backstay connector.
GTO-15 antenna lead-in wire long enough to go from AT-140 Tuner to antenna
OK/NA
OK/NA OR GAM/McKim Split Lead Single Sideband Antenna (GTO cable not required)
OK Deck fitting/Clam Clamp for through hole for GTO-15 cable
OK/NA Optional DSP Speaker/Device
Misc. Vulcanizing Tape, electric grease and terminal grease lubricant, Solder, soldering
Iron, SWR / Power meter, Volt Ohm meter, cable ties, tools
OK
In Add Audio Weather Fax
OK Mono audio cable with 3.5mm connectors
Weather Fax software that supports Audio input.
OK
In
Add Email and Weather FAX
OK Pactor Modem (Pactor 4, PTC IIusb or PTC IIpro)
OK/NA USB cable for PTC IIusb
OK/NA RS232 cable with serial to USB adapter for PTC IIpro
OK/NA Control of Frequency by Modem - SCS 8083 six (6) foot Frequency control cable
OK/NA
Control of Frequency by Modem - SCS 8084 12 foot Frequency control cable
OK/NA Control of Frequency by Computer - RS232 cable with serial to USB adapter
OK/NA SCS 9090 six (6) foot Interconnecting cable
OK/NA SCS 9091 six (12) foot Interconnecting cable
(12) ferrite snap on cores for the selected three cables above (cores for up to 17/64" size)
Also called Ferrite Data line filters
OK
OK
Computer capable of running Windows software
Download Airmail for free from Sailmail.com for Sailmail or Windlink email service
OK/NA
Other HF-SSB email service software
OK/NA
OK/NA
Weather FAX software (May be included with Airmail)
