- Page 1 17L Table Top Cooler Model number: RH17CLR1001 (B) IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation and Handling ………………………………………. Installing and Switching on Your Appliance ………………………………………. Before Switching On ………………………………………. Your Appliance & the Compartments ………………………………………. Unit ………………………………………. Where to put your appliance ………………………………………. Installation …………………………….………… Usage Information ………………………………………. -
Page 3: Safety Instructions
Safety Instructions This appliance is a Semi-conductor electric refrigerating appliance, which is a Category 10 other appliance, according to ErP 643/2009. Its design temperature is 17°C. Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. - Page 4 • Do not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 5: Electrical Safety
• One-, two- and three -star compartments (if they are presented in the appliance) are not suitable for the freezing of fresh food. • If the appliance is left empty for long periods, switch off, defrost, clean, dry and leave the door open to prevent mount developing within the appliance. -
Page 6: Installing And Switching On Your Appliance
Installing and Switching on Your Appliance • Operating voltage for your appliance is 220-240V at 50Hz. • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home. •... -
Page 7: Before Switching On
Before Switching On • Before using your appliance, add a teaspoon of bicarbonate of soda to warm water and with a damp cloth wipe down all parts of the new appliance, then repeat the process with a clean damp cloth and dry. (ensure the appliance is not connected to the power when performing this task). -
Page 8: Your Appliance & The Compartments
Your Appliance and the Compartments Temperature dial Drip tray Light Door hinge cover Door shelf Removable wire shelf Door seal Adjustable feet 10. Door frame Parts may vary according to the appliance model. -
Page 9: Where To Put Your Appliance
Where to put your appliance This appliance should only be placed on a flat, solid surface. Do not place your appliance on a carpeted surface as this will prevent adequate ventilation. Choose a dry and well-ventilated space. No less than 50mm (5cms) must be left around the sides and 100mm (10cms) around the back of the appliance to allow sufficient cooling. -
Page 10: Installation
Installation • The unit should be kept away from direct sunlight. • Remove all transport tapes and foam protection pieces. Clean the interior of the appliance with a cloth dampened in lukewarm soap and water. Wipe with clear water and wipe dry. •... -
Page 11: Usage Information
Usage Information Thermostat Setting Note: The temperature of freshly stored items and how often the door is opened affects the temperature in the compartment. If required, change the temperature setting. • When you first switch on the appliance, to enable suitable cooling, the appliance should work 24 hours continuously until it cools down to sufficient temperature. -
Page 12: Door Foot Attachment
Usage Information Shelves • The wire shelf can be removed to allow for storage of larger items. • Removing a shelf - Remove all of the items from the shelf that you want to remove. Lift the shelf upwards and then gently pull the shelf away from the appliance. •... -
Page 13: Replacing The Bulb
Replacing the Bulb The light is an energy efficient, long life LED. Therefore should not need replacing throughout the life of the product however if it does it has to be replaced by a qualified engineer. Please call the service team on 0345 208 8750. The following symbol indicates that the light source in this appliance should only be replaced by a qualified engineer: Food Storage Guidelines... -
Page 14: Cleaning & Maintenance
Cleaning and Maintenance • Disconnect the appliance from the power supply before cleaning. • Do not pour water directly over or on the appliance. • The compartment should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. •... -
Page 15: Connection To The Mains Supply
Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or coloured... -
Page 16: Troubleshooting
Troubleshooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. The appliance doesn't work Check that the plug is not faulty. Check that the fuse has not blown. Check that the voltage is correct for the appliance. Check that the appliance is not overfilled. - Page 17 Troubleshooting Problem Solution Check that nothing has leaked or any stagnant liquid is at Smell/odour the bottom of the appliance. Clean if required.
-
Page 18: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. -
Page 19: Technical Specification
Technical Specification Model number RH17CLR1001 (B) Rated Voltage 220-240V/50Hz Net capacity (litres) 17 litres Dimensions (CMs): (H)36.0 x (W)38.5 x (D)41.5... -
Page 20: Product Fiche
Product Fiche Model RH17CLR1001 (B) Fresh Food Storage Compartment Volume (L) Frozen Food Storage Volume (L) Storage Temperature ( ° C) 5 – 14 Energy Consumption (kWh/per year) Energy Consumption (kWh/per year), based on standard test results for 24 hours... -
Page 21: Notes
Notes... - Page 22 Notes...
- Page 23 Notes...
- Page 24 Swan Lane, Hindley Green, Wigan, WN2 4AY, United Kingdom Product Care (Ireland) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, T23 AT2P, Ireland. Russell Hobbs is the registered trademark of Spectrum Brands (UK) Ltd.
