HYXIPOWER M600-SW-NA User Manual

Micro inverter

Advertisement

Quick Links

User Manual
M600/800/1000-SW-NA
MICRO
INVERTER
Carefully read this inverter user instructions before using.
Read and save these instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M600-SW-NA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HYXIPOWER M600-SW-NA

  • Page 1 User Manual M600/800/1000-SW-NA MICRO INVERTER Carefully read this inverter user instructions before using. Read and save these instructions.
  • Page 2 ZHEJIANG HYXI TECHNOLOGY CO., LTD ( hereinafter referred to as "HYXIPOWER" ). TRADEMARKS and other HYXIPOWER trademarks are the trademarks or registered trademarks of HYXIPOWER All other trademarks mentioned herein are the properties of their respective owners.
  • Page 3: Table Of Contents

    HYX-M600/800/1000-SW-NA User Manual Contents Contents 1. Safety Instructions ..............................1 1.1 Safety Instruction .................................1 1.2 Symbol Description ................................1 1.2.1 Symbols Used in the Manual ............................1 1.2.2 Other Symbols .................................2 1.3 Radio Wave Interference Statement ..........................2 2. Product Introduction .............................. 3 2.1 Photovoltaic On-Grid System ............................3 2.2 Microinverter ..................................3 2.3 2-in-1 Microinverter System ............................4 2.4 Communication Technology ............................4...
  • Page 4 HYX-M600/800/1000-SW-NA User Manual Contents 5.4 End-of-life Disposal ................................16 6. Human-Computer Interaction ..........................17 6.1 Installing the App ................................17 6.2 APP User manual ................................17 6.3 System debugging ................................17 6.4 Network Configuration ..............................17 7. Appendix ................................... 18 7.1 Technical Specifications ..............................18 7.2 Grid Support Details ...............................19 7.3 Wiring Diagram .................................21 7.4 Installation Map .................................21...
  • Page 5: Safety Instructions

    • Before disconnecting the microinverter from the solar module, the AC side power grid must be disconnected first. • If the microinverter does not work normally, contact after sales services of HYXIPOWER. Unauthorized destruction or opening of the microinverter will not be covered by warranty.
  • Page 6: Other Symbols

    HYX-M600/800/1000-SW-NA User Manual 1. Safety Instructions CAUTION • To avoid potential safety hazards, the corresponding instructions must be strictly followed. NOTICE • This operation is prohibited, and relevant personnel should stop the operation. 1.2.2 Other Symbols Symbol Description Caution When the device is running, do not step within 0.2 m of its periphery. High Voltage The high voltage generated by microinverter can endanger life.
  • Page 7: Product Introduction

    2.1 Photovoltaic On-Grid System The on-grid system diagram of HYX-M1000-SW-NA series microinverter is as follows: 2.2 Microinverter HHYX-M600-SW-NA, HYX-M800-SW-NA, HYX-M1000-SW-NA series are 2-in-1 microinverters, which can connect two photovoltaic modules. They are module-level photovoltaic inverters with module- level monitoring function.
  • Page 8: 2-In-1 Microinverter System

    1-in-1 2-in-1 4-in-1 This manual mainly introduces Hyxipower 2-in-1 microinverter series. This series of HYX-M1000-SW-NA has outstanding performance in 2-in-1 series, with an output power up to 960VA. Each microinverter can be connected to two photovoltaic modules. It has independent MPPT and module-level data monitoring functions, high power generation, easy and convenient maintenance features.
  • Page 9: Inverter Size And Termnial Instruction

    HYX-M600/800/1000-SW-NA User Manual 2. Product Introduction 2.6 Inverter Size and Termnial Instruction A: AC Branch Connector B: Antenna C: DC terminal...
  • Page 10: Installation

    HYX-M600/800/1000-SW-NA User Manual 3. Installation 3. Installation Each microinverter is installed on a mount just below the solar module panel. The low-voltage DC line on the panel side of the solar module can be directly connected to the microinverter, but it must be protected from direct sunlight, rain, snow, ultraviolet rays, etc. It is recommended to leave a gap of at least 50mm around the microinverter casing to ensure ventilation and heat dissipation.
  • Page 11: Installation Procedures

    HYX-M600/800/1000-SW-NA User Manual 3. Installation 3.3 Installation Procedures 3.3.1 How to Make a T-Junction Bus • Step 1: Prepare several sections of T-junction connecting wires according to the number of microinverters to be installed on site. • Step 2: Removing the T-junction cable at the end. Use the T-knot removal tool to remove the Loosen the inner screw, unscrew the nut, and lower cover.
  • Page 12: Microinverter Installation

    HYX-M600/800/1000-SW-NA User Manual 3. Installation • Step 4: Secure the T-junction cable Put the T-junction connecting wire on the guide rail and fix it with cable tie. CAUTION • Nut tightening torque: 2.5±0.5N·m, Screw tightening torque: 0.8±0.1N·m, Do not over-tighten, Do not damage the sealing ring in the T-junction connector during assembly and disassembly.
  • Page 13: Connect Pv Module

    HYX-M600/800/1000-SW-NA User Manual 3. Installation 3.3.4 Connect PV module • Step 1: Install the PV module above the microinverter. • Step 2: Connect the DC output cable of the PV module with the input side of the microinverter. CAUTION • Ensure that the output current and voltage of the PV modules are consistent with the inverter.
  • Page 14: Operate And Power On

    • Step 1: Close the main Grid circuit breaker. • Step 2: Close the AC circuit breaker of each microinverter branch, and the system will automatically generate power after about 2 minutes. • Step 3: Set up monitoring system on HYXiPOWER Smart PV Cloud Platform.
  • Page 15: Fault Clearance

    HYX-M600/800/1000-SW-NA User Manual 4. Fault Clearance 4. Fault Clearance Only qualified professionals can implement the following troubleshooting operations when the microinverter solar system is not working properly. 4.1 Status indication and error reporting 4.1.1 Start indicator When the DC side of the microinverter is powered on for the first time : •...
  • Page 16 HYX-M600/800/1000-SW-NA User Manual 4. Fault Clearance Fault code Fault description Solution 1.Occasionally, it may be a short-term power grid abnormality. When the power grid is normal, it will resume work without manual intervention. 2.If all the microinverters in the power station have 3082 Island protection frequent islanding alarms, please contact the power...
  • Page 17: On-Site Inspection (Qualified Installers Only)

    HYX-M600/800/1000-SW-NA User Manual 4. Fault Clearance Fault code Fault description Solution 1.If the input DC voltage is too high, please ensure that the input photovoltaic module voltage flow is PV1-PV4 absorption capacity overvoltage not higher than the maximum input voltage of the 3098 Inverter bridge 1 hardware microinverter.
  • Page 18 HYX-M600/800/1000-SW-NA User Manual 4. Fault Clearance technical parameter table of the user manual. • Step 7: If the problem persists, please call Hyxipower's customer support number. Precautions for routine maintenance: DANGER • Do not attempt to repair the microinverter, if troubleshooting fails, return it to the factory for a replacement.
  • Page 19: Maintenance Guide

    HYX-M600/800/1000-SW-NA User Manual 5. Maintenance Guide 5. Maintenance Guide 5.1 Routine maintenance • Only authorized personnel are allowed to perform maintenance operations and are responsible for reporting abnormal conditions. • Wear personal protective equipment for maintenance operations. • In normal operation, check the environment. Make sure that the environment does not meet the normal working requirements of the microinverter due to time changes, and ensure that the microinverter is not exposed to harsh weather and is not covered by foreign objects.
  • Page 20: End-Of-Life Disposal

    HYX-M600/800/1000-SW-NA User Manual 5. Maintenance Guide 5.4 End-of-life Disposal If the device is no longer in use or needs to be stored for a long time, please make sure that the packaging is intact. Store the device in a well-ventilated indoor area that will not cause damage to device components.
  • Page 21: Human-Computer Interaction

    Scan the QR code and download the APP: 6.2 APP User manual For more information on using the HYXiPower APP, please refer to the user manual "HYXiPower APP". 6.3 System debugging For system configuration and debugging, please refer to the user manual "HYXipower Local Debugging APP".
  • Page 22: Appendix

    HYX-M600/800/1000-SW-NA User Manual 7. Appendix 7. Appendix 7.1 Technical Specifications Product Model HYX-M600-SW-NA HYX-M800-SW-NA HYX-M1000-SW-NA Input (DC) Typical module compatibility 240-450 ⁺ W 320-600 ⁺ W 400-700 ⁺ W MPPT voltage range 16-60V Max. input voltage Start-up input voltage Max. input current 16A/16A Max.
  • Page 23: Grid Support Details

    North American UL1741 、 UL1741SB, IEEE 1547-2018, IEEE 1547.1-2020, IEEE 1547a-2020, HECO SRD 2.0, C22.2 No.107.1-16. The Grid Support functions are controlled on HYXiPOWER Monitoring Platform and the DMU is required in this PV system. Symbol...
  • Page 24: Manufacturer's Stated Accuracy

    Adjustment Range "Inductive, under excited, power factor " -0.8 "Capacitive, overexcited, power factor " Manufacturer’s Stated Accuracy HYX- HYX- HYX- Units M600-SW-NA M800-SW-NA M1000-SW-NA Output power rating "Reactive power absorption (inductive, under excited)" "Reactive power production (capacitive, overexcited)" Manufacturer’s Stated Accuracy...
  • Page 25: Wiring Diagram

    HYX-M600/800/1000-SW-NA User Manual 7. Appendix 7.3 Wiring Diagram Wiring Diagram 7.4 Installation Map 7.5 Contact Information If you have any questions about this product, please contact us ! In order to provide you with faster and better after-sales service, we need your assistance to provide the following information: Device model:...
  • Page 26 Version: UM_HYX-M1000-SW-NA_V1.2-202410_NA The manual is subject to change without notice while the product is being improved. Zhejiang Hyxi Technology Co., Ltd. Room 216, Block A, Building 1, No. 57 Jiang'er Road, Changhe Street, Binjiang District, Hangzhou, Zhejiang Province, China www.hyxipower.com support@hyxipower.com...
