HEWITT L0A14-DW Assembly Instructions

Before beginning assembly, read instructions completely and check to see that you have the following parts:
1 - HARDWARE BAG NAM1450
3 - 18" 1-1/2" x 1-1/2" Legs – LL181
2 - B1200 Winches – LWB12
2 - Winch Bolt Bags – LWBBS
2 - 3/16" x 14' Cables – L1C143
2 - Spinner Knobs – LKNOB
6 - 2" Tear Drop Pulleys – L1P2T
2 - 5/16" 3-Link Chains
Welded – L1PC5/163LW
11 - 1-1/2" x 1-1/2" Black Plastic
Plugs – D1PC1SQ
2 - 3/16" Cable Clamps – L1CC3/16
4 - 1/4" 2-Link Chains – L1PC1/42L
14 - 3/8" Lock Nuts – NN38L
4 - 2 x 4 CARPETED WOOD BUNKS
72" Long NAM1405
STEP 1
Lay the four "H" shaped lift arms flat on the ground as pictured. Be sure the welded-on
spacers (circled) are pointing in the same direction.
Use four / " x 4" bolts and lock nuts to attach the outsides of the lift arms
3
8
to the 1-1/2" sq. side frames. Use the two
nuts to attach the insides of the lift arms to the 1-1/2" sq.
middle frame. Do not overtighten lock nuts –
Lift arms must move freely. (Be sure that
the left and right sides are positioned
correctly. The offset boxes at the ends
of each side must face outward).
OFFSET
3/8" x 4" BOLT
HEWITT MACHINE & MFG, INC.
1 - Assembly Sheet – NAASSY14
1 - Moisture Bag
1 - BOLT BAG – NA14DWBB
11 - 1/2" x 1-1/2" Set Screws – LLSS
12 - 3/8" x 2-1/2" Bolts – NB38212G
4 - 3/8" x 3-1/2" Bolts – NB38312G
4 - 3/8" x 4" Bolts – NB384G
2 - 3/8" x 6-1/2"- Bolts – NB38612G
8 - 3/8" x 2-1/2" Carriage
Bolts – NB38212C
4 - 3 / 8 " x 4 " C a r r i a g e B o l t s – N B 3 8 4 C
6 - 3/8" Washers – NW38FL
20 - 3/8" Nuts – NN38S
/ " x 6-1/2" bolts and two lock
3
8
OFFSET
/ " x 4
3 "
8
LOCK NUT
3/8" x 6-1/2" BOLT
"Quality Since 1971"
www.hewitt-roll-a-dock.com
PERSONAL MINI LIFT ASSEMBLY
4 - LIFT ARMS NAM0706
3 - SIDES
Left: NAM0708L 1-1/2" sq.
Right: NAM0708R 1-1/2" sq.
Middle: NAM0708M 1-1/2" sq.
NAM0708L
/
1
1 " Square
2
/ " x 6-1/2
3 "
8
3 / " x 4 "
8
LOCK NUT
Box 111 Nicollet, MN 56074
e-mail: info@hewitt-roll-a-dock.com
NAASSY14 | 10-11 | LIFT_MINI_ NAASSY14.INDD
1400 LB. DOUBLE WINCH
INSTRUCTIONS
2 - FRONT BRACE
2 - WINCH
WHEEL
LWWS
NAM0708M
1 /
1 " Square
2
/ " x 4
3 "
8
/ " x 6-1/2
3 "
8
OFFSET
LOCK NUT
(507) 225-3421
L0A14-DW
NAM0703
2 - TOP FRAME
NAM0702
NAM0708R
1 /
1 " Square
2
/ " x 4
3 "
8
3/8" x 4" BOLT
