- Page 1 User reference guide Daikin room air conditioners FTXTP25M5V1B FTXTP35M5V1B FTXTP25N5V1B FTXTP35N5V1B...
-
Page 2: Table Of Contents
Symptoms that are NOT system malfunctions....................... 38 8.1.1 Symptom: A sound like water flowing is heard ..................... 38 8.1.2 Symptom: A blowing sound is heard......................38 8.1.3 Symptom: A ticking sound is heard........................ 38 User reference guide FTXTP-M_FTXTP-N Daikin room air conditioners 4P728152-3 – 2023.03... - Page 3 Symptom: The outdoor fan rotates while the air conditioner is not in operation ........39 Solving problems based on error codes ......................... 39 Troubleshooting for wireless LAN connection ....................... 40 9 Disposal 10 Glossary FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 4: About The Documentation
User reference guide: Detailed step-by-step instructions and background information for basic and advanced usage Format: Digital files on https://www.daikin.eu. Use the search function find your model. Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. - Page 5 Example: " 1–3 Figure title" means "Figure 3 in chapter 1". Indicates a table title or a reference to it. Example: " 1–3 Table title" means "Table 3 in chapter 1". FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 6: User Safety Instructions
Do NOT place any objects containing water on the unit. CAUTION ▪ Do NOT place any objects or equipment on top of the unit. ▪ Do NOT sit, climb or stand on the unit. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 7: Instructions For Safe Operation
The refrigerant inside this unit is mildly flammable. CAUTION Do NOT insert fingers, rods or other objects into the air inlet or outlet. When the fan is rotating at high speed, it will cause injury. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 8 CAUTION Do NOT operate the system when using a room fumigation-type insecticide. Chemicals could collect in the unit, and endanger the health of people who are hypersensitive to chemicals. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
- Page 9 If damaged, the unit may fall and result in injury. CAUTION Do NOT touch the heat exchanger fins. These fins are sharp and could result in cutting injuries. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
- Page 10 Stop operation and shut OFF the power if anything unusual occurs (burning smells etc.). Leaving the unit running under such circumstances may cause breakage, electrical shock or fire. Contact your dealer. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 11: About The System
INFORMATION The following figures are just examples and may NOT completely match your system layout. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 12: Indoor Unit Display
▪ Curtains. Make sure that curtains or other objects do NOT block the signal between the unit and the wireless remote control. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 13: Components: Wireless Remote Control
Automatic operation mode button l LCD display 3.2.2 Status: Wireless remote control LCD Icon Description Operation mode = Automatic Operation mode = Drying Operation mode = Heating Operation mode = Cooling FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 14: To Operate The Wireless Remote Control
Result: When the indoor unit receives a signal from the wireless remote control, you will hear a sound: Sound Description Beep-beep Operation starts. Beep Setting changes. Long beep Operation stops. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 15: Before Operation
1 Choose a place where the signals reach the unit. 2 Attach the holder with screws to the wall or a similar location. 3 Hang the wireless remote control on the holder. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 16: To Turn On The Power Supply
4.4 To turn on the power supply 1 Turn the circuit breaker on. Result: The flap of the indoor unit will open and close to set the reference position. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 17: Operation
To adjust the airflow direction (swing or fixed Airflow direction position). To adjust the amount of air blown into the Airflow rate room. To run more quietly. Advanced features FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 18: Operation Mode And Temperature Setpoint
In that case, the system automatically switches to defrosting operation to remove the frost. During defrosting operation, hot air is NOT blown from the indoor unit. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 19: To Start/Stop Operation Mode And To Set The Temperature
5 airflow rate levels, from " " to " " Automatic airflow rate operation Indoor unit quiet operation. When the airflow rate is set to " ", the noise from the unit will be reduced. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 20: To Adjust The Airflow Rate
Flap range in cooling or drying operation b Flap range in heating operation c Flap range in fan only operation FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 21: To Adjust Vertical Airflow Direction
Powerful and Comfort airflow operation CANNOT be used at the same time. The last selected function takes priority. If the vertical automatic swing is selected, Comfort airflow operation will be cancelled. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 22: To Start/Stop Comfort Airflow Operation
Result: is displayed on the LCD. Powerful operation runs for 20 minutes; after that, operation returns to the previously set mode. 2 Press to stop. Result: disappears from the LCD. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 23: Econo Operation
5.9 OFF/ON timer operation Timer functions are useful for automatically switching the air conditioner off/on at night or in the morning. You can also use OFF timer and ON timer in combination. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 24: To Start/Stop Off Timer Operation
1 hour. The timer can be set between 1 to 12 hours. Example: If is set when the unit is NOT operating, operation will start after 2 hours. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 25: To Combine Off Timer And On Timer
▪ Auto-control equipment. E.g. automatic doors or fire alarm equipment. This product may cause faulty behaviour of the equipment. ▪ Microwave oven. It may affect wireless LAN communications. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 26: To Install The Onecta App
2 Follow the directions on the screen to install the ONECTA app. INFORMATION Scan the QR code to download and install the ONECTA app on your mobile phone or tablet: FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 27: Energy Saving And Optimum Operation
Adjust the air flow direction to avoid cool air from gathering on the floor or warm air against the ceiling. (Up during cooling or dry operation to the ceiling and down during heating operation.) ▪ Avoid direct air flow to room inhabitants. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 28 Energy saving and optimum operation ▪ Operate the system within the recommended temperature range (26~28°C for cooling and 20~24°C for heating) to save energy. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 29: Maintenance And Service
DANGER: RISK OF ELECTROCUTION To clean the air conditioner or air filter, be sure to stop operation and turn all power supplies OFF. Otherwise, an electrical shock and injury may result. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 30: To Clean The Indoor Unit And Wireless Remote Control
Contact your dealer. 1 Clean with a soft cloth. If it is difficult to remove stains, use water or a neutral detergent. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 31: To Clean The Front Panel
1 Push the tab at the centre of each air filter, then pull it down. 2 Pull out the air filters. 3 Wash the air filters with water or clean them with a vacuum cleaner. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 32: To Clean The Titanium Apatite Deodorising Filter And The Silver Particle Filter (Ag-Ion Filter)
1 Remove the silver particle filter (Ag-ion filter) and titanium apatite deodorising filter from the tabs 2 Remove the dust from the filter with a vacuum cleaner. 3 Soak the filter for 10 to 15 minutes in warm water. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 33: To Replace The Titanium Apatite Deodorising Filter And The Silver Particle Filter (Ag-Ion Filter)
2 After operation stops, turn the breaker OFF. 3 Clean the air filters and replace them in their original positions. 4 Remove the batteries from the wireless remote control. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 34 Maintenance costs shall be borne by the customer. In certain operating conditions the inside of the unit may get dirty after several seasons of use. This results in poor performance. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 35: Winter Season
Maintenance and service 7.10.1 Winter season Only for RXTP-R: NOTICE Remove any icicles on the outdoor unit. Use gloves to avoid injury and damage to the unit. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 36: Troubleshooting
▪ The air conditioner may stop operating after sudden large voltage fluctuations to protect the system. It automatically resumes operation after about 3 minutes. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 37 If after checking all above items, it is impossible to fix the problem yourself, contact your installer and state the symptoms, the complete model name of the unit (with manufacturing number if possible) and the installation date (possibly listed on the warranty card). FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 38: Symptoms That Are Not System Malfunctions
Moisture generated by defrost becomes steam and exits. 8.1.8 Symptom: The units can give off odours The unit can absorb the smell of rooms, furniture, cigarettes, etc., and then emit it again. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 39: Symptom: The Outdoor Fan Rotates While The Air Conditioner Is Not In Operation
Signal transmission error (between indoor and outdoor unit) Indoor/outdoor unit combination fault Indoor unit Error code Description Indoor unit PCB abnormality Freeze-up protection or high-pressure control Fan motor (DC motor) abnormality FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... -
Page 40: Troubleshooting For Wireless Lan Connection
▪ Turn the unit off and then back on. ▪ Make sure the LEDs are not disabled in the application. ▪ Check if the adapter is installed correctly. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 41 2 seconds. Now switch back to AP mode by pressing the MODE button again for 2 seconds. This procedure will change the wireless channel on which the Wireless LAN adapter is operating. Repeat if necessary. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03...
-
Page 42: Disposal
Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FTXTP-M_FTXTP-N User reference guide Daikin room air conditioners 4P728152-3 – 2023.03... - Page 43 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
