HMS Networks Intesis IN485MIT001I000 Installation Manual page 2

Installation Guide | Publication date: 2024-05-20
DIP Switches
The gateway includes three DIP switches: SW1 (8 switches) at the bottom and SW2 (8 switches)
and SW3 (3 switches) at the top.
Table 1. SW1(P6 to P8): BACnet MS/TP baudrate
Binary value Position
b0 .. b7 1 2 3 4 5
XXXXX000 X X X X X
XXXXX100 X X X X X
XXXXX010 X X X X X
XXXXX110 X X X X X
XXXXX001 X X X X X
XXXXX101 X X X X X
XXXXX011 X X X X X
XXXXX111 X X X X X
Table 2. SW2 (P1 to P7): BACnet MS/TP MAC address; (P8): Temperature unit (°C/°F)
Binary value Position
b0 .. b7 1 2 3 4 5 6
0 0 0 0 0 0 0 X ↓ ↓ ↓ ↓ ↓ ↓ ↓ X
1 0 0 0 0 0 0 X ↑ ↓ ↓ ↓ ↓ ↓ ↓ X
0 1 0 0 0 0 0 X ↓ ↑ ↓ ↓ ↓ ↓ ↓ X
1 1 0 0 0 0 0 X ↑ ↑ ↓ ↓ ↓ ↓ ↓ X
... ...
1 0 1 1 1 1 1 X ↑ ↓ ↑ ↑ ↑ ↑ ↑ X
0 1 1 1 1 1 1 X ↓ ↑ ↑ ↑ ↑ ↑ ↑ X
1 1 1 1 1 1 1 X ↑ ↑ ↑ ↑ ↑ ↑ ↑ X
X X X X X X X 0 X X X X X X
X X X X X X X 1 X X X X X X
Table 3. SW3 (P1 to P3): BACnet polarization and termination resistor
Binary value Position
b0 .. b2 1 2 3
EIA-485 bus without termination resistor. The gateway is not at one
0 X X ↓ X X
120 Ω termination resistor active. The gateway is at one end of the
1 X X ↑ X X
X 0 0 X ↓ ↓
X 1 1 X ↑ ↑
The DIP switches configuration will only take effect after rebooting the gateway.
Dimensions
• Net dimensions (HxW.D):
Millimeters: 93 x 53 x 58 mm
Inches: 3.7 x 2.1 x 2.3"
Leave enough clear space to wire the gateway easily and for the subsequent
manipulation of elements.
Description
6 7 8
↓ ↓ ↓ Autobaudrate (default value)
↑ ↓ ↓ 9600 bps
↓ ↑ ↓ 19200 bps
↑ ↑ ↓ 38400 bps
↓ ↓ ↑ 57600 bps
↑ ↓ ↑ 76800 bps
↓ ↑ ↑ 115200 bps
↑ ↑ ↑ Autobaudrate
MAC
Description
address
7 8
0 -
1 -
2 -
3 -
... -
125 -
126 -
127 -
X ↓ - Temperature in Celsius (default)
X ↑ - Temperature in Fahrenheit
Description
end of the EIA-485 bus (default value)
EIA-485 bus
No bus polarization (default value)
Bus polarization active
© HMS Industrial Networks SLU | www.hms-networks.com
LEDs Information
Two LEDs are placed between SW1 and the AC Unit socket at the gateway's bottom.
LED Status
ON
L1
Flickering
Green
OFF
ON
L2
Blinking
Red
Flashing
LED PATTERNS
• ON: 100% on
• Flickering: irregular cycle (90% on - 10% off approx)
• Blinking: 50% on - 50% off
• Flashing: 10% on - 90% off
• OFF: 100% off
Technical Specifications
Housing
Weight
Terminal wiring
Mounting
EIA-485 port
BACnet MS/TP
AC unit port
LED indicators
DIP switches
Operational and storage
temperature
Operational and storage humidity
Isolation Voltage
Isolation resistance
Disposal and Recycling
This product contains electronic components and must be properly disposed of
according to local laws and regulations. For further information, refer to:
www.intesis.com/weee-regulation
For further information on the installation, connection, and configuration of this gateway, refer to
the User manual.
Description
BACnet
BACnet MS/TP link performed
Activity on the BACnet MS/TP bus
BACnet MS/TP link not performed
AC unit
AC communication error
AC unit error
AC communication OK
Plastic, type PC (UL 94 V-0)
Net dimensions (HxWxD): 93 x 53 x 58 mm / 3.7 x 2.1 x 2.3"
Color: Light grey. RAL 7035
85 g (3 oz)
Wire cross-section/gauge per terminal:
2
One core: 0.2 .. 2.5 mm (24 .. 11 AWG)
2
Two cores: 0.2 .. 1.5mm (24 .. 15 AWG)
Three cores: Not permitted
Use solid or stranded wires (twisted or with ferrule).
Wall, DIN rail, or inside the indoor unit
1 x pluggable terminal block (3 poles: B, A, and SG)
1 x Specific socket
2 x Communication status
SW1: Baudrate configuration
SW2: MAC address and temperature unit
SW3: Bus polarization and termination:
Celsius: Op: 0 to +70°C; St: -20 to 85°C
Fahrenheit: Op: 32 to 158°F; St: -4 to 185°F
5% to 95% RH non-condensing
1500 VDC
1000 MΩ
