FS71 User Manual v1.3
All-In-One 24MP Film Scanner with HDMI
Thank you for your purchase of this Magnasonic product. Please read
this user manual carefully before using product to ensure proper use.
Keep this manual in a safe place for future reference.
magnasonic.com/support
We reserve the right to change models, configurations, or specification without notice or liability. Product may not
be exactly as shown. © MAGNASONIC®, MAGNASONIC®, the MAGNASONIC® marks may be registered. All other
trademarks are property of their respective owners

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS71 and is the answer not in the manual?

Questions and answers

Summary of Contents for Magnasonic FS71

  • Page 1 We reserve the right to change models, configurations, or specification without notice or liability. Product may not be exactly as shown. © MAGNASONIC®, MAGNASONIC®, the MAGNASONIC® marks may be registered. All other trademarks are property of their respective owners...
  • Page 2 At Magnasonic, our mission is a simple one – create people-driven products that make life’s daily adventures easier and more fun. We believe everyday experiences should be extraordinary.
  • Page 3: Table Of Contents

    Watching Saved Images From a TV Screen ............11 Downloading Images To Your Computer ............11 Formatting Your SD Card ..................12 FAQ / Troubleshooting......................13 Specifications .........................14 Magnasonic® Warranty .......................15 Important Safety Instructions ..................17 Safety Alerts ........................17 Best Practices for Safe Use ..................17 Cleaning and Care.......................18 FCC/HDMI Information .......................19...
  • Page 4: Product Information

    Product Information 110 Slide Insert Negative Adapter 110 Film Insert Slide Adapter Super 8/8mm Insert...
  • Page 5 Product Information Front LCD Screen Home Button Power Button OK/Image Settings Button Back/Mirror Button Forward/Flip Button Film/Slide Adapter Slot Capture Button Back SD Card Slot Mini USB Port HDMI Port...
  • Page 6: Operating Instructions

    Main Menu Icons Capture Images Gallery Format SD Card Connect to PC Language Setting Film Type Setting Resolution Setting...
  • Page 7: Cleaning And Care

    Operating Instructions Cleaning and Care Use the included cleaning brush to ensure there is no dust or debris on the lens. Insert the soft end of the brush, face down, into the film/slide holder slot. Carefully push the brush around inside to get rid of any dust or debris that may be on the LED backlight.
  • Page 8: Changing The Language

    Changing The Language On the main menu, go to Language. You may now select the language of your choice by using the < and > buttons to scroll between the available selections. Press the OK button to select the language. Prepping Your Film/Slides Insert your slide or film into the appropriate slide or film adapter.
  • Page 9: Using An Sd Card

    Note: If you are using a 128GB SD card, it may need to be formatted before using for the first time. Please see page 12 for formatting instructions. Using an SD Card Insert the SD card, face down, into the SD card slot located at the back of the film scanner.
  • Page 10: Viewing Your Scanned Images

    To adjust brightness or color, press the OK button. Use the left and right arrow buttons to move between brightness, red, green, or blue. Press the OK button to adjust them up or down. When ready, press the button to return to your image. You can also mirror or flip your image prior to scanning and saving your image by pressing the left (mirror) or right (flip) buttons.
  • Page 11: Watching Saved Images From A Tv Screen

    Watching Saved Images From a TV Screen Turn on the film scanner. Using an HDMI to HDMI cable (not included), connect the HDMI plug into the HDMI port at the back of the film scanner. Connect the other end of the HDMI cable into the HDMI port on your TV. Note: When you connect the film scanner to your TV via HDMI, the scanner’s LCD screen will turn off automatically.
  • Page 12: Formatting Your Sd Card

    Formatting Your SD Card WARNING: Formatting your SD card will delete all files stored on the SD card. Download your files from your SD card to your computer before formatting. In the main menu, go to Format press the OK button. When prompted if you would like to format the media, use the <...
  • Page 13: Faq / Troubleshooting

    FAQ / Troubleshooting Issue Solution Ensure the film/slides are clean and that you clean the inside of the How can I get the best quality scan scanner with the included cleaning possible? brush immediately before scanning. See pg. 7 for instructions on how to use the cleaning brush.
  • Page 14: Specifications

    Issue Solution Ensure an HDMI cable is not connected to the back of the film The scanner screen is black but it scanner. Confirm the USB power has power. source is 5V 1A and test with another USB power source. Confirm the USB power source is 5V There are red lines on the display 1A and test with another USB power...
  • Page 15: Magnasonic® Warranty

    Warranty Exclusions Magnasonic products are warrantied for parts and labor for one year from date of original purchase, and are subject to the terms and conditions of the warranty. Any refurbished products that are discontinued hold a 90 day warranty from the date of original purchase.
  • Page 16 This warranty does not cover the shipping cost, insurance, or any other incidental charges. Products shipped for warranty service must be pre-paid by the customer, and Magnasonic will cover the cost to ship the repaired or replaced product back to the customer.
  • Page 17: Important Safety Instructions

    Important Safety Instructions This unit has been designed and manufactured to ensure your personal safety. Use only for its intended use as described in this manual. Improper use can result in potential electrical shock or fire hazards. Read all safety and operating instructions carefully before installation and use.
  • Page 18: Cleaning And Care

    ventilation conditions. The ventilation should not be impeded. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged.
  • Page 19: Fcc/Hdmi Information

    FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 20 magnasonic.com...
