Sony SDM-27U9M2 Dismantling Information For Use

Sony SDM-27U9M2 Dismantling Information For Use

Lcd digital color monitor
Hide thumbs Also See for SDM-27U9M2:

Advertisement

Table of Contents

Dismantling Information forUse
by ProfessionalRecyclers
ORIGINAL MANUAL ISSUE DATE: 7/2024
Model:
SDM-27U9M2
LCD Digital Color Monitor
Conditions of Use:
(1) Please use this information only for the purpose of performing repair and recycling Sony products.
9-897-202-41
Using this information for any purpose other than the purpose described foregoing is forbidden.
(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information
in whole or in part without the prior written permission of the author.
Revision of Information:
Sony Corporation
This information may be changed or updated at any time without any prior notice. Please confirm that
this information is up-to-date before using it.
© 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDM-27U9M2 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony SDM-27U9M2

Summary of Contents for Sony SDM-27U9M2

  • Page 1 SDM-27U9M2 LCD Digital Color Monitor Conditions of Use: (1) Please use this information only for the purpose of performing repair and recycling Sony products. 9-897-202-41 Using this information for any purpose other than the purpose described foregoing is forbidden. (2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written permission of the author.
  • Page 2 MODEL LIST/REVISION HISTORY MODEL COLOR COMMANDER DEST. SDM-27U9M2 CEI Black SDM-27U9M2...

  • Page 3: Safety Note

    5) SAFETY-RELATED COMPONENT WARNING!!: Components identified by shading and ! mark on the exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony.
  • Page 4 7) Check the antenna terminals, metal trim, metalized knobs, screws and all other exposed metal parts for AC leakage. Check leakage test as described next. 8) For safety reasons, repairing the Power board and/or Inverter board is prohibited. SDM-27U9M2...
  • Page 5 Note: including AC adaptor, AC adaptor/DC operated unit Lead Free Solder. The boards are identified by the LF logo located combination close to the board designation. Figure 2 – Measuring network for Leakage Current Figure 5: LF logo on circuit board Figure 4: LF Logo SDM-27U9M2...
  • Page 6 SAFETY NOTE The servicing of these boards requires special precautions. It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints. SDM-27U9M2...

  • Page 7: Optional Equipment

    (6) Parts Tray for loose screws and small items 3 PREPARATION BEFORE REPAIRS Before you begin, unplug the Monitor from the desk or wall outlet. Then simply place the monitor faced-down on top of a thick blanket, on a large/flat surface. SDM-27U9M2...

  • Page 8: Service Position

    5. Remove all screws on the front (6 screws). bezel (13 screws). REF. No. PART No. DESCRIPTION REMARKS 5-042-480-01 SCREW M4 11 4 pcs 5-061-434-01 SCREW M3*0.5 4 pcs 5-046-961-01 SCRW M3*6 10 pcs 5-042-496-01 SCREW M3L5 13 pcs SDM-27U9M2...
  • Page 9 2. Hold the stand riser and raise it to remove the stand. 5-061-428-01 ASSY_SO_U27_MK2_RISER 5-061-429-01 ASSY_SO_U27_MK2_BASE 5-061-432-01 SO_U27_MK2_RUBBER_BAND 1 pc Hold the stand riser and raise it to remove the stand. Press VESA QR POM on the button of the rear cover. SDM-27U9M2...
  • Page 10 2. Hold the stand riser and raise it to remove the stand. 5-061-429-01 ASSY_SO_U27_MK2_BASE 5-061-432-01 SO_U27_MK2_RUBBER_BAND 1 pc Hold the stand riser and raise it to remove the stand. Press VESA QR POM on the button of the rear cover. SDM-27U9M2...
  • Page 11 DISASSEMBLY AND PARTS LIST 1-2. How to disassemble rear cover REF. No. PART No. DESCRIPTION REMARKS 1. Remove 4 screws (M4*11) on the Rear Cover. 5-061-427-01 ASSY_SO_U27_MK2_REAR_COVER Rear cover 5-042-480-01 SCREW M4 11 4 pcs SDM-27U9M2...
  • Page 12 1-2. How to disassemble rear cover 2. Open Rear Cover in order as below. Slowly and gently disassemble with bare hands. Be careful not to disassemble forcefully or violently to prevent the buckle from breaking. Refer to the U27 disassembly video for details. SDM-27U9M2...
  • Page 13 REF. No. PART No. DESCRIPTION REMARKS 3. Remove AL sheet and FK BD FFC. 5-062-731-01 EMI_AL_TAPE_W30XL70_IN_PIECE Remove 1 pc Caution: Be careful when opening the rear cover as the FFC is connected between the key board and the main board. SDM-27U9M2...
  • Page 14 * After installing the FFC, Before pulling After pulling push the black part to lock it. the black part the black part Remove AL tape. Check the position of the black part. 1. Remove the cable while pinching the connector claw. SDM-27U9M2...
  • Page 15 LVDS FFC (MB -PANEL) Backlight FFC top 4. Disassemble eDP cable and Backlight FFC. 1-021-166-11 LVDS FFC 105MM (MB -PANEL) Backlight FFC side 1-021-165-11 LVDS FFC 51P (MB -PANEL) 1-021-164-11 LOUDSPEAKER Speakers 5-061-434-01 SCREW M3*0.5 4 pcs 5-046-961-01 SCRW M3*6 4 pcs SDM-27U9M2...
  • Page 16 LVDS FFC 51P (MB -PANEL) Printed Circuit 1-021-161-11 MOUNTED PWB A (MB) Main board Board, incl. capacitors 5-062-732-01 THERMAL PAD Thermal pad for scaler 5-046-961-01 SCRW M3*6 6 pcs When disassembling the MAIN BRACKET, be careful not to tear the THERMAL PAD. SDM-27U9M2...
  • Page 17 DISASSEMBLY AND PARTS LIST 1-5. How to disassemble front bezel 1. Remove 13 screws (M3*5). EF. No. PART No. DESCRIPTION REMARKS 5-042-490-01 ASSY_21-SO-U27_BEZEL Bezel Liquid Crystal Display A-5071-920-A LCM ASSY WITH INDIVIDUAL PACKI 1 pc 5-042-496-01 SCREW M3L5 13 pcs SDM-27U9M2...
  • Page 18 1. Remove 3 screws (M3*3.5). REF. No. PART No. DESCRIPTION REMARKS 1-021-163-11 MOUNTED PWB FK BOARD (KEY) Key board 1-021-162-11 MOUNTED PWB (POWER LED BOARD) Power LED board 5-061-426-01 SO_U27_MK2_JOYSTICK MK2 Joystick cover 5-061-439-01 SPONGE_L12*W8*T10__EMI 1 pc 5-042-478-01 SCREW M3*3.5 3 pcs SDM-27U9M2...

  • Page 19: Circuit Boards Location

    2. CIRCUIT BOARDS LOCATION 2-1. CIRCUIT BOARDS LOCATION Function key board LED board Main board SDM-27U9M2...
  • Page 20 English 2024FL08-Data Made in Japan 9-897-202-41 © 2024 Sony Corporation SDM-27U9M2...
