Dismantling Information forUse
by ProfessionalRecyclers
ORIGINAL MANUAL ISSUE DATE: 9/2024
Model:
SDM-27Q10S
OLED Digital Color Monitor
Conditions of Use:
(1) Please use this information only for the purpose of performing repair and recycling Sony products.
9-897-204-41
Using this information for any purpose other than the purpose described foregoing is forbidden.
(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information
in whole or in part without the prior written permission of the author.
Revision of Information:
Sony Corporation
This information may be changed or updated at any time without any prior notice. Please confirm that
this information is up-to-date before using it.
© 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDM-27Q10S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony SDM-27Q10S

Summary of Contents for Sony SDM-27Q10S

  • Page 1 SDM-27Q10S OLED Digital Color Monitor Conditions of Use: (1) Please use this information only for the purpose of performing repair and recycling Sony products. 9-897-204-41 Using this information for any purpose other than the purpose described foregoing is forbidden. (2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written permission of the author.
  • Page 2 MODEL LIST/REVISION HISTORY MODEL COLOR COMMANDER DEST. SDM-27Q10S CEI Black SDM-27Q10S...

  • Page 3: Safety Note

    5) SAFETY-RELATED COMPONENT WARNING!!: Components identified by shading and ! mark on the exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony.
  • Page 4 Image retention may occur if images are displayed in the same location on the screen repeatedly or over extended periods of time. This is not a malfunction of the monitor. Avoid displaying images that may cause image retention. SDM-27Q10S...
  • Page 5 Class II equipment (2-pin plug): for each terminal, the worst value deterioration. Point them out to the customer and recommend their of measurement must not exceed AC 350uA peak. replacement. Note: including AC adaptor, AC adaptor/DC operated unit combination SDM-27Q10S...
  • Page 6 (not a neon lamp) between the hot side of the receptacle and the retaining screw. Try both slots, if necessary, to locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground potential (see Figure 3). Figure 3. Checking for earth ground. SDM-27Q10S...

  • Page 7: Optional Equipment

    (6) Parts Tray for loose screws and small items 3 PREPARATION BEFORE REPAIRS Before you begin, unplug the Monitor from the desk or wall outlet. Then simply place the monitor faced-down on top of a thick blanket, on a large/flat surface. SDM-27Q10S...

  • Page 8: Service Position

    Remove the Rear Cover. REF. No. PART No. DESCRIPTION REMARKS 5-042-480-01 SCREW M4 11 4 pcs 4. Remove all screws on the Main 5-062-830-01 SCREW-MACHINE-1 WASHER-ROUND H 5 pcs bracket (4 screws). 5-042-497-01 SCREW M3*7.5 4 pcs SDM-27Q10S...
  • Page 9 1. Press VESA QR POM on the button of the rear cover. 5-062-819-01 Y24_PZ27_STAND_RISER_ASSY 2. Hold the stand riser and raise it to remove the stand. 5-062-826-01 Y24_PZ27_STAND_BASE_ASSY Hold the stand riser and raise it to remove the stand. Press VESA QR POM on the button of the rear cover. SDM-27Q10S...
  • Page 10 DISASSEMBLY AND PARTS LIST 1-2. How to disassemble rear cover REF. No. PART No. DESCRIPTION REMARKS 1. Remove 4 screws (M4*11) on the Rear Cover. 5-062-825-01 Y24_PZ27_REAR_COVER Rear cover 5-042-480-01 SCREW M4 11 4 pcs SDM-27Q10S...
  • Page 11 Rework jig Refer to APPENDIX-1 Slowly and gently disassemble with the rework jig. Be careful not to disassemble forcefully or violently to prevent the buckle from breaking. Caution： Be careful to ensure all hooks disassembled when opening the rear cover. SDM-27Q10S...
  • Page 12 SPONGE EMI gasket 5-062-830-01 SCREW-MACHINE-1 WASHER-ROUND 5 pcs Align the sponge with the marking line and paste the sponge. ⑩ Paste AL tape Be careful FFC when Paste AL tape between nearby punch edge. disassembling AL tape! VDD/EVDD cable. SDM-27Q10S...
  • Page 13 Note : 1-1 should match with 2-1, 1-2 match with 2-2 506586101 Y24_PZ27_MAIN_BRACKET_ASSY_2 Small HS, match with 2-2 506586401 T-PAD_T3 1.2T, match with 1-2 504249701 SCREW M3*7.5 506282301 Thermal PAD_T2 Printed Circuit Board, 102319011 MOUNTED PWB A (MB) incl.capacitors 506282701 Y24_PZ27_PCB_PLATE_ASSY 506283101 T-PAD_T1 SDM-27Q10S...
  • Page 14 2 pcs Disassemble the key cover Tip of removing FFC: pull the black part to unlock and remove FFC. with the rework jig. Before pulling the black part After pulling the black part Check the position of the black part. SDM-27Q10S...

  • Page 15: Circuit Boards Location

    2. CIRCUIT BOARDS LOCATION 2-1. CIRCUIT BOARDS LOCATION Function key board Main board SDM-27Q10S...
  • Page 16 English 2024HL08-Data Made in Japan 9-897-204-41 © 2024 Sony Corporation SDM-27Q10S...
