Summary of Contents for HYXIPOWER Sub-1G
- Page 1 Zhejiang Hyxi Technology Co., Ltd. Quality Innovation Efficiency Win-win 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 2 Preparation Microinverters Physical Installation Contents DMU Physical installation APP configuration 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 3 Preparation 1 - Overall wiring diagram T-junction Removal Tool Distribution box T-junction Bus End Plug T-junction connecting wire Grid … T-junction Branch Port Protection Cover LOAD DC Connector Removal Tool DC Extension Cable Smart Meter WiFi/Ethernet/4G HYXipower Cloud 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 4 （If the DMU is installed inside a metal box, under a metal concrete roof, or in a complex installation environment that results in weak signal strength, it is recommended to add an external antenna to the Sub-1G External antenna DMU to increase signal strength） (Short one)
- Page 5 Preparation 3 - Products included in the above diagram Product Name Picture Description Used to extend the connection distance between DC Extension Cable micro inverters and photovoltaic modules Used to protect unused bus connection ports on T-junction Bus End Plug AC bus connectors at the end of AC branches T-junction Branch Port Protection Used to protect unused branch connection ports...
- Page 6 Buy from Local 0.5mm² For equipment grounding use Ground wire 4~10mm² Buy from Local Used to extend the connection distance DC-EC-1m Buy from Hyxipower between micro inverters and photovoltaic DC Extension Cable modules or Local 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 7 Preparation 5 - T-junction Installation Instructions Double-row vertical installation Single-row vertical installation 1-in-1 <1.6m 1-in-1 <1.6m TJ-Cable-20T-19L-10AWG-1.6m-NA TJ-Cable-20T-19L-10AWG-1.6m-NA 2-in-1 <1.6m 2-in-1 <3m TJ-Cable-13T-12L-10AWG-3m-NA TJ-Cable-20T-19L-10AWG-1.6m-NA 4-in-1 <5.7m 4-in-1 <3m TJ-Cable-7T-6L-10AWG-5.7m-NA TJ-Cable-13T-12L-10AWG-3m-NA 浙江大华技术股份有限公司 | www.dahuatech.com Example: Microinverters PV panels AC cables...
- Page 8 Preparation 6 - T-junction Installation Instructions Single-row horizontal installation 1-in-1<3m TJ-Cable-13T-12L-10AWG-3m-NA 2-in-1<5.7m TJ-Cable-7T-6L-10AWG-5.7m-NA Example: 4-in-1<11m (almost no such installation) TJ-Cable-7T-6L-10AWG-5.7m-NA Microinverters PV panels Double-row vertical installation 1-in-1 <3m AC cables TJ-Cable-13T-12L-10AWG-3m-NA 2-in-1 <3m TJ-Cable-13T-12L-10AWG-3m-NA 4-in-1 <5.7m 浙江大华技术股份有限公司 | www.dahuatech.com TJ-Cable-7T-6L-10AWG-5.7m-NA...
- Page 9 Preparation 7 - Microinverter Introduction Name AC Branch Connector Antenna DC terminal Light Status Meaning Fast flashes(1s gap) Normal Fast flashes(3s gap) Communication Fault Green Fast flashes(5s gap) PV input fault Light on Ground fault Fast flashes(1s gap) Fault Fast flashes(1s gap) AC fault 浙江大华技术股份有限公司...
-
Page 10: Interface Layout
Preparation 8 - DMU introduction Interface Layout Indicator Lights Description Name Description External Sub-1G antenna interface POWER Power indicator SD card slot Network communication USB port (connecting to the server) DRM port Microinverter communication COM. (connecting to microinverter） Ethernet port... - Page 11 Preparation 9 - Tools Preparation Wire nippers Tape measure Cable tie Screwdriver Wire stripper Marker Multimeter Safety gloves Hexagon wrench Utility knife 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 12 Preparation Microinverters Physical Installation Contents DMU Physical installation APP configuration 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 13 Insert the lower T-junction cover back Install a T-junction bus end plug at the into place and make sure it is secure. end of the T-junction. 浙江大华技术股份有限公司 | www.dahuatech.com Installation video: https://webfile.hyxipower.com/soft/20240102/Installation-Video_Microinverter_Ver1.0-202311.mp4...
- Page 14 Microinverter installation 2 - Install T-junction Bus cables Step 3: T-junction and bus connection Insert the AC cable into the T-junction Prepare the AC cable by stripping the connector at the correct hole position. ends. Tighten the screws, and then the nuts. Insert the lower T-junction cover back into place, making sure it is secure.
- Page 15 Microinverter installation 3 - Draw Installation Map Installation Map: Step1: Record the location of the Microinverters to facilitate operation and maintenance Step2: Facilitate the establishment of connection between DMU and microinverter 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 16 Microinverter Installation 4 - Microinverter Installation Step 1: Mark the installation position of the Microinverter on the bracket according to the layout of the photovoltaic modules. Step 2: Fix the Microinverter on the bracket with M8*25mm screw, then lock the screw. 浙江大华技术股份有限公司...
- Page 17 Microinverter Installation 5 - Metal roof Scenario Equipment antenna placement Cable grooming Equipment installation height × × × Cables tangled haphazardly The antenna is at the peak of The distance between Microinverters the Metal roof around the antenna and the Metal roof is less than 3 inches √...
- Page 18 Microinverter Installation 6 - Connect Microinverter with T-junction Connect Microinverter with T-junction Insert the output AC feeder connector of the microinverter into the T-junction bus connector Until hearing a ‘click’ sound. Ensure that the installation is tight. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 19 Microinverter Installation 7 - Connect PV module Connect PV module 1. Install the PV module above the microinverter. 2. Connect the DC output cable of the PV module with the input side of the microinverter. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 20 Preparation Microinverters Physical Installation Contents DMU Physical installation APP configuration 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 21 DMU Installation 1 - Accessories display Name Power adapter Screws Mount Fixed base Quick installation guide Installation map 浙江大华技术股份有限公司 | www.dahuatech.com...
-
Page 22: Wall-Mounted
DMU Installation 2 - Under roof Scenario Install on desktop Wall-mounted Installation video: https://webfile.hyxipower.com/soft/20240102/Installation-Video_HYX-DMU-4G_Ver1.0-202311.mp4 浙江大华技术股份有限公司 | www.dahuatech.com... - Page 23 DMU Installation 3 - Metal Roof Scenario Example Microinverters (under PV panels) Photovoltaic panel Waterproof box & DMU Please note: 1. The installation angle of the Sub_1G antenna needs to be vertically upward, and there should be no metal obstructions around it. 2.
- Page 24 DMU Installation 4 - Metal roof Scenario External antennas: Short one: sub-1g antenna Place DMU in waterproof box on metal Long one: 4g/WiFi antenna roof and use External antennas Press the reset button 5 times quickly to switch modes(Internal to External)
- Page 25 DMU Installation 7 - Check signal strength 1. Please do not fix the position of the DMU in advance if possible. 2. The signal values of the DMU and the microinverter can be detected during software configuration. page 44-45 “ ”...
- Page 26 Meter Installation (Optional) Meter RS485A&B Recommended specifications of the meter-DMU 2-pin 485 cable: 0.5 square mm RVVP shielded twisted pair wire. Arrow points to the Grid. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 27 Preparation Microinverters Physical Installation Contents DMU Physical installation APP configuration 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 28 APP configuration 1 - Registration 1. Download HYXipower APP . Registration 2. Register the account of the person in charge of the organization. 1.Connect your phone to DMU Near-end 2.Connect Microinverters to DMU Commissioning 3.Connect DMU to Internet Check Signal...
- Page 29 Step 1: Download the APP and register . organization , fill in the relevant information and register. Method 1 Search “Hyxipower " in the App Store · APP store (IOS) · Google play Method 2 Scan the QR code download the APP 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 30 APP Configuration 1 – Download&Registration - Admin registration Step 3 : Log in to your account , select Service - Member Management , and then select " " Invite members . It is recommended to choose the administrator role. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 31 APP configuration 2 - Near-end Commissioning 1. Download HYXipower APP . Registration 2. Register the account of the person in charge of the organization. 1.Connect your phone to DMU Near-end 2.Connect Microinverters to DMU Commissioning 3.Connect DMU to Internet Check Signal...
- Page 32 APP configuration 2 - Connect Phone to DMU Step 1: Open the APP. Please update APP before debugging if there is one. Select More and choose your local server. Then choose Near-end Commissioning. It will take few seconds download the latest firmware.
- Page 33 APP configuration 2 - Connect Phone to DMU Step 2: Scan the barcode of the DMU, Step 3: If the barcode cannot be recognized, Join WLAN network DMU-XXXXXXXXXXXX. You can also choose to connect manually. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 34 APP configuration 2 - Connect phone to DMU Find the WIFI in settings of phone starting with DMU and connect: DMU-XXXXXXXXXXXX; to the “Hyxipower" APP and select Next. Password is hyxi0607 or 12345678, after connected, return Keep the APP running in...
-
Page 35: Android System
APP configuration 2 - Connect Phone to DMU Android system : Find the WIFI in settings of phone starting with DMU and connect: DMU-XXXXXXXXXXXX; to the “Hyxipower" APP and select Next. Password is hyxi0607 or 12345678, after connected, return WIFI setting interface... - Page 36 APP configuration 2 - Connect Phone to DMU Step 4: Scan DMU’s barcode and log in device : select Installer or Owner, Initial default password: hyxi0607 or 12345678 If you forget the password, you can quickly press the DCS RESET button 4 times to reset password. 浙江大华技术股份有限公司...
- Page 37 APP configuration 2 - Connect DMU to Microinverters Step 6: Select "Inverter" and scan the barcode of the Step 5: Enter quick settings Microinverters to connect them to DMU. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 38 APP configuration 2 - Connect DMU to Microinverters Add Microinverters to the certain DMU by scanning the barcode on the installation map. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 39 APP configuration 2 - Meter Step 9: Click "Configuration of Meters" , fill in the number of Step 8: Click meter and select "Grid type" meters (Usually 3) and address of meters(The default address is 1) Check and connect the meter according to the diagram 浙江大华技术股份有限公司...
- Page 40 APP configuration 2 - Meter Step 10: Select the “Mounting position” for the current meter, and select the address of the current meter, and the APP will automatically assign an address to the current meter. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 41 APP configuration 2 - Setup Time Zone and Grid code Step 11: Enter the grid connection Setup and set the Step 12: Setup Export Control, Choose time zone and grid code according to local regulations whether to feed power to the grid 浙江大华技术股份有限公司...
- Page 42 APP configuration 2 - Connect DMU to Internet Step 13: Communication settings, Choose your local server, fill in the Wi-Fi name and password for wireless mode. Confirm the automatic IP acquisition switch is for wired connection mode. No need to fill in the APN, username and password for the...
- Page 43 APP configuration 3 - Check Signal Strength 1. Download HYXipower APP . Registration 2. Register the account of the person in charge of the organization. 1.Connect your phone to DMU Near-end 2.Connect Microinverters to DMU Commissioning 3.Connect DMU to Internet...
- Page 44 APP configuration 3 - Check Signal Strength Step 1: Check the sub-1g signal between microinverters and each DMU through COMM.Maintenance 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 45 APP configuration 3 - Check Signal Strength The current proportion of “No different signal Step 2: Check the microinverters with Signal” equipment. “Weak Signal”, and adjust the installation method of the Microinverter and the installation position and quantity of DMU to ensure that the signals of all devices are above “Moderate Signal”.
- Page 46 APP configuration 4 - Create a Plant for Owner 1. Download HYXipower APP . Registration 2. Register the account of the person in charge of the organization. 1.Connect your phone to DMU Near-end 2.Connect Microinverters to DMU Commissioning 3.Connect DMU to Internet...
- Page 47 Scan the QR code of the DMU or add it account, click the Add Plant phone from the DMU’s through the Recently debugged device button WiFi. Make sure your phone has Internet access 浙江大华技术股份有限公司 | www.dahuatech.com Create Plant video: https://webfile.hyxipower.com/soft/20231129/HYXiPOWER-APP_Create-plants_Ver1.0-20231103.mp4...
- Page 48 APP configuration 4 - Create a Plant for the owner Step 4: Add owner - manually add or scan the owner's QR code to bind. Manually add - enter the email address or mobile phone number of the Plant owner. If the owner is not registered, click to help him register and bind. The system will generate a random password and send a text message or email to the registered account 浙江大华技术股份有限公司...
- Page 49 APP configuration 4 - Create a Plant for the owner Step 5: Plant name-Plant type(House hold Use)- Region-Time Zone Step 6: More Info-Next. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 50 APP configuration 4 - Create a Plant for the owner Step 6: Fill in Electricity Pice Type, Currency and Revenue per KWh, select Finish, and the Plant is successfully created. 浙江大华技术股份有限公司 | www.dahuatech.com...
- Page 51 Installation Acceptance Step 1: Select Plant User's Plant - Device, and ensure that the online state of device is correct. Step 2: After installation is completed, continuously monitor for more than half an hour, select Statistics Energy Analysis , view the realtime power statistics curve, and ensure that the Plant has started generating electricity normally.
- Page 52 THANKS Zhejiang Hyxi Technology Co., Ltd. Innovatio Quality Efficiency Win-win 浙江大华技术股份有限公司 | www.dahuatech.com...
