6600 REG
6600 X-WIDE
CORNER UPRIGHT NAHL5604
84" 3 x 3
(2) CROSS BEAMS
NAHL6605 W/SINGLE CABLE
6600 LB REG
NAHL5606 W/DOUBLE CABLE
NAHL6605W W/SINGLE CABLE
6600W LB
NAHL5606W W/DOUBLE CABLE
X-WIDE
(2) LONG BEAMS NAHL6610
(2) HL WOOD KEEL BOARDS - LCRKH
(2) CARPETED BUNKS - LFLBL121
WINCH
2501
LWHW25
(4) LEVELING LEGS LLH31
4 Corner Braces
30-1/2" x 3/4" x 3/4"
40" Winch Wheel
- LWWL
HEWITT MACHINE & MFG, INC.
(4) LONG BASES NAHL3807
(2) CROSS BASES NAHL3808
(2) CROSS BASES NAHL3808W
(4) UPRIGHTS
CORNER UPRIGHT NAHL5603
84" 3 x 3
NAHL6611
(4)
(8)
(4)
(1)
(1)
(4)
(8)
(12) 3" x 3" Plastic Plugs – D1PC3SQ
(1)
(1)
(1)
NAHL4609
(1)
(1)
(1)
"Quality Since 1971"
www.hewittrad.com
VERTICAL LIFT PARTS LIST
CORNER WINCH UPRIGHT NAHL5601
(02)
(02)
(02)
(02)
( 0 4 )
( 0 3 )
BED SLIDE BAG – NAHLBSB4
(4)
Bed Slide Bracket - NAHLBSB
HARDWARE IN BAG NAHL6612
3" x 5" Cradle
Blocks – LCRB3X9
3" x 16" x 1/4" Cradle
Side Plates – LCRSP16
6" Aluminum Keel
Plates – LCRKPL
2" Tear Drop Pulley – LIP2T
3/8" x 3-1/2" Chain Bolts – NB38312CH
3/8" X 4" Leg Pins w/Clips – LLP4
1/2" Nuts (Steel) – NN12S
Assembly Instructions – NAASSYH66
Moisture Bag
Winch Clamp - LDLWC
3" Sheave - L1PS3
7/8" x 5/8" x 1" Bushing - L1BH1
5/8" x 2-1/2" Shoulder Bolt -NB58212178S
Box 111
Nicollet, MN 56074
PAGE 1
NAASSYH66 | 11-23 | LIFT_VERT_6600_NAASSYH66-66W.INDD
6600 LB. ALUMINUM
(AS OF 2020) L0AH66
120" 3 x 3
120" 3 x 3
126" 3 x 3
84" 3 x 3
CORNER UPRIGHT NAHL5602
115-1/2" 3-3/4 x 7-1/2
(01)
115-1/2" 3-3/4 x 7-1/2
(01)
121-1/2" 3-3/4 x 7-1/2
(01)
121-1/2" 3-1/2 x 7-1/2
(01)
104" 3-1/2 x 3-1/2
( 0 1 )
104" 3-1/2 x 3-1/2
( 0 2 )
2" X 10" X 12'
(1)
Plate with Clevis
– NAHL56PC
(1)
BOLT BOX – NAHL66BB
(50) 3/8" x 1" SS Bolts -NB381G
(4)
3/8" x 2-1/2" SS Carriage Bolts -NB38212C
(2)
3/8" SS Washers -NW38FL
(94) 3/8" Brass Nuts -NN38S
(4)
1/2" Brass Nylock Lock Nuts -NN12N
(4)
1/2" x 2-1/2" SS Bolts -NB12212G
(5)
1/2" SS Washers -NW12FL
(9)
3/8" x 4-1/2" SS Bolts -NB38412G
(20) 3/8" x 5" SS Bolts -NB385G
(8)
3/8" x 10" SS Carriage Bolt -NB3810C
(1-1/2" Threads)
(1)
3/8" x 4" SS Hex - NB384G
(10) 3/8" x 1-1/2" Hex Bolt - NB38112G
(5)
5/8" SS Nut - NN583S
(8)
3/8" Nylock Nuts - NN38N
(507) 225-3421
84" 3 x 3
Advertisement
Related Manuals for HEWITT 6600
Summary of Contents for HEWITT 6600
- Page 1 (10) 3/8" x 1-1/2" Hex Bolt - NB38112G 5/8" x 2-1/2" Shoulder Bolt -NB58212178S 5/8" SS Nut - NN583S 40" Winch Wheel 3/8" Nylock Nuts - NN38N - LWWL "Quality Since 1971" HEWITT MACHINE & MFG, INC. Box 111 Nicollet, MN 56074 (507) 225-3421 www.hewittrad.com PAGE 1...
- Page 2 6600 VERTICAL LIFT ASSEMBLY INSTRUCTIONS NOTES: Each cross base and long base has a number at one end that corresponds to the corner upright it attaches to, NAHL5604 or NAHL5602. Simply match these numbers to assemble the main frame. Use washers on all slotted holes.
- Page 3 Nut Double Sheave, Replacement Sheaves and Bushings 1-1/4" x 3-3/16" Bushing, 6600 HL Sheave and Bushing Kit – L1SH66K 5/8" x 5" Bolt and Nut (Kit includes all Bushings and Sheaves for lift) (Sheaves and Bushings can be order individually) Replacement Bolts and Nuts for Sheaves 5/8"...
- Page 4 6600 REGULAR VERTICAL LIFT CABLE ASSEMBLY INSTRUCTIONS 1. Route cables as shown. 2. Attach cable ends identified in drawing as Cable Attachment (Top View) A, B, C, and D to bottom bracket on corner uprights. (see inset 1). Screw Cable 3. Attach cable ends E, F, G and H to top bracket on corner uprights.
- Page 5 6600 EXTRA WIDE VERTICAL LIFT CABLE ASSEMBLY INSTRUCTIONS 1. Route cables as shown. 2. Attach cable ends identified in drawing as Cable Attachment (Top View) A, B, C, and D to bottom bracket on corner uprights. (see inset 1). Screw Cable 3. Attach cable ends E, F, G and H to top bracket on corner uprights.
- Page 6 6600 VERTICAL LIFT KEEL/CRADLE ASSEMBLY INSTRUCTIONS 1. Attach keel boards and bunks as shown. 2. Adjust as necessary. 3. Insert 3" x 3" plastic plugs in ends of long bases and cross bases. 2-1/2" CARRIAGE BOLTS CARPETED BUNK BUNK SIDE PLATES 3"...
-
Page 7: Warranty
There is no other express warranty. forward as far as possible without over running the lift. (The stem HEWITT Machine and Mfg. Inc. is not liable for incidental should be close to the back of the rear cross arm) or consequential damages or injuries of any kind due •...
