- Page 1 MoniMax7600I Installation Manual Copyrightⓒ 2010 Nautilus Hyosung Inc. All right reserved...
- Page 2 MoniMax7600I Installation Manual Revision Record Date Page Version Description of Change May 2010 New Publication 12~13 Modified AC Inlet Box. June 2010 22~23 Added how to install the topper on the ATM. Modified Block Diagram of AC Inlet Box. December 2010 11~12 Modified the image of dimension on side view.
-
Page 3: Table Of Contents
Configuration ··················································································································· 13 Input Specification ········································································································· 14 Power Cable ················································································································· 14 System Installation How to unpack and move the MoniMax7600I into position ········································ 15 Packing Dimensions ······································································································ 16 Installation Condition and Space ··················································································· 17 Placement of the MoniMax7600I ATM ·········································································· 18 Installation and Service Clearance ···············································································... -
Page 4: Introduction
Consumers can carry out transactions, receive paper currency and transaction records (statements and receipts). The MoniMax7600I ATM is installed on a new or existing concrete island. The terminal is weather- sealed to allow for exposure to the weather. This manual is designed to provide installation guide for the MoniMax7600I ATM and provide... -
Page 5: Warning Signs
MoniMax7600I Installation Manual Warning Signs Common Precautions for Safety Precautions outlined this manual provide information on safe and proper handling of the product. Non-compliance of the precautions may result in injury or damage to the product. This precaution symbol with sample term tells you safety warnings during equipment handlings. -
Page 6: Description Of Warning Signs
MoniMax7600I Installation Manual Description of Warning Signs Sign Description Risk Of Electric Shock • Do not remove cover. Only a maintenance engineer should open the cover. • To avoid risk of electric shock, do not touch. • Make sure to turn off the power before servicing the equipment. - Page 7 MoniMax7600I Installation Manual Sign Description Fire Hazard • Place the equipment in an area away from any combustible materials. • The equipment may catch on fire from overheating or short circuit of the power supply unit. Disassembly • Do not disassemble or modify the equipment unless you are a certified engineer.
-
Page 8: System Configuration
MoniMax7600I Installation Manual System Configuration ATM Components ..10 ..11 ..12 Fig.1 MoniMax7600I Components ATM Signage & Logo Receipt Printer Slot Statement Printer (Option) Encryption PIN Pad Tilting Screen Control Buttons Envelope Stacker (BCA/CSM Upgradeable) Customer Display (Touch or Function key) -
Page 9: Atm Dimensions
MoniMax7600I Installation Manual ATM Dimensions Dimension on Front View Fig.2 ATM Dimensions on front... - Page 10 MoniMax7600I Installation Manual Dimension on Side View Fig.3 ATM Dimensions on side...
-
Page 11: Terminal Block Interface
MoniMax7600I Installation Manual Terminal Block Interface Terminal Block Interface (1) Fig.4 Terminal Block Interface (1) - Page 12 MoniMax7600I Installation Manual Terminal Block Interface (2) Fig.5 Terminal Block Interface (2)
-
Page 13: Ac Inlet Box
MoniMax7600I Installation Manual AC Inlet Box Function Secure the stability during AC power input and system operation and distribute the AC power evenly. Block Diagram * AC Inlet Box Specification: 110 Vac 20A Fig.6 Block Diagram Configuration NOTE1 - Terminal Block : AC Inlet of the AC Inlet Box. (Due to the electrical shock hazard, be sure to connect Power code to AC Inlet Box after removing the Power Cable Plug from AC Source.) -
Page 14: Input Specification
MoniMax7600I Installation Manual NOTE3 - Surge Protector : Prevent the system damage from inflow of high voltage such as thunderbolt. (AC Free Voltage can be inputted.) NOTE4 - Multi Outlet : Distribute AC Power to each system power. NOTE5 – AC Power Strip : Distribute AC Standard Power to sub-units. -
Page 15: System Installation
MoniMax7600I Installation Manual System Installation How to unpack and move the MoniMax7600I into position Unpack the machine on top of the palette. ● Cut the straps that are fastened around the box with a knife. (refer to Fig.7) (Be careful when cutting the straps.) ●... -
Page 16: Packing Dimensions
MoniMax7600I ATM. ● Handle the MoniMax7600I ATM with care when moving it. Do not move the ATM with either the safe door or top chassis open. Ensure that the safe door and top chassis are closed and locked. -
Page 17: Installation Condition And Space
MoniMax7600I Installation Manual NOTE: Approximate weight of a boxed MoniMax7600I ATM is 2755lbs (1250Kg). Actual weight will vary depending on ATM component configuration. 1 1800 mm (70.87 inches) 2 1300 mm (51.18 inches) 3 1170 mm (46.0 inches) Installation Condition and Space Following conditions should be met before installing equipment. -
Page 18: Placement Of The Monimax7600I Atm
1. Standard (with EDU-P): 2755lbs(1250Kg) Weight 2. Option (with BNA): 2910lbs(1320Kg) Placement of the MoniMax7600I ATM The MoniMax7600I ATM can be placed on a new or existing concrete island (Fig.10). Fig.10 Placement of the MoniMax7600I ATM MoniMax7600I ATM Guard posts (4) New or existing concrete island (Concrete island to be flat and level in area of ATM.) -
Page 19: Installation And Service Clearance
MoniMax7600I Installation Manual Installation and Service Clearance 1) Installing and Servicing Area for MX7600I (Pilot) Following diagram is describing the areas required for installing and servicing the MX7600I... - Page 20 MoniMax7600I Installation Manual Fig.11 (a) Service Clearance for the MoniMax7600I ATM: Service Position - Plan View Fig.11 (b) Service Position - Front View...
- Page 21 MoniMax7600I Installation Manual Fig.11 (c) Service Position - Side View...
- Page 22 MoniMax7600I Installation Manual 2) Anchor Diagram for MX7600I (Mass Production)
- Page 23 MoniMax7600I Installation Manual 2) Installing and Servicing Area for MX7600I (Mass Production) Following diagram is describing the areas required for installing and servicing the MX7600I...
- Page 24 MoniMax7600I Installation Manual 120.0° 120.0° Fig.12 (a) Service Clearance for the MoniMax7600I ATM: Service Position - Plan View Fig.12 (b) Service Position - Front View...
- Page 25 MoniMax7600I Installation Manual 125.0° Fig.12 (c) Service Position - Side View...
-
Page 26: Anchor Diagram
MoniMax7600I Installation Manual Anchor Diagram 1) Anchor Diagram for MX7600I (Pilot) -
Page 27: Topper Installation
MoniMax7600I Installation Manual Topper Installation The following procedures detail how to install the topper on the ATM. ● Insert the lower front door key into the lock on the lower front door. ● Turn the key clockwise and open the lower front door. - Page 28 MoniMax7600I Installation Manual ● There is a topper cover inside the ATM. ● Remove 3 nuts around the topper cover through inside the ATM using nut driver. Nut Driver ● Then remove topper cover and install the topper on the ATM.
-
Page 29: Atm Signage
MoniMax7600I Installation Manual ATM Signage Be supposed to paste the decoration label on the light, where the bank logo or advertisement is printed. Decorate Label where the bank logo or advertisement is printed. Dimension of ATM Signage Fig.13 ATM Signage Dimension... -
Page 30: Precautions
MoniMax7600I Installation Manual PRECAUTIONS MX7600I has system battery back up units as optional itself to grantee customers transaction safety when losing power status. This function will proceed automatic safe shut down either. But we are recommending to use UPS system for power sourcing to ATM.
