  • Page 1 User reference guide Split system air conditioner User reference guide English Split system air conditioner FTXTA30A2V1BW...
  • Page 2: Table Of Contents

    Wireless LAN connection ............14 Indicates a situation that could result in explosion. 5.12.1 Precautions when using the wireless adapter..... 14 5.12.2 To install the Daikin Online Controller application ..14 User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 3: For The User

    ▪ Do NOT sit, climb or stand on the unit. Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. ▪ Units are marked with the following symbol: The original documentation is written in English. All other languages are translations.
  • Page 4: About The System

    Signal transmitter Front panel LCD display Service cover Temperature adjustment button Intelligent eye sensor ON/OFF button Display Vertical swing button and menu (push 2 seconds) Room temperature and humidity sensor User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 5: Status: User Interface Lcd

    ▪ Setting the brightness of the user interface display. ▪ Setting the clock. ▪ Setting the indoor unit position. Airflow rate = Medium low ▪ Turning on the power supply. Airflow rate = Low FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 6: To Fix The User Interface To The Wall

    Note: The display automatically returns to the default screen after 60 seconds. To return to the default screen sooner, press twice. 2 Press to set the current day of the week. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 7: To Turn On The Power Supply

    Operation range To automatically turn ON or OFF the ON timer + Use the system in the following temperature and humidity ranges for system. timer safe and effective operation. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 8: Operation Mode And Temperature Setpoint

    1 Press one or more times to select the operation mode. [—] Stays in a fixed position. Result: The mode will be set as follows: User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 9: To Adjust Vertical Airflow Direction

    Comfort airflow and Intelligent eye operation You can use Comfort and Intelligent eye operation separately, or combine them. 3 Press to change the setting. 4 Press to change the setting. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 10: Intelligent Eye Operation

    Example: At night. from the LCD. Powerful operation This operation quickly maximizes the cooling/heating effect in any operation mode. You can get the maximum capacity. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 11: To Start/Stop Econo And Outdoor Unit Quiet Operation

    LCD and the timer temperature and temperature in the room (higher lamp goes off. and the day of the week are displayed on the LCD. temperature difference = higher airflow rate). FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 12: To Start/Stop On Timer Operation

    OFF timer Monday Blank Deletes reservation 25°C 27°C ▪ Make up to 4 settings. 5 Press 6:00 8:30 17:30 22:00 Result: The ON/OFF timer mode is set. and the time blink. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 13: To Copy Reservations

    Result: The selected reservation is deleted. Result: The whole reservation is copied to the selected day and the 6 Press to exit. timer lamp lights orange. Result: Remaining reservations will be active. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 14: Wireless Lan Connection

    AP mode display (menu  ▪ Wireless LAN access point ) appears. ▪ Installed free Daikin Online Controller application Note: If needed, the SSID number and the KEY are located on the unit or can be found in the accessory bag.
  • Page 15: Energy Saving And Optimum Operation

    Result: The display will return to the default screen. 6 Open the Daikin Online Controller application and follow the steps on the screen. Result: Wireless adapter mode will automatically change from Energy saving and optimum the AP mode to the RUN mode, the timer LED is blinking.
  • Page 16: Maintenance And Service

    If damaged, the unit may fall and result in injury. Global warming potential (GWP) value: 675 CAUTION Do NOT touch the heat exchanger fins. These fins are sharp and could result in cutting injuries. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 17: To Clean The Indoor Unit And User Interface

    5 Pull down both locks on the back of the front panel. 6 Open the front panel until the support fits into the fixing tab. 4 Wash the air filters with water or clean them with a vacuum cleaner. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 18: To Clean The Titanium Apatite Deodorizing Filter And The Silver Particle Filter (Ag-Ion Filter)

    (Ag-ion filter) INFORMATION Replace the filter every 3 years. 1 Remove the tabs on the filter frame and replace the filter with a new one. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 19: To Take Following Items Into Account Before A Long Idle Period

    In case the ON/OFF button was pressed start soon. right after operation was stopped or if the mode was changed. Operation will start after 3 minutes to protect the system. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 20: Symptoms That Are Not System Malfunctions

    The unit can absorb the smell of rooms, furniture, cigarettes, etc., Contact your dealer. and then emit it again. The user interface Replace the batteries of the user interface. display is blank. User reference guide FTXTA30A2V1BW Split system air conditioner 4P518786-4D – 2019.04...
  • Page 21: Symptom: The Outdoor Fan Rotates While The Air Conditioner Is Not In Operation

    Humidity sensor error ▪ Try resetting to the factory default and repeat the setting. Outdoor unit "To reset the connection Error code Description setting factory 4-way valve abnormality default" on page 15. FTXTA30A2V1BW User reference guide Split system air conditioner 4P518786-4D – 2019.04...
  • Page 22: Disposal

    9 Disposal Field supply Problem Measure Equipment NOT made by Daikin that can be combined with Displayed indoor/outdoor ▪ Online Controller displays product according instructions temperature/humidity value in indoor/outdoor temperature/ accompanying documentation. Online Controller differs from the humidity only for the indoor/ value measured by other outdoor unit's surrounding.
  • Page 24 4P518786-4D 2019.04...
