Installation manual Daikin room air conditioner Installation manual FTXTP25A5V1B English Daikin room air conditioner FTXTP35A5V1B... -
Page 2: Table Of Contents
▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). 12 Technical data ▪ The full set of the latest technical data is available on the Daikin 12.1 Wiring diagram ................10 Business Portal (authentication required). -
Page 3: About The Box
To remove the accessories from the indoor unit 1 Remove: ▪ the accessory bag located at the bottom of the package, ▪ the mounting plate attached to the back of the indoor unit. FTXTP-A Installation manual Daikin room air conditioner 3P769578-2C – 2024.05... -
Page 4: About The Unit
INFORMATION: Declaration of conformity relative humidity of 80%, or when fresh air is inducted into the ▪ Daikin Industries Czech Republic s.r.o. declares that wall, then additional insulation is required (minimum 10 mm the radio equipment type inside of this unit is in thickness, polyethylene foam). -
Page 5: To Drill A Wall Hole
2 Insert a wall embedded pipe into the hole. 3 Insert a wall cover into the wall pipe. 2 Remove any burrs along the cut section using a half round needle file. Wall embedded pipe Putty FTXTP-A Installation manual Daikin room air conditioner 3P769578-2C – 2024.05... -
Page 6: Connecting The Drain Piping
▪ Foreign materials inside pipes (including oils for fabrication) must be ≤30 mg/10 m. Refrigerant piping diameter Use the same diameters as the connections on the outdoor units: Installation manual FTXTP-A Daikin room air conditioner 3P769578-2C – 2024.05... -
Page 7: Refrigerant Piping Insulation
This could result in electrical shock or fire. WARNING Keep the interconnection wiring away from copper pipes without thermal insulation as such pipes will be very hot. FTXTP-A Installation manual Daikin room air conditioner 3P769578-2C – 2024.05... -
Page 8: Specifications Of Standard Wiring Components
Note: In case the interconnection cable was stripped in advance, cover the ends with insulating tape. 4 Bend the end of the cable up. Installation manual FTXTP-A Daikin room air conditioner 3P769578-2C – 2024.05... -
Page 9: Finishing The Indoor Unit Installation
Next commissioning instructions in this chapter, a general commissioning checklist is also available on the Daikin Business Portal (authentication required). The general commissioning checklist is complementary to the instructions in this chapter and can be used as a... -
Page 10: Checklist Before Commissioning
Daikin website (publicly accessible). The insulation resistance of the compressor is OK. ▪ The full set of the latest technical data is available on the Daikin Business Portal (authentication required). There are NO damaged components or squeezed pipes on the inside of the indoor and outdoor units. - Page 11 Magnetic relay Neutral n=*, N=* Number of passes through ferrite core Pulse-amplitude modulation PCB* Printed circuit board Power module Switching power supply PTC* PTC thermistor Insulated gate bipolar transistor (IGBT) FTXTP-A Installation manual Daikin room air conditioner 3P769578-2C – 2024.05...
- Page 12 DAIKIN ISITMA VE SOĞUTMA SİSTEMLERİ SAN.TİC. A.Ş. Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak, No:20, 34848 Maltepe İSTANBUL / TÜRKİYE Tel: 0216 453 27 00 Faks: 0216 671 06 00 Çağrı Merkezi: 444 999 0 Web: www.daikin.com.tr 3P769578-2C 2024.05...
