3.2 Operating Indicator
Description
Light
Status
Fast flashes (1s gap)
Normal
Slow flashes (3s gap)
Communication error
Green
Slow flashes (5s gap)
PV input error
Light on
Ground error
Fast flashes (1s gap)
Error
Red
Fast flashes (2s gap)
AC error
4. System Commissioning
4.1 Installing the App
Method 1
Method 2
Download the "HYXiPOWER
Scan the QR code and
download the APP :
APP" from the app store:
• App Store (IOS)
• Google Play
4.2 APP Quick Guide
Set up monitoring system please refer to the DMU User Manual or DMU Quick
Installation Guide.
For more information on using the HYXiPOWER APP, please scan the QR
code.
App Quick Guide
6.2.51.18.00062
QIEN-M500-S-NA-Ver1.0-202312
App Download
Product information is subject to change without notice.
© 2023 Zhejiang Hyxi Technology Co., Ltd. All rights reserved.
QUICK
INSTALLATION
GUIDE
MICRO
INVERTER
M300/400/500-S-NA
www.hyxipower.com
