Panasonic RX-SA79 Service Manual

Service
Stereo Radio Cassette Player
General:
Power Requirement:
Power Output:
Input:
Output:
Dimensions:
Weight:
Radio Section:
Radio Frequency Range:
Intermediate Frequency:
Sensitivity:
Tape Deck Section:
Frequency Response:
Motor:
Track System:
Tape Speed:
RX-SA79 Mechanism Series
M@ SPECIFICATIONS
ORDER NO. GAD8712228C2
Radio Cassette
RX-SA/9
Color
ee ee For All European
areas except United
Kingdom.
eee For United Kingdom.
7MW(3.5MWx2) ... RMS(max.)
DC IN; 1.5V(mini jack)
Headphones; 350 93.5
85.5x122.5x32mm
227g without batteries
FM; 87.5~108MHz
AM; 520~1610KHz
FM; 10.7MHz
AM; 455kHz...[Z] 470kHz...[ZE]
FM; 3nV/0.04mW output (-3dB Limit Sens)
AM; 100uV/m/0.04mW output
Normal; 20~15,000Hz
CrO2; 20~15,000Hz
Metal; 20~15,000Hz
Electrical governor motor
4-track 2-channel stereo playback
1-7/8ips(4.8cm/s)
'Weights and dimensions shown are approximate.
Design and specifications are subject to change without notice.
