TAKEDO
- 3VF
NXL
INSTRUCTION MANUAL
5
16-01-2007
REL.
DATE
T.M. Check and Approval

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAKEDO-3VF NXL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMS TAKEDO-3VF NXL

Summary of Contents for SMS TAKEDO-3VF NXL

  • Page 1 ® TAKEDO - 3VF INSTRUCTION MANUAL 16-01-2007 REL. DATE T.M. Check and Approval...

  • Page 2: Table Of Contents

    INDEX INTRODUCTION..................Page SAFETY WARNINGS AND CAUTIONS ..........Page CONNECTING THE POWER CIRCUIT..........Page BASIC CONFIGURATION APPLICATION EXAMPLE......Page KEYPAD AND PROGRAMMING ............Page Page 5.1 MONITOR ..................... Page 5.2 PARAMETERS..................Page 5.3 FAULTS ....................ADJUSTMENT PROCEDURE .............Page CHECKS AND MAINTENANCE............Page SUMMARY TABLES OF SASSI MOTOR PARAMETERS....Page DECLARATION OF CONFORMITY.............Page TAKEDO - 3VF NXL USER MANUAL Release 5 date 16-01-2007...

  • Page 3: Introduction

    1 – INTRODUCTION TAKEDO-3VF NXL is an inverter drive with built-in EMC filter and smoothing choke, responding to European Directives 89/336/EEC (electromagnetic compatibility) and 73/23/EEC (low voltage equipment). The inverter can operate only in open loop conditions. This manual provides you with the necessary information about putting on duty and the operation of NXL frequency converter.

  • Page 4: Connecting The Power Circuit

    (contact SMS for suggestions if required). 4- The inverter drive is connected <<up line>> of the power contactors. The drive is able to control motor operation in two directions;...
  • Page 5 It is advisable to connect the shield to earth at both ends by means of a U-clip or by means of special terminals that can be supplied by SMS. In the event that the shield cannot be bonded with a fully encircling clamp or clip inside the motor terminal box, the connection must be made by securing the shield to the frame at a point before the cable enters the box.

  • Page 6: Basic Configuration Application Example

    4 – BASIC CONFIGURATION APPLICATION EXAMPLE TAKEDO - 3VF NXL USER MANUAL Release 5 date 16-01-2007...

  • Page 7: Keypad And Programming

    5 – KEYPAD AND PROGRAMMING Right Menu key Left Menu key Scroll forward through menus. Move Scroll back through menus. Move the cursor to right (in the parameters cursor to left (in the parameters menu). Access edit mode. menu). Exit from edit mode. Hold down the key for 2…3 seconds to return to the main menu.

  • Page 8: Parameters

    IMPORTANT 5.2 P2 = PARAMETERS The parameters with grey background can only be changed after SMS advice! BASIC PARAMETERS AND RUN CONFIGURATION Par. Description unit/meas Def. Value P2.1.1 Limite corrente / Current Limit 1,8 x Inv P2.1.2 Tensione Nom Motor / Motor Nom Volt P2.1.3...

  • Page 9: Faults

    P2.3.3 and P2.3.7 to 0. If the alarm still occurs, please contact SMS. TAKEDO - 3VF NXL USER MANUAL Release 5 date 16-01-2007...

  • Page 10: Adjustment Procedure

    5.5 S5 = SYSTEM MENU SMS advises against modifying parameters relative to this MENU. 5.6 E6 = EXPANSION BOARDS SMS advises against modifying parameters relative to this MENU.
  • Page 11 6.6 – IDENTIFICATION (IMPORTANT!) After setting the correct motor data, it is essential to perform the IDENTIFICATION routine. - Set parameter 2.1.7 to 1 and transmit a call command: the contactors energizes, the brake doesn’t open, and on the keypad appear the “RUN” message. - When the “STOP”...
  • Page 12 high speed. 2 - Ensure that motor rpm is as requested and speed is constant at If the speed is not constant (fluctuating) adjust parameter 2.1.4. (motor speed), reducing or increasing rpm. deceleration phase 3 - Now check the : the lift must reach the floor after covering a short distance at constant speed (max.

  • Page 13: Checks And Maintenance

    6.10 – PARAMETERS FOR EMERGENCY OPERATION WITH BATTERY POWER SUPPLY(MINIMUM 96VDC) EFFECTIVE ONLY IN EVACUATION RUN 2.5.2 EVACUATION MODE: 0= MANUAL (DOES NOT SELECT FAVOURABLE RUN DIRECTION) 1 = AUTOMATIC (SELECTS FAVOURABLE RUN DIRECTION) 2.5.1 MAXIMUM SPEED IN EVACUATION: this is the maximum speed of the motor, whatever the level effectively activated (high, low, inspection, etc.).
  • Page 14 For further information and advice contact: SMS SISTEMI e MICROSISTEMI s.r.l. (Gruppo SASSI HOLDING) Cap. Soc. 260.000 i.v. Via Guido Rossa, 46/48/50 40056 Crespellano BO R.E.A 272354 CF - Reg. Imprese Bo 03190050371 P.IVA IT 00601981202 Tel. : +39 051 969037...
