Dimplex DCPF40ANT Instruction Manual page 6

40cm hv pedestal fan

Advertisement

Parts
Fan blade
Rear Guard
Retaining clip
Motor shaft
Front guard
Fixing screws
Speed control
Motor housing
Power cord
Adjustment knob
Bolt
Pivot knob
Fan blade screw
Screw
Upper pillar
Nut
Neck Retaining
screw
Height adjustment
knob
Main pillar
Stand base
Weight
Clamping washer
L-shaped screw
Speed control
6
