4600 REG
4600 X WIDE
(4) UPRIGHTS
CORNER UPRIGHT NAHL3804
84" 3 x 3
(2) CROSS BEAMS
4600 LB
REG
4600W LB
X-WIDE
(2) LONG BEAMS
(2) WOOD KEEL BOARDS - LCRK
(2) CARPETED BUNKS - LFLB121
(4) LEVELING LEGS LLH31
(1) 40" WINCH WHEEL
LWWL
(4) CORNER BRACES
NAHL4609
30-1/2" x 3/4" x 3/4"
"Quality Since 1971"
HEWITT MACHINE & MFG, INC.
www.hewittrad.com
PAGE 1
(4) LONG BASES NAHL3807
(2) CROSS BASES NAHL3808
(2) CROSS BASES NAHL3808W
#3
CORNER UPRIGHT NAHL3803
84" 3 x 3
NAHL4605 W/SINGLE CABLE
NAHL4606 W/DOUBLE CABLE
NAHL4605W W/SINGLE CABLE
NAHL4606W W/DOUBLE CABLE
NAHL4610
(4)
30"
(8)
2-5/8"
x
(4)
2-5/8"
(4)
(1)
(1)
(1)
(4)
(14) 1/2" Nuts (Steel) – NN12S
(12) 3" x 3" Plastic Plugs – D1PC3SQ
(1)
(1)
(1)
(1)
(1) WINCH 2001
LWHW20
Box 111
Nicollet, MN 56074
VERTICAL LIFT PARTS LIST
CORNER WINCH UPRIGHT NAHL3801
#1
#2
(02)
(04)
(02)
(04)
107-5/8" 1-1/4" x 5
BED CORNER AND SLIDE BAG - NAHLCHB
HL Bed Slide Bracket - NAHLBSB
HARDWARE IN BAG NAHL4612
3" x 14" x 1/4" Cradle
Side Plates – LCRSP14
2" x 2" Cradle Blocks – LCRB2
Reinforcement
Plate – LCRKP
2" Tear Drop Pulley – LIP2T
3/8" x 3-1/2" Chain Bolts – NB38312CH
Spinner Knob Only – LKNOB1
3/8" X 4" Leg Pins w/Clips – LLP4
Assembly Instructions – NAASSYH26
Winch Instruction – WHWI
Moisture Bag
Winch Clamp - LDLWC
(507) 225-3421
NAASSYH46 | 12-23 | LIFT_VERT_4600_NAASSYH46.INDD
4600 LB. ALUMINUM
(AS OF 2021) L0AH46
120" 3 x 3
120" 3 x 3
126" 3 x 3
84" 3 x 3
CORNER UPRIGHT NAHL3802
84" 3 x 3
Note: Numbers are
engraved in the
#1
bottom of corner
posts.
115-1/2" 2 x 6-1/4
(01)
115-1/2" 2 x 6-1/4"
(03)
121-1/2" 2 x 6-1/4
(01)
121-1/2" 2 x 6-1/4"
(03)
24"
2" X 6" X 12'
(4)
Inside Corner Bracket - NAHLICB
(1)
BOLT BOX – NAHL46BB
(48) 3/8" x 1" SS Bolts - NB381G
(2)
3/8" x 1-1/4" SS Bolt - NB38114FT
(4)
3/8" x 2" SS Bolts - NB382G
(1)
3/8" x 2-1/2" SS Bolt - NB38212G
(8)
3/8" x 3" SS Bolts - NB383G
(12) 3/8" X 3-1/2" SS Botls - NB38312G
(2)
3/8" x 4" SS Bolts - NB384G
(4)
3/8" x 2-1/2" SS Carriage Bolts - NB38212C
(8)
3/8" x 8-1/2" SS Carriage Bolts - NB38812C
(3)
3/8" SS Washers - NW38FL
(90) 3/8" Brass Nuts - NN38S
(4)
1/2" x 2-1/2" SS Bolts - NB12212G
(5)
1/2" SS Washers - NW12FL
(8)
3/8" x 1-1/2" SS Bolts - NB38112G
(8)
Nylock Nuts - NN38N
