I Q F I E L D W I R E A B L E C O N N E C T O R S ( S I N G L E - P H A S E ) Q U I C K I N S TA L L G U I D E - E N - M T
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
SAVE THIS INFORMATION
Follow all safety and assembly instructions when installing
IQ Field Wireable Connectors.
Safety symbols
+ DANGER: This indicates a hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING: This indicates a situation where failure to follow
*
instructions may be a safety hazard or cause equipment malfunc-
tion. Use extreme caution and follow instructions carefully.
; WARNING: Risk of burn. Failure to follow instructions may result
in burn injury.
✓
NOTE: This indicates information particularly important for opti-
mal system operation.
Safety instructions
DANGER: Risk of electric shock. Do not use Enphase equipment in
+
a manner not specified by the manufacturer. Doing so may cause
death or injury to persons, or damage to equipment.
DANGER: Risk of electric shock. Be aware that installation of this
+
equipment includes risk of electric shock. Do not use without
first removing AC power from the Enphase system. Disconnect
the power coming from the photovoltaics before servicing or
installing.
DANGER: Risk of electric shock. Risk of fire. Before making any
+
connections verify that the circuit breakers are in the off position.
Double check all wiring before applying power.
DANGER: Risk of electric shock. Risk of fire. Only use electrical
+
system components approved for wet locations, including but not
limited to conduit fittings.
DANGER: Risk of electric shock. Risk of fire. Only quali-
+
fied personnel should install, troubleshoot, or replace the
IQ Field Wireable Connector.
DANGER: Risk of electric shock. Improper use of the
+
IQ Field Wireable Connector or its components may result in a
shock, fire or explosion. To reduce these risks, disconnect all
wiring before attempting any maintenance.
DANGER: Risk of electric shock. Risk of fire. Ensure that all AC and
+
DC wiring is correct and that none of the AC wires are pinched,
shorted, or damaged.
DANGER: Risk of electric shock. Risk of fire. Do not attempt to
+
repair or alter the IQ Field Wireable Connector.
DANGER: Risk of electric shock. Risk of fire. Make sure the
+
conductors are not damaged. If the exposed wires are damaged,
the system may not function properly.
WARNING: Risk of equipment damage. Enphase male and female
*
connectors must only be mated with the matching male/female
connector.
WARNING: Risk of equipment damage. This product is intended for
*
operation in an environment having a maximum ambient tempera-
ture of 85ºC.
Safety instructions, continued
WARNING: When installing the cabling, secure any loose cable to
*
minimize tripping hazard
WARNING: Before installing or using the IQ Field Wireable Connec-
*
tor, read all instructions and cautionary markings in the technical
description, on the Enphase System, and on the photovoltaic (PV)
equipment.
✓
NOTE: Maintenance and cleaning must be performed by qualified
personnel.
✓
NOTE: Using unapproved attachments or accessories may result
in damage or injury.
✓
NOTE: When looping the IQ Cable, do not form loops smaller
than 12 cm in diameter.
✓
NOTE: Perform all electrical installations in accordance with all
applicable local electrical codes.
✓
NOTE: To ensure optimal reliability and to meet warranty require-
ments, install the IQ Field Wireable Connectors according to the
instructions in this guide.
✓
NOTE: Protection against lightning and resulting voltage surge
must be in accordance with local standards.
✓
NOTE: The connector is considered to be in compliance with UL
6703 only when assembled in the manner specified by these
assembly instructions.
✓
NOTE: Cable used with IQ Field Wireable Connectors must meet
the following requirements:
• Min/max outer insulation diameter (including the clear second
insulator): 3.75 mm/4.05 mm
• Number of conductor strands/size: 49 strands of 0.25 mm
• Wire size: 2.5 mm 2
Note for third-party products:
Any third-party manufacturer or importer product(s) used to install or commis-
sion Enphase product(s) shall comply with the applicable EU Directive(s) and
requirements in the EEA (European Economic Area). It is the responsibility of
the installer to confirm that all such products are labelled correctly and have the
required compliant supporting documentation.
Compliance with EU Directives
This product complies with the following EU Directives and can be used in
the European Union without any restrictions.
• Low Voltage Directive (LVD) 2014/35/EU
• Restriction of Hazardous Substances (RoHS) 2011/65/EU
The full text of the EU Declaration of Conformity (DoC) is available at
https://enphase.com/en-mt/installers/resources/documentation.
Manufacturer:
Enphase Energy Inc.,
47281 Bayside Pkwy, Fremont, CA, 94538,
United States of America, PH: +1 (707) 763-4784.
Importer:
Enphase Energy NL B.V.,
Het Zuiderkruis 65, 5215MV, 's-Hertogenbosch,
The Netherlands, PH: +31 73 3035859.
PREPARATION
Check that you have IQ Field Wireable Connectors as needed for your
installation. Both female and male connectors are sold in packs of ten:
• IQ Field Wireable Connector (female): Q-CONN-R-10F
• IQ Field Wireable Connector (male): Q-CONN-R-10M
Make sure you have the following recommended tools:
• Diagonal cutter
• Wire stripper
• Crimp tool: Multi-Contact PV-CZM-18100, -19100, or -22100
• Torque wrench
• IQ Disconnect Tool
When to use IQ Field Wireable Connectors
Use IQ Field Wireable Connectors with IQ Cable:
• Easily connect IQ Cables on the roof without complex wiring
• Use female connectors to make connections from any IQ Cable
open connector
• Make a jumper to connect with a remote part of the array: Use
female-female for cable-to-cable connections
• Use a mated pair of connectors to splice two cut ends of the cable
IQ
Disconnect
Tool
