SAFETY NOTICE:
If this appliance is not properly installed, a house fire
may result. For your safety, follow the installation
directions. Contact local building or fire officials about
restrictions and installation inspection requirements
in your area.
Wood Stove
Freestanding Stove
Mobile-Home Approved
Alcove Approved
Hearth-Stove Approved
Copyright 2019,
Travis Industries, Inc.
$10.00
100-01498
7/17/2020
Evergreen
Owner's Manual
Save these instructions
for future reference
Conforms to UL STD 1482; Certified to ULC S627-2000
Listed
Advertisement
Table of Contents
Related Manuals for Travis Industries Lopi Evergreen
Summary of Contents for Travis Industries Lopi Evergreen
- Page 1 For your safety, follow the installation directions. Contact local building or fire officials about restrictions and installation inspection requirements in your area. Copyright 2019, Travis Industries, Inc. $10.00 Listed 100-01498 7/17/2020 Conforms to UL STD 1482; Certified to ULC S627-2000...
-
Page 2: Introduction
Introduction Introduction We welcome you as a new owner of a Lopi Evergreen wood-burning stove. In purchasing an Evergreen you have joined the growing ranks of concerned individuals whose selection of an energy system reflects both a concern for the environment and aesthetics. The Evergreen is one of the finest appliances the world over. -
Page 3: Table Of Contents
Adjusting the Burn Rate ........ 21 94400953) ............39 Approximate Air Control Settings ......21 GreenStart Igniter Installation Addendum .. 40 Understanding Your Heater’s Combustion System ............. 22 © Travis Industries 7/17/2020 - 1498 Evergreen... - Page 4 This wood heater needs periodic inspection and repair for proper operation. It is against federal regulations to operate this wood heater in a manner inconsistent with operating instructions in this manual. © Travis Industries 7/17/2020 - 1498 Evergreen...
- Page 5 Avoid placing wood against the glass when loading. Do not slam the door or strike the glass. Do not throw this manual away. Travis Industries, Inc. grants This manual has important no warranty, implied or This operating and maintenance...
-
Page 6: Installation Options
This heater meets the 2020 U.S. EPA’s cord wood emission limits for wood heaters. Tested to EPA Alt-125, ASTM E3053-17, ASTM 2515-11, CSA B415.1-10 this heater has been shown to deliver heat at rates ranging from 12,772 to 70,720 BTU/hr and an emission value of 1.52g/h. Report No. 0028WS119E © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 7: Planning The Installation
Planning the Installation We suggest that you have an authorized Travis Industries dealer install your stove. If you install the stove yourself, your authorized dealer should review your installation plans. Check with local building officials for any permits required for installation of this stove and notify your insurance company before proceeding with installation. -
Page 8: Floor Protection Requirements
NOTE: Standard residential installations with reduced clearance connector may use the clearance determined by the manufacturer of the connector for the connector to wall clearance or the clearance listed in this manual. Offsets must be used to maintain the stove to wall clearance. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 9: Top View - Straight Installation
(i) Measure rear and side clearances from the stove top. (j) Vent diameter varies depending on brand and model. (k) Measure front 28" clearances from the stove 712mm top. 5" 127mm 20.25" 515mm Figure 2 © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 10: Chimney Connector Requirements
Offsets must be used to maintain the stove to wall clearance. Mobile homes must use the clearances listed in this manual under "Additional Requirements for Mobile Home Installations". © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 11: Chimney Requirements
`plugging' of the chimney. Inadequate draft will cause the appliance to leak smoke into the room through appliance and chimney connector joints. An uncontrollable burn or excessive temperature indicates excessive draft. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 12: Chimney Termination Requirements
Requires a 3” duct that attaches to the back of the stove (see “a” below). Outside air duct must have a rodent screen and rain hood (see “b” below). The Travis Industries Outside Air Kit (sku 99200139) includes all the above components. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 13: Alcove Installation Requirements
40” Minimum height of alcove 84” 6" above stove top Non-Combustible Alcove (a) Non-Combustible (brick) (b) Air Space with non-combustible reinforcement (c) Combustible material Min. 3 1/2" Min. 1" (89mm) (25mm) Figure 5 © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 14: Mobile Home Requirements
12" Min. connector manufacturer's clearance. The appliance must be secured to the floor (consult your building official). Leg clips are available from Travis Industries (sku 98900509). Connector Clearance Mobile home installations require a spark arrester at the chimney (as outlined above) termination. -
Page 15: Standard Ceiling With A Factory-Built Chimney
Minimum 15' Chimney (4.57M) Connector Maximum 33' Sections (10.05M) Floor Protection (See the section "Floor Stove Clearances Protection Requirements" (See the section "Stove for more details) Placement Requirements" for more details) Figure 9 © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 16: Exterior Factory-Built Chimney
(18" if using single-wall connector) Chimney Connector Sections Follow the chimney manufacturer's instructions and clearances for wall penetrations. A wall radiation shield Follow (thimble) is required. Clearances Listed in the Woodstove Manual Minimum 74" Figure 11 © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 17: Hearth Stove Installation
We strongly recommend a full reline (positive connection) when venting through a masonry chimney. We also recommend that a minimum 3’ chimney be added to the minimum system height for every 1’ of horizontal run. © Travis Industries 2/22/2021 - 1498 Evergreen... -
Page 18: Safety Notice
If you are uncertain of over-firing conditions, we suggest placing a stove thermometer (e.g. Rutland® Model 710) directly in front of the flue outlet on the stovetop temperatures exceeding 800° are generally considered over-firing and will void the warranty. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 19: Opening The Door
During normal operation, push the bypass in. Bypass Pulled Out Used for starting and re-loading Use the included pull tool to operate the bypass rod Bypass Pushed In Used for normal operation © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 20: Starting A Fire
This should start the chimney drafting (this eliminates "cold air blockage"). Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning rapidly, place a few larger pieces of wood onto the fire. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 21: Adjusting The Burn Rate
The air control becomes hot during operation - use gloves or a tool to prevent burns. The air control may take several minutes to influence the burn rate. When making adjustments, you may wish to let the stove burn for 10 minutes to gauge performance. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 22: Understanding Your Heater's Combustion System
© Travis Industries 7/17/2020 - 1498... -
Page 23: Ash Removal
Use the included tool to lift the ash dump from the floor of the firebox (there are two – use either or both). Then scrape the ashes into the ash dump. NOTE: This tool is only designed for use with the ash dump (do not use it as a poker or to postion wood). © Travis Industries 7/17/2020 - 1498 Evergreen... - Page 24 Slide the ashpan out and use the included handle and lifting rod to remove the ashpan. Ashpan Removal – Stove Version Swing the ashpan door down. Slide the ashpan out. Use the included handle to slide the ashpan forward. Use both hands to transport the ashpan. © Travis Industries 7/17/2020 - 1498 Evergreen...
-
Page 25: Re-Loading The Stove
Blower Sounds: The blower will make a slight "humm" as it pushes air through the stove. Hint: Make sure the leveling bolts on legs are extended - preventing the hearth from amplifying any vibrations. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 26: Hints For Burning
Cut wood to length and Store the wood off the ground in a chop into quarters. covered area. Allow for airflow Air Flow around the wood to dry the wood. Air Flow Air Flow © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 27: Do Not Burn List
Burning these materials may result in release of toxic fumes or render the heater ineffective and cause smoke. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 28: Troubleshooting
Inspection" on page 30 for details. Check the ash bed for coals. Often, coals are still glowing under a slight bed of fly ash. By raking these into a pile you can re-start your stove quickly. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 29: Daily Maintenance (While Stove Is In Use)
The ash acts as a light abrasive. The glass will develop a very slight haze over time. This is normal and will not affect viewing of the fire. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 30: Monthly Maintenance (While Appliance Is In Use)
Tighten the nut and test operation. You may need to repeat this process, either moving the nut inwards or outwards, until the door Door Handle catch is in the correct position. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 31: Creosote - Formation And Need For Removal
Secondary Air Tubes - Check the air tubes and pins to make sure they are intact and not severely deteriorated. Slight scaling or rusting of the metal is normal. Make sure the pins hold the air tubes in place. Firebricks - Replace any severely damaged firebrick. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 32: Door Parts
To remove the door, swing the door open 90°. Grasp the door with both hands and lift upwards. If the door does not disengage, swing it open and closed while lifting upwards to work the door off the hinges. © Travis Industries 7/17/2020 - 1498... -
Page 33: Firebox Parts
Remove the baffle insulation (take care – it is fragile and may be covered in flyash). The baffle plates may be removed to finalize baffle removal. To replace the baffle components, follow the instructions in reverse order. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 34: Air Tube Removal & Replacement
The pin will then disengage from the air tube (you may wish to rotate the tube slightly). Pivot the air tube downwards and slide it out of the air channel on the opposite side. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 35: Air Tube Identification
Note that there are nine firebricks, including the igniter firebrick. ID # Description Qty. Part # Full Size Firebrick (4.5” x 9”) 251-00000 Cut Firebrick (Approx 6.8” x 2.1”) 251-00078 Cut Firebrick (Approx 6” x 4.5”) 251-00079 © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 36: Warranty
Limited 7 Year Warranty Warranty Register your TRAVIS INDUSTRIES, INC. Limited 7 Year Warranty online at traviswarranty.com. TRAVIS INDUSTRIES, INC. warrants this gas appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows Check with your dealer in advance for any costs to you when arranging a warranty call. - Page 37 At that time, you may be asked to ship your appliance, freight charges prepaid, to TRAVIS INDUSTRIES, INC. TRAVIS INDUSTRIES, INC., at its option, will repair or replace, free of charge, your appliance if it is found to be defective in material or workmanship within the time frame stated within this 5 year warranty.
-
Page 38: Listing Label
Listing Label Listing Label © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 39: Rear Blower (Part # 99000143)
Contact your dealer for details. GreenStart™Woodstove Igniter (Part # 94400953) An optional GreenStart™ igniter is available for your stove. This accessory starts your fire with a simple push of the button. Contact your dealer for details. © Travis Industries 7/17/2020 - 1498 Evergreen... -
Page 40: Greenstart Igniter Installation Addendum
(b) Replace the right backwall firebrick with the igniter firebrick included with the igniter (it has a hole it in). (c) Make sure to attach the cover plate and cover box to the stove after the igniter is in place (these components, along with screws, are included with the stove). © Travis Industries 7/17/2020 - 1498 Evergreen... - Page 41 Optional Equipment © Travis Industries 7/17/2020 - 1498 Evergreen...
- Page 42 Firebox Parts ............ 33 Why Dry Wood is Key ........26 Firebrick and Baffle Inspection ......31 Wood Cutting and Storage ......26 Firebrick Removal & Replacement ..... 35 Yearly Maintenance ......... 31 © Travis Industries 7/17/2020 - 1498 Evergreen...
