enphase Ensemble COMMS-KIT-01 Quick Install Manual

Q U I C K I N S T A L L G U I D E
Installing the
Enphase Ensemble™ Communications Kit
The Enphase Ensemble Communications Kit (COMMS-KIT-01) contains a wireless USB adapter to install in an Enphase IQ Combiner™ or near an Enphase IQ
Envoy™. The kit enables wireless communication between the Enphase IQ Envoy or Enphase IQ Combiner™ and Enphase Encharge™ storage as well as Enphase
Enpower™ Microgrid Interconnection Device (MID). Note that you must install the Ensemble Communications Kit to enable complete functionality of the Ensem-
ble energy management system. The kit includes both 2.4GHz and sub-GHz wireless radios. The Ensemble system seamlessly switches between the two bands
to ensure reliable wireless communication.
Read and follow all warnings and instructions in this Guide. If you do not fully understand any of the concepts, terminology, or hazards outlined in these
instructions, refer installation to a qualified electrician or installer. These instructions are not meant to be a complete explanation of a renewable energy
system. All installations must comply with national and local electrical codes. Professional installation is recommended.
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This guide contains important instructions that you must follow during
installation of the Enphase Ensemble Communications Kit.
Safety and Advisory Symbols
DANGER: This indicates a hazardous situation, which if not avoided, will
result in death or serious injury.
⚠
WARNING: This indicates a situation where failure to follow instructions
may be a safety hazard or cause equipment malfunction. Use extreme
caution and follow instructions carefully.
✓
NOTE: This indicates information particularly important for optimal
system operation. Follow instructions carefully.
Safety Instructions
DANGER: Risk of electric shock. Risk of fire. Do not attempt to repair the
Enphase Ensemble Communications Kit. It contains no user-serviceable
parts. If the equipment fails, contact Enphase Customer Support for assis-
tance or replacement equipment (enphase.com/en-us/support/contact).
DANGER: Risk of electric shock. Do not use Enphase equipment in a
manner not specified by the manufacturer. Doing so may cause death or
injury to persons, or damage to equipment.
DANGER: Risk of electric shock. Risk of fire. Only qualified personnel
should troubleshoot, install, or add parts to the IQ Combiner or IQ Envoy.
DANGER: Risk of electric shock. All sources to equipment being serviced
must be disconnected external to the device. In particular, the storage
system may energize conductors, so storage circuits must ALWAYS be
isolated via circuit breaker or disconnect before working on any portion
of the system.
DANGER: Risk of electric shock. Risk of fire. Only use electrical system
components approved for wet locations.
Enphase Customer Support: enphase.com/en-us/support/contact
DANGER: Risk of electric shock. Risk of fire. Ensure that all wiring is
correct and that none of the wires are pinched or damaged.
DANGER: Risk of electric shock. Risk of fire. Do not work alone. Someone
should be in the range of your voice or close enough to come to your aid
when you work with or near electrical equipment. Remove rings, brace-
lets, necklaces, watches etc. when working with batteries, photovoltaic
modules or other electrical equipment.
DANGER: Risk of electric shock. Risk of fire. Before making any connec-
tions verify that the circuit breakers are in the off position. Double check
all wiring before applying power.
⚠
WARNING: Before installing or using the IQ Combiner, read all instruc-
tions and cautionary markings in the technical description and on the
equipment.
✓
NOTE: Using unapproved attachments or accessories could result in
damage or injury.
