Revision History Rev. Date Contents 2024.01.22 JEONG.SS LEE.DS Mass Product Step JIN.SK 1 / 15...
Page 3
Purpose, Part List ■ Purpose This is the instruction how to add NFC(KIOSK-IV) ■ Parts Part No. Part Name Q’ty Etc. 5412000140 UNIT:VIVOPAY KIOSK IV(IDVK-411):IDTECH 4210009167 SUPPORT:NFC_VIVOPAY_IV_MX2800 44683801 SCREW:TRUSS:TAP-2:M4X8:W/ZN 3200009956 CABLE_ASSY:MBD(CN12)NFC_IF:550MM 3200012367 CABLE_ASSY:VIVO4_SPR_PWR:LOBBY 33659001 CABLE_TIE:CABLE:BLACK:100 5721002914 LABEL:RF 2 / 15...
Page 4
[Step 1] Front Panel Open Using the system key, unlock the top of the front panel and then pull the front forward. Front Panel 3 / 15...
Page 5
[Step 2] Front Panel Rotation Unscrew the two fixing pieces on the front and base of the SHU. (requires both left and right release) "O" marked part Remove the screw and turn the front panel forward. Hold both ends and slowly rotate the front panel. 44654303 SCREW:PH:M4X8:S/W:F/W(L) Front Panel...
Page 6
[Step 3] NFC Part Sub Assembly Assemble NFC fixed brkt and module. (4210009167, 5412000140) When fixing the NFC, remove the nut from the module, combine the stud bolt and brkt, and re-tighten the nut to assemble. 4210009167 SUPPORT:NFC 5412000140 UNIT:VIVOPAY KIOSK IV 5 / 15...
Page 7
[Step 4] NFC Part Assembly Fix the NFC module mounted on brkt. (44654303 → 1ea) 6 / 15...
Page 8
[Step 5] NFC Cabling Connect to the board CN12 port on the back of the OPL. (3200009956) 7 / 15...
Page 9
[Step 6] NFC Cabling Connect the cable as shown below. (3200009956) 8 / 15...
Page 10
[Step 7] NFC Cabling Disconnect the SPR cables from the old power supply and organize them as follows. (3200012367) 9 / 15...
Page 11
[Step 8] NFC Cabling Connect the 3200009956 cable NFCP and 3200012367 cable NFCP connectors. 10 / 15...
Page 12
[Step 9] Front Panel Rotation After rotating the front panel again, fix the left and right frames of the panel again. (44654303 → 2ea) 44654303 SCREW:PH:M4X8:S/W:F/W(L) Rotate SHU Base 11 / 15...
Page 13
[Step 10] Close the Front Panel Push the front panel back to lock the pin lock on the panel. Make sure that the front panel is locked properly. Check Locked Front Panel 12 / 15...
Page 14
[Step 11] Labeling (NFC Label) As Label the groove as shown below 13 / 15...
Page 15
[Step 12] S/W Setting 1. Activate RFID Reader. - Navigate to OPERATOR PROGRAM >> SYSTEM SETUP >> DEVICE SETUP - Press RFID EN/DISABLE button to activate RFID Reader. 14 / 15...
Page 16
[Step 13] S/W Setting 2. Testing RFID Reader - Navigate to OPERATOR PROGRAM >> DIAGNOSTICS >> AUXILIARY UNIT >> RFID CARD SCAN - Contact your card to RFID Reader then the card data would be shown on ‘ISO1’ area. ISO1 Card data captured by RFID Reader would be shown.
